Acceptance &                           Integration                          Testing Using                              Beh...
Pair Programming                          Say hello to the person next to you....Saturday, 29 October 11
Set Up                          USB StickSaturday, 29 October 11
Set Up                                  For instant set up:            1) Copy code into a new vhost with the web root    ...
Set Up                                  Goto: tests/acceptance/            If setting up today run the Behat command using...
Me          Software Engineer          PHP Developer         Sky Bet         PHP / MySQL Stack         PHPUnit / Selenium ...
Roadmap        •Intro To Behaviour Driven Development        •Introducing Behat        •Gherkin & Steps        •API / Serv...
joind.in                          http://joind.in/talk/view/4328Saturday, 29 October 11
What Marco Said......Saturday, 29 October 11
StoriesSaturday, 29 October 11
What is BDD?Saturday, 29 October 11
Introducing Behat....Saturday, 29 October 11
Resistance is futile.......Saturday, 29 October 11Origins in Rubys cucumber
What Does It Test?                                Scripts                                 API’s                           ...
Integration Testing                                   !=                             Unit TestingSaturday, 29 October 11
Anatomy Of A Behat TestSaturday, 29 October 11
Saturday, 29 October 11Describes the behaviour in a storyHuman ReadableSamples Later
Saturday, 29 October 11PHP that maps to lines of the gherkin.Behat parses gherkin and runs the associatedsteps.
Writing Behat Tests                          $ben > cd /path/to/projects/tests                          $ben > behat --ini...
Writing Behat TestsSaturday, 29 October 11
Feature Files         Feature: Home Page                  When visiting the PHPCon site                  As a site visitor...
ScenariosScenario: Get all conferences    Given there is conference data in the database    When I go to the homepage    T...
Scenarios                              Given                          (Some Context)                              When    ...
Given                          (Some Context)            Given there is conference data in the databaseSaturday, 29 Octobe...
When                                  (Some Event)                              When I go to the homepage                 ...
Then                            (The Outcome)            Then I should see three conferences in a table            Then I ...
ConferenceService.feature      Feature: ConferenceService Class               In order to display conferences on          ...
Class Methods & AnnotationsSaturday, 29 October 11Written By our TESTERS - Fed In From BAsHow is this feature executed?Eac...
/ Everybody Stand Back /                Behat Knows Regular ExpressionsSaturday, 29 October 11PHP Annotations used to map ...
Demo One                          Behat’s - Regex FuSaturday, 29 October 11
Introducing.......                          The Sample DomainSaturday, 29 October 11
My Amazing PHP Conference                     WebsiteSaturday, 29 October 11
Service LayersSaturday, 29 October 11
Demo OneSaturday, 29 October 11
Fill in the Feature Context File          public function __construct(array $parameters)          {              $params =...
Fill in the Feature Context File        /**          * @Given /^there is conference data in the database$/          */    ...
Fill in the Feature Context File           /**             * @When /^I use the findConferences method$/             */    ...
Fill in the Feature Context File           /**             *@Then /^I should get an array of (d+) conferences$/           ...
/**                   * @Then /^it should contain the                   * conference "([^"]*)"$/                   */     ...
Exceptions == Test FailuresSaturday, 29 October 11
Demo Two                          Passing Behat TestSaturday, 29 October 11
Exercise One                          Testing a service layer with Behat.Saturday, 29 October 11
Exercise One                          Open the PDF in the misc folder.                            Read through Section One...
Failing TestSaturday, 29 October 11If exceptions are encountered .....
Passing Test!Saturday, 29 October 11
What about the UI?Saturday, 29 October 11We’ve covered testing a service class. But how do you test the UI?
MinkSaturday, 29 October 11Part of the Behat Project.A abstraction over a number of different browser testing tools.
Mink                            Goutte           Sahi                                 Zombie.jsSaturday, 29 October 11Gout...
Extend Mink Context                          Includes predefined steps                   Use Bundled steps to create       ...
