Abusing JavaScript to Measure Web Performance

  1. 1. • Philip Tellis• .com• philip@lognormal.com• @bluesmoon• geek paranoid speedfreak• http://bluesmoon.info/ Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 1
  2. 2. I <3 JavaScriptBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 2
  3. 3. So much that I wore Mustache socks to my wedding Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 3
  4. 4. I’m also a Web SpeedfreakBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 4
  5. 5. We measure real user website performanceBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 5
  6. 6. This talk is (mostly) about how we abuse JavaScript to do it Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 6
  7. 7. Abusing JavaScript to Measure Web Performance Philip Tellis / philip@lognormal.com Boston #WebPerf Meetup / 2012-07-24Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 7
  8. 8. First, a note about the code Note that in the code that follows, + new Date is equivalent to new Date().getTime() Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 8
  9. 9. 1 LatencyBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 9
  10. 10. 1 Blinking Lights It takes about 16ms for light to get from SF to Boston (24ms through fibre) ... Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 10
  11. 11. 1 Blinking Lights It takes about 16ms for light to get from SF to Boston (24ms through fibre) Though it takes about 100ms to ping... why? Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 10
  12. 12. 1 HTTP Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 11
  13. 13. So to measure latency, we need to send 1 packet each way, and time it Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 12
  14. 14. 1 Network latency in JavaScript var ts, rtt, img = new Image; img.onload=function() { rtt=(+new Date - ts) }; ts = +new Date; img.src="/1x1.gif"; Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 13
  15. 15. 1 Notes • 1x1 gif is 35 bytes • including HTTP headers, is smaller than a TCP packet • Fires onload on all browsers • 0 byte image fires onerror • which is indistinguishable from network error Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 14
  16. 16. 2 TCP handshakeBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 15
  17. 17. 2 ACK-ACK-ACK Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 16
  18. 18. 2 Connection: keep-alive Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 17
  19. 19. 2 Network latency & TCP handshake in JavaScript var t=[], tcp, rtt; var ld = function() { t.push(+new Date); if(t.length > 2) // run 2 times done(); else { var img = new Image; img.onload = ld; img.src="/1x1.gif?" + Math.random() + ’=’ + new Date; } }; var done = function() { rtt=t[2]-t[1]; tcp=t[1]-t[0]-rtt; }; ld(); Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 18
  20. 20. Notice that we’ve ignored DNS lookup time here... how would you measure it? Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 19
  21. 21. Network Throughput 3Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 20
  22. 22. 3 Measuring Network Throughput data_length download_time Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 21
  23. 23. Should you fly a 747 or a 737? • A 747 seats 400+ passengers • A 737 seats about 150 • Both take about the same time to fly from SFO to BOS • A 747 takes longer to load and unload The best selling aircraft to date is the 737 Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 22
  24. 24. 3 Network Throughput in JavaScript // Assume global object // image={ url: ..., size: ... } var ts, rtt, bw, img = new Image; img.onload=function() { rtt=(+new Date - ts); bw = image.size*1000/rtt; // rtt is in ms }; ts = +new Date; img.src=image.url; Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 23
  25. 25. 3 Measuring Network Throughput If it were that simple, I wouldn’t be doing this talk. Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 24
  26. 26. 3 TCP Slow Start Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 25
  27. 27. 3 Measuring Network Throughput So to make the best use of bandwidth, we need resources that fit in a TCP window Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 26
  28. 28. 3 There is no single size that will tax all available networks http://www.yuiblog.com/blog/2010/04/08/analyzing-bandwidth-and-latency/ Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 27
  29. 29. 3 Network Throughput in JavaScript – Take 2 // image object is now an array of multiple images var i=0; var ld = function() { if(i>0) image[i-1].end = +new Date; if(i >= image.length) done(); else { var img = new Image; img.onload = ld; image[i].start = +new Date; img.src=image[i].url; } i++; }; Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 28
  30. 30. 3 Measuring Network Throughput Slow network connection, meet really huge image Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 29
