Storm - pipes andfilters on steroids      Andre Sprenger    BigData Roundtable   Hamburg 30. Nov 2011
My background•   info@andresprenger.de•   Studied Computer Science and Economics•   Background: banking, ecommerce, online...
“Next click” problemRaymie Strata (CTO,Yahoo):“With the paths that go through Hadoop [at Yahoo!], thelatency is about fifte...
“Next click” problem                             (next) HTTP         HTTP           HTTP          HTTPRequest      Respons...
Example problems•   Realtime statistics - counting, trends, moving average•   Read Twitter stream and output images that a...
Pick your framework...•   S4 - Yahoo, “real time map reduce”, actor model•   Storm - Twitter•   MapReduce Online - Yahoo• ...
System requirements•   Fault tolerance - system keeps running when a node    fails•   Horizontal scalability - should be e...
Storm in a nutshell•   Written by Backtype (aquired by Twitter)•   Open Source, Github•   Runs on JVM•   Clojure, Python, ...
Programming model•   Tuple - name/value list•   Stream - unbounded sequence of Tuples•   Spout - source of Streams•   Bolt...
Spout        tuple tuple tuple tupleSpout        tuple tuple tuple tuple
Bolt   Processes streams and generates new streams.tuple tuple tuple tuple                                  tuple tuple tu...
Bolt•   filtering•   transformation•   split / aggregate streams•   counting, statistics•   read from / write to database
TopologyNetwork of Streams, Spouts and Bolts                    Bolt         Bolt     Spout                    Bolt     Sp...
TaskParallel processor inside Spouts and Bolts.Each Spout / Bolt has a fixed number of Tasks.      Spout                Bol...
Stream groupingWhich Task does a Tuple go to?•   shuffle grouping - distribute randomly•   field grouping - partition by fiel...
Word count example                Sentence            Word    (“a”, 2)                 Splitter           Count   (“b”, 2)...
Guaranteed processing                             (“a”)                             (“b”)                                 ...
Runtime view
Reliability•   Nimbus / Supervisor are SPOF•   both are stateless, easy to restart without data loss•   Failure of master ...
Administration•   Nimbus / Supervisor / Zookeeper need monitoring    and supervisor (e.g. Monit)•   Cluster nodes can be a...
Community•   Source is on Github - https://github.com/    nathanmarz/storm.git•   Wiki - https://github.com/nathanmarz/sto...
Storm summary•   Nice programming model•   Easy to deploy new topologies•   Horizontal scalability•   Low latency•   Fault...
Questions?