Back To:                 My Amazing PHP Conference                         Website!Saturday, 29 October 11We need a UI to ...
Example                          Using Minks Bundled Steps  Scenario: View all conferences on the homepage      Given ther...
Link                                FeatureContext.php                                        to                          ...
class FeatureContext                      public function __construct(array $parameters)                      {           ...
Demo Three                          A Behat UI Test (Using Mink + Goutte)Saturday, 29 October 11This is ok - but ties the ...
Exercise Two                          Testing the UI with Mink and                          the headless browser Goutte.Sa...
Exercise Two                          Open the PDF in the sources folder.                             Read through Section...
Abstracting your scenario Scenario: View all conferences on the homepage     Given there is conference data in the databas...
Mink Feature Context class UIContext extends BehatMinkBehatContext MinkContext {     protected $pageList = array(         ...
/**              * @When /^I am on the "([^"]*)" page$/              */             public function iAmOnThePage($pageName...
/**              * @Then /^I should see "([^"]*)" in the "([^"]*)"$/              */             public function iShouldSe...
Demo Four              A Behat UI Test (Using Mink + Goutte)         UI implementation abstracted away from Gherkin.Saturd...
Exercise Three          Abstracting the UI implementation away from the                              Gherkin.Saturday, 29 ...
Exercise Three                          Open the PDF in the sources folder.                            Read through Sectio...
Javascript Testing with                                   SahiSaturday, 29 October 11
Back To:                 My Amazing PHP Conference                         Website!Saturday, 29 October 11We need a UI to ...
Example          @javascript          Scenario: Use autocomplete functionality to          complete a input field         ...
Great Reuse             @javascript             Scenario: Use autocomplete functionality to             complete a input f...
// In the UIContext class                          /**                             * @Given /^I wait for the suggestion bo...
Demo Five                              UI Testing With SahiSaturday, 29 October 11This is ok - but ties the feature to you...
Saturday, 29 October 11
Exercise Four                          UI Testing With SahiSaturday, 29 October 11
Exercise Four                          Open the PDF in the sources folder.                             Read through Sectio...
DataSaturday, 29 October 11How do you supply your data?
SQL FixtureSaturday, 29 October 11Can be difficult to maintain.Hides Data in a fixture NOT in your scenarios.
PhabricSaturday, 29 October 11
Gherkin Tables    Scenario:        Given The         following events   exist        | Name |          Date               ...
Demo Five                          Dynamic fixture creation with Phabric.Saturday, 29 October 11This is ok - but ties the f...
Case Study:                          Behat at Sky BetSaturday, 29 October 11Whats the problem we are solving.Three element...
The ProblemSaturday, 29 October 11Whats the problem we are solving.Three elements of the team.Delivering the product first ...
The Business          AnalystSaturday, 29 October 11BA / Product owner has all the knowledgeWrite stories
The TesterSaturday, 29 October 11Testers test implementation vs the story
The                                  DeveloperSaturday, 29 October 11Dev - write the codeAutomate the process of testing i...
The ProblemSaturday, 29 October 11Whats the problem we are solving.Three elements of the team.Delivering the product first ...
BDD - Skybet Workflow                                BA’s Write Stories                              Testers Write Gherkin ...
BDD - Skybet Workflow                                  Less Defects                          Fewer times through this cycle...
The Place Of Acceptance &                        Integration TestsSaturday, 29 October 11Whats the problem we are solving....
Balance.Saturday, 29 October 11Jason HugginsThe place of acceptance and integration tests
A whole world of trouble.Saturday, 29 October 11Takes a long time to run,Harder to implement, when they break you have to ...
joind.in                          http://joind.in/talk/view/4328Saturday, 29 October 11
Questions?Saturday, 29 October 11
Links     Behat Github Page: https://github.com/Behat/Behat        Mink On Github: https://github.com/Behat/Mink          ...
