Midgard2
Content repository for mobile applications
Henri
Bergius



          Microblogs: @bergie
              http://bergie.iki.fi
Content Repository


Don't invent your own file formats
Content Repository


Objects instead of SQL
Content Repository


            Objects instead of SQL




http://xkcd.com/327/
Content Repository


Signals about changes
Content Repository


Data model is scriptable
Content Repository


Synchronization and sharing
With a content repository
incredible power is at your disposal
Free Content Repositories


•   Schema-based, relational   •   Schema-free
•   Query Builder              •   Javascript m...
...and they talk to each other
The Midgard Project
•   Free software project    •   Object-Relational
    since 1999                   Mapping, trees, D-...
Midgard on Maemo 5




Conboy: notes on your phone
Midgard on Maemo 5




Workstreamer: project tracking for N900
Midgard on the web




Qaiku.com: conversational microblogging
Getting started with Midgard
Installation
•   Linux distribution repositories (Ubuntu, Debian, RHEL,
    OpenSuse etc) on OBS:
    http://download.open...
Objects are defined by MgdSchema
<!-- This will be installed to /usr/share/midgard2/schema/ -->
<type name="midgard_person...
Midgard API for PHP
<?php
// Load the Midgard2 API extension
dl('midgard2.so');

// Set up the repository config
$config =...
Midgard API for PHP
// Create a new person object
$person = new midgard_person();
$person->firstname = 'Leif';
$person->la...
import antigravity




http://xkcd.com/353/
import antigravity
# Load the Midgard2 API extension
import _midgard as midgard

# Set up the repository config
configurat...
Midgard API: PHP vs. Python
// Create a new person object              # Create a new person object
$person = new midgard_...
Oh, and Vala too!
/* valac --debug --pkg midgard2 -o midgard-vala-example example.vala --vapidir=./ */
using GLib;
using M...
any tools you use, Midgard is there
...maybe even in your finger
How about Qt?
•   Midgard already
    works in PySide
    applications
•   Would be great to
    have proper Qt
    suppor...
Tree access

•   Parent-child relations
    •   get_parent()
    •   list_children()
•   Access via named paths
    •   ge...
Extending objects
•   Subclasses in MgdSchema
    <type name="bossa_attendee" extends="midgard_person">
       <property n...
Midgard MVC

Put your content repository on the web
Midgard MVC
•   Very efficient MVC
    framework for PHP
•   Python and D-Bus for
    background processing
•   Gettext + ...
Midgard MVC




Tomboy web synchronization with Midgard
Midgard Runtime
Explore the possibilities
           of content repositories




midgard2.org   #midgard on FreeNode   @MidgardProject
Upcoming SlideShare
Loading in...5
×

Midgard2 - Content Repository for mobile applications

2,349

Published on

Content repository presentation at Bossa Conference 2010

Published in: Technology
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
2,349
On Slideshare
0
From Embeds
0
Number of Embeds
0
Actions
Shares
0
Downloads
10
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

