Drupal Recipes:
Building Image Galleries
     Covering Flickr, jQuery, and
       Drupal best practices


    Presented by...
Start with a plan, and make
   Drupal work for you.
(don’t limit your imagination to what Drupal
  and existing modules do...
Planning

Remember that most*
people don’t think like a
relational database



  *Disclaimer: I recently used database con...
My Plan
User Experience:
  • Show random image thumbnails on the
    sidebar
  • Show a sliding image viewer on the right
...
Looking for Modules
• drupal.org
• drupalmodules.com
• CVS checkout of all contributions
  (grep search for keywords)
• As...
Implementation

There are essentially two types of Drupal
modules:
1. Reusable “ingredients”
2. Complete solutions
(there’...
My Approach
Use complete solutions if appropriate, BUT:
• DON’T spend too long finding them
• DON’T spend too long forcing ...
My Approach
Use common “ingredients” to build what you need.
Building the site

              start here



Input    Storage           Retrieval   Output
Storage
Preferred: CCK + Imagefield
Not-recommended:
  • Attach multiple image files directly to a node
  • Use a non-CCK no...
Storage
New content type: Image
Data Input

      • Millions of people
        already use it
      • Easy to upload
        photos
Why import to Drupal?

         • Theming flexibility
         • Integration
         • Security
Flickr Import
Plan:
•  Automatically download new photos from
   Flickr
•  Create Drupal nodes with attached images
•  Imp...
The closest I could find...

• Activity Stream
• FlickrRippr
• Emfield/Emfield Import
• Flickr module
LE
      U
     D
     O
    M
EW




         Flickr API Module
N




     • Loads phpFlickr
     • Stores the Flickr API...
Flickr API Module
LE
      U
     D
     O
    M
EW




         Flickr Sync Module
N




     Downloads new Flickr photos
     to new Drupa...
Flickr Sync Module
Settings page:
 • Configure the
   content fields to use
 • Specify batch
   importing settings
Flickr Sync Module

Every user has
Flickr sync settings
in their account
settings
Flickr Sync Module
      Performing an import manually
(cron will keep things up-to-date, but the manual
   process is nic...
Thumbnails with a lightbox
Lightboxes

• Popular replacement for popup windows
• Comparison of “lightbox” type modules:
  http://www.drupal.org/node/...
Lightboxes

Lightboxes typically work using the “rel”
attribute of a link:

<a href=quot;images/image-1.jpgquot;
rel=quot;...
Using the Views UI

     Create a block

     Filter for image nodes
Lightboxes
                         Theming the view

function phptemplate_views_view_imagelist($view, $type, $nodes) {
  ...
No more hunting for a module to
 do exactly what you want -- with
just a little view theming code the
      possibilities ...
Building an image slider
LE
      U
     D
     O
    M
EW
N




        Image Slider Module
         Concept based on jQuery slideViewer 1.1
Building a new module can
 be easier than building a
      complex theme
Building the image slider

• Setup a new View (just like before)
• Call the View from your module:
  $view = views_get_vie...
Theming output
<div class=quot;imagesliderquot; style=quot;width:   500px; height: 300pxquot;>
  <ul style=quot;width: 150...
Image slider CSS
div.imageslider {
  overflow: hidden;
  position: relative;
}

div.imageslider ul {        Change left
  ...
Image slider JavaScript
• Get the image slider container
• Find out how many images there are
• Get the width of the image...
Add module settings

            Easy to add,
            easy to change
Tips for using CSS and
JavaScript with Drupal
CSS and JavaScript


  Load only where needed
Adding JavaScript


JavaScript should be unobtrusive
“Auto Attach”
      Runs your JavaScript if JavaScript is
      available and when everything is ready.


// Global Killsw...
Use Drupal.settings
          Drupal can output settings that can
           be easily read in your JavaScript:
In PHP:
dr...
Adding JavaScript


Follow good naming conventions
Naming Conventions
Typically lower/upper , but just be consistent
with Drupal and jQuery, or whatever JS
libraries you wor...
Adding JavaScript


  Use proper namespacing
JavaScript Namespacing

What’s wrong with this?


for (i = 0; i < 5; i++) {

    // do something

}
JavaScript Namespacing

Using undefined
variables clutters
the global
namespace!
JavaScript Namespacing

Define every variable!


for (var i = 0; i < 5; i++) {

    // do something

}
JavaScript Namespacing
Namespace everything. Even JavaScript
functions will overwrite each other:

function test() {
  ale...
JavaScript Namespacing

An example of proper namespacing:


  var Drupal = Drupal || {};

  Drupal.extend = function(obj) ...
Adding JavaScript


 Learn to understand scope
Understanding Scope
       Simple Example of jQuery scope:

function autoAttach() {
  var settings = {
     foo: 'bar'
  }...
Understanding Scope
    Using a separate function for handlers
function autoAttach() {
  var settings = {
     foo: 'bar'
...
Understanding Scope
     Passing additional variables with ‘call’
function autoAttach() {
  var settings = {
     foo: 'ba...
Tools
• Firefox with Firebug
• Aptana Studio
• Opera Developer Tools
• IE Developer Toolbar
• Windows (for testing)
New Drupal.org Releases

 • http://drupal.org/project/flickrapi
 • http://drupal.org/project/flickrsync
 • http://drupal.org...