  31. 31. 3 Network Throughput in JavaScript – Take 3 var img = new Image; img.onload = ld; image[i].start = +new Date; image[i].timer = setTimeout(function() { image[i].expired=true }, image[i].timeout); img.src=image[i].url; Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 30
  32. 32. 3 Network Throughput in JavaScript – Take 3 if(i>0) { image[i-1].end = +new Date; clearTimeout(image[i-1].timer); } Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 31
  33. 33. 3 Network Throughput in JavaScript – Take 3 if(i >= image.length || (i > 0 && image[i-1].expired)) { done(); } Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 32
  34. 34. 3 Measuring Network Throughput Are we done yet? Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 33
  35. 35. 3 Measuring Network Throughput Are we done yet? sure... Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 33
  36. 36. 3 Measuring Network Throughput Except network throughput is different every time you test it Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 34
  37. 37. Statistics to the Rescueflickr/sophistechate/4264466015/ Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 35
  38. 38. 3 Measuring Network Throughput The code for that is NOT gonna fit on a slide Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 36
  39. 39. But this is sort of what we see world-wide Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 37
  40. 40. And it’s different for different countries This is India Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 38
  41. 41. 4 DNSBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 39
  42. 42. 4 Measuring DNS time_with_dns − time_without_dns Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 40
  43. 43. 4 Measuring DNS in JavaScript var t=[], dns, ip, hosts=[’http://hostname.com/’, ’http://ip.ad.dr.ess/’]; var ld = function() { t.push(+new Date); if(t.length > hosts.length) done(); else { var img = new Image; img.onload = ld; img.src=hosts[t.length-1] + "/1x1.gif"; } }; var done = function() { ip=t[2]-t[1]; dns=t[1]-t[0]-ip; }; ld(); Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 41
  44. 44. 4 Measuring DNS • What if the IP changes? • What if DNS is cached? • What if you map DNS based on geo location? Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 42
  45. 45. 4 Wildcard DNS Entries *.foo.com → IP address Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 43
  46. 46. 4 Measuring DNS in JavaScript – take 2 var base_url="http://*.foo.com/", timers = {}, gen_url=""; function start() { var random = Math.random().toString(36), cache_bust = Math.random(), img = new Image(); gen_url = base_url.replace(/*/, random); img.onload = A_loaded; timers.start = +new Date; img.src = gen_url + "image-l.gif?t=" + cache_bust; } Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 44
  47. 47. 4 Measuring DNS in JavaScript – take 2 function A_loaded() { var cache_bust = Math.random(), img = new Image(); img.onload = B_loaded; timers.a_loaded = +new Date; img.src = gen_url + "image-l.gif?t=" + cache_bust; } I’ll let you figure out B_loaded Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 45
  48. 48. 4 Measuring DNS Full code in boomerang’s DNS plugin Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 46
  49. 49. 5 IPv6Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 47
  50. 50. 5 Measuring IPv6 support and latency 1 Try to load image from IPv6 host • If timeout or error, then no IPv6 support • If successful, then calculate latency and proceed 2 Try to load image from hostname that resolves only to IPv6 host • If timeout or error, then DNS server doesn’t support IPv6 • If successful, calculate latency Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 48
  51. 51. 5 Measuring IPv6 support and latency Full code in boomerang’s IPv6 plugin Note, only run this if you know IPv6 is supported by the client Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 49
  52. 52. 6 Other StuffBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 50
  53. 53. 6 Other Stuff We Measure • NavTiming – navtiming.js • navigation.connection.type – mobile.js • window.performance.memory – memory.js • Number of DOM nodes and byte size of HTML – memory.js Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 51
  54. 54. And we try to do it fastBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 52
  55. 55. – .done()Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 53
  56. 56. Code/References • http://lognormal.github.com/boomerang/doc/ (BSD Licensed) • www.lognormal.com Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 54
  57. 57. • Philip Tellis• .com• philip@lognormal.com• @bluesmoon• geek paranoid speedfreak• http://bluesmoon.info/ Boston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 55
  58. 58. Thank you Ask me about a discount codeBoston #WebPerf Meetup / 2012-07-24 Abusing JavaScript to Measure Web Performance 56