Midgard2 - Content Repository for mobile applications

  1. 1. Midgard2 Content repository for mobile applications
  2. 2. Henri Bergius Microblogs: @bergie http://bergie.iki.fi
  3. 3. Content Repository Don't invent your own file formats
  4. 4. Content Repository Objects instead of SQL
  5. 5. Content Repository Objects instead of SQL http://xkcd.com/327/
  6. 6. Content Repository Signals about changes
  7. 7. Content Repository Data model is scriptable
  8. 8. Content Repository Synchronization and sharing
  9. 9. With a content repository incredible power is at your disposal
  10. 10. Free Content Repositories • Schema-based, relational • Schema-free • Query Builder • Javascript map/reduce • C, glib, libgda • Erlang • LGPL • Apache License • D-Bus signals • JSON polling via HTTP • Library • Daemon midgard2.org couchdb.apache.org
  11. 11. ...and they talk to each other
  12. 12. The Midgard Project • Free software project • Object-Relational since 1999 Mapping, trees, D-Bus signals • Contributors from most European countries • APIs for C, PHP, Python, Vala, Objective-C, ... • Synchronized release model, every 6 months • Linux, Mac, Maemo
  13. 13. Midgard on Maemo 5 Conboy: notes on your phone
  14. 14. Midgard on Maemo 5 Workstreamer: project tracking for N900
  15. 15. Midgard on the web Qaiku.com: conversational microblogging
  16. 16. Getting started with Midgard
  17. 17. Installation • Linux distribution repositories (Ubuntu, Debian, RHEL, OpenSuse etc) on OBS: http://download.opensuse.org/repositories/home:/midgardproject:/mjolnir/ • After that Midgard is just an apt-get install python- midgard2 or apt-get install php5-midgard2 away • Maemo 4 and 5 available in Extras Devel (soon Extras) • On OS X use MacPorts or the ObjC bundle
  18. 18. Objects are defined by MgdSchema <!-- This will be installed to /usr/share/midgard2/schema/ --> <type name="midgard_person"> <property name="id" type="unsigned integer" primaryfield="id"> <description>Local non-replication-safe database identifier</description> </property> <property name="firstname" type="string" index="yes"> <description>First name of the person</description> </property> <property name="lastname" type="string" index="yes"> <description>Last name of the person</description> </property> <property name="birthdate" type="datetime"> <description>Birth date of the person</description> </property> <property name="email" type="string" index="yes"> <description>Email address of the person</description> </property> </type>
  19. 19. Midgard API for PHP <?php // Load the Midgard2 API extension dl('midgard2.so'); // Set up the repository config $config = new midgard_config(); $config->dbtype = 'SQLite'; $config->database = 'midgardexample'; // this will store to SQLite in ~/.midgard2/data/midgardexample.db // Open a Midgard repository connection $midgard = midgard_connection::get_instance(); $midgard->open_config($config); // Prepare storage for your data midgard_storage::create_base_storage(); midgard_storage::create_class_storage('midgard_person');
  20. 20. Midgard API for PHP // Create a new person object $person = new midgard_person(); $person->firstname = 'Leif'; $person->lastname = 'Eriksson'; $person->create(); // Query system for all persons with lastname "Eriksson" $qb = new midgard_query_builder('midgard_person'); $qb->add_constraint('lastname', '=', 'Eriksson'); $persons = $qb->execute(); foreach ($persons as $person) { echo "{$person->lastname}, {$person->firstname} has GUID {$person- >guid}n"; // Add an email address and update $person->email = 'leif@vinland.no'; $person->update(); }
  21. 21. import antigravity http://xkcd.com/353/
  22. 22. import antigravity # Load the Midgard2 API extension import _midgard as midgard # Set up the repository config configuration = midgard.config() configuration.dbtype = 'SQLite' configuration.database = 'midgardexample' # this will store to SQLite in ~/.midgard2/data/midgardexample.db # Open a Midgard repository connection connection = midgard.connection() connection.open_config(configuration) # Prepare storage for your data midgard.storage.create_base_storage() midgard.storage.create_class_storage('midgard_person')
  23. 23. Midgard API: PHP vs. Python // Create a new person object # Create a new person object $person = new midgard_person(); person = midgard.mgdschema.midgard_person() $person->firstname = 'Leif'; person.firstname = 'Leif' $person->lastname = 'Eriksson'; person.lastname = 'Eriksson' $person->create(); person.create() // Query system for all persons with # Query system for all persons with // lastname "Eriksson" # lastname "Eriksson" $qb = new qb = midgard.query_builder('midgard_person') midgard_query_builder('midgard_person'); qb.add_constraint('lastname', '=', 'Eriksson') $qb->add_constraint('lastname', '=', persons = qb.execute() 'Eriksson'); for person in persons: $persons = $qb->execute(); print "%s, %s has GUID %s" foreach ($persons as $person) % (person.lastname, person.firstname, { person.guid) echo "{$person->lastname},” # Add an email address and update . ” {$person->firstname}” person.email = 'leif@vinland.no' . “ has GUID {$person->guid}n"; person.update() // Add an email address and update $person->email = 'leif@vinland.no'; $person->update(); }
  24. 24. Oh, and Vala too! /* valac --debug --pkg midgard2 -o midgard-vala-example example.vala --vapidir=./ */ using GLib; using Midgard; namespace MidgardValaExample { void main() { Midgard.init(); Midgard.Config config = new Midgard.Config(); config.read_file ("midgard_test", true); Midgard.Connection cnc = new Midgard.Connection(); cnc.open_config (config) Midgard.Object person = new Midgard.Object (cnc, "midgard_person", null); person.set ("firstname", "Leif"); if (person.create()) { string guid; person.get ("guid", out guid); GLib.print ("Created new person identified by GUID %s n", guid); }
  25. 25. any tools you use, Midgard is there
  26. 26. ...maybe even in your finger
  27. 27. How about Qt? • Midgard already works in PySide applications • Would be great to have proper Qt support • Anybody want to help with this?
  28. 28. Tree access • Parent-child relations • get_parent() • list_children() • Access via named paths • get_by_path()
  29. 29. Extending objects • Subclasses in MgdSchema <type name="bossa_attendee" extends="midgard_person"> <property name="likesbeer" type="boolean" default="true" /> </type> • Ad-hoc additional properties object.set_parameter('bossa', 'key', 'value') value = object.get_parameter('bossa', 'key') • Binary attachments are also supported • Metadata in repository, file in filesystem • API provides access to filehandles
  30. 30. Midgard MVC Put your content repository on the web
  31. 31. Midgard MVC • Very efficient MVC framework for PHP • Python and D-Bus for background processing • Gettext + intl i18n • TAL templating • Full WebDAV support • Git for packaging and deployment
  32. 32. Midgard MVC Tomboy web synchronization with Midgard
  33. 33. Midgard Runtime
  34. 34. Explore the possibilities of content repositories midgard2.org #midgard on FreeNode @MidgardProject
