Grokking the REST Architectural Style Grokking the REST Architectural Style Presentation Transcript

  • Grokking the REST Architectural Style Ben Ramsey ■ Dutch PHP Conference ■ 12 June 2009
  • Yes. I am this guy.
  • Roatan Beach - Perfect Day, by Janusz Leszczynski REST
  • Is it about pretty URLs? Tom Coates, by Patrick Lauke
  • #webdevgangsign How about XML over HTTP? Web Developer Gang Sign, by Josh Lewis
  • Any web service that’s not SOAP? A Bar of Ivory Soap, by iirraa
  • Representational State Transfer Restful Summer, by Clear Inner Vision
  • Public Domain, from Wikimedia Commons Theory of REST
  • REST defines a style by which a resource’s state may be transferred using a representation of that resource.
  • Client-server Separated, by Hansol Lee
  • Stateless Stateless by Koesmanto Bong
  • Cache Cache County, Utah by J. Stephen Conn
  • 1.Identification of resources 2.Representation of resources 3.Linked resources 4.Resource metadata Uniform Interface used to interface, by Tom Hensel
  • Layered Sedimentary Layers by Mark Thurman
  • jeremyʼs tie by Gitchel Code-on-demand
  • RESTful Benefits Improved response time & reduced server load Improves server scalability Requires less client-side software Depends less on vendor software No need for resource discovery Better long-term compatibility & evolvability than RPC Sand Banks Sunset, by Clear Inner Vision
  • A Real-World Analogy Money!, by Tracy Olson
  • RESTful Practice Public Domain, from Wikimedia Commons
  • “[REST] is intended to evoke an image of how a well-designed Web application behaves: a network of web pages (a virtual state-machine), where the user progresses through an application by selecting links (state transitions), resulting in the next page (representing the next state of the application) being transferred to the user and rendered for their use.” — Roy Fielding Drip Drops and the Spider Web, by Mike Bitzenhofer
  • Hypertext Transfer Protocol URIs provide unique addresses Constrained interface with methods and content types Transactions are atomic Built-in support for layering Provides for cache control #110 Hypertext Transfer Protocol, by maako
  • HTTP Interface Methods Cut & Paste GET Copy PUT Paste Over POST Paste After DELETE Cut #110 Hypertext Transfer Protocol, by maako
  • Content Types HTTP supports content types through the Content-Type header A single resource can be transferred in various content types Content negotiation used to tell the server what type to return to the client REST community doesn’t care for content negotiation #110 Hypertext Transfer Protocol, by maako
  • Lifecycle of a Resource 1 POST /content HTTP/1.1 Host: example.org Content-Type: application/xml 2 HTTP/1.x 201 Created Date: Thu, 13 November 2008 16:43:56 GMT Location: /content/1234 #110 Hypertext Transfer Protocol, by maako
  • Lifecycle of a Resource 3 GET /content/1234 HTTP/1.1 Host: example.org 4 HTTP/1.x 200 OK Date: Thu, 13 November 2008 16:44:13 GMT Content-Type: application/xml #110 Hypertext Transfer Protocol, by maako
  • Lifecycle of a Resource 5 PUT /content/1234 HTTP/1.1 Host: example.org Content-Type: application/xml 6 HTTP/1.x 200 OK Date: Thu, 13 November 2008 16:48:26 GMT Content-Type: application/xml #110 Hypertext Transfer Protocol, by maako
  • Lifecycle of a Resource 7 DELETE /content/1234 HTTP/1.1 Host: example.org 8 HTTP/1.x 204 No Content Date: Thu, 13 November 2008 16:50:47 GMT #110 Hypertext Transfer Protocol, by maako
  • Resource-oriented Architecture 1. Represent itself to the client 2. Transition from one state to the next 3. Destroy itself Additionally, the system knows how to create a resource. Where I Teach, by Todd Ehlers
  • Resource-oriented Architecture Resources are addressable Resources have no state Resources are connected Resources share the same interface Where I Teach, by Todd Ehlers
  • Resource-oriented Architecture Query string parameters appropriate in some cases Pragmatic use of URIs instead of using HTTP headers RPC-style APIs are avoided Representation should have links URI templates specify URI families Where I Teach, by Todd Ehlers
  • Resource-oriented Architecture Should expose many URIs Session cookies are not RESTful Combined resources are RESTful only if represented as a URI URIs should facilitate “cut & paste” Where I Teach, by Todd Ehlers
  • Atom A resource-oriented protocol for publishing documents that sits on top of HTTP Molecule display, by Christian Guthier
  • Atom Entry Document application/atom+xml;type=entry Feed (Collection) Document application/atom+xml;type=feed Category Document application/atomcat+xml Service Document application/atomsvc+xml Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 1 GET /index.atom HTTP/1.1 Host: example.org 2 HTTP/1.x 200 OK Date: Thu, 13 November 2008 17:13:14 GMT Content-Type: application/atomsvc+xml Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 3 GET /archives.atom HTTP/1.1 Host: example.org 4 HTTP/1.x 200 OK Date: Thu, 13 November 2008 17:13:46 GMT Content-Type: application/atom+xml;type=feed Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 5 GET /categories.atom HTTP/1.1 Host: example.org 6 HTTP/1.x 200 OK Date: Thu, 13 November 2008 17:13:48 GMT Content-Type: application/atomcat+xml Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 7 POST /archives.atom HTTP/1.1 Host: example.org Content-Type: application/atom+xml;type=entry 8 HTTP/1.x 201 Created Date: Thu, 13 November 2008 17:16:32 GMT Location: /archives/1234.atom Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 9 GET /archives/1234.atom HTTP/1.1 Host: example.org 10 HTTP/1.x 200 OK Date: Thu, 13 November 2008 17:16:36 GMT Content-Type: application/atom+xml;type=entry Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 11 PUT /archives/1234.atom HTTP/1.1 Host: example.org Content-Type: application/atom+xml;type=entry 12 HTTP/1.x 200 OK Date: Thu, 13 November 2008 17:23:12 GMT Content-Type: application/atom+xml;type=entry Molecule display, by Christian Guthier
  • Atom Resource Lifecycle 13 DELETE /archives/1234.atom HTTP/1.1 Host: example.org 14 HTTP/1.x 204 No Content Date: Thu, 13 November 2008 19:34:29 GMT Molecule display, by Christian Guthier
  • Resource-oriented Design 1. Determine your resources User Content /users /content /users/{username} /content/{ID} Before we had CAD, we had Lead!, by Wendell
  • Resource-oriented Design 2. Decide the methods for each resource /users /users/{username} /content /content/{ID} GET GET GET GET POST PUT POST PUT DELETE DELETE Before we had CAD, we had Lead!, by Wendell
  • Resource-oriented Design 3. Link your resources Users own content Each user owns multiple content items Each content item has one owner Before we had CAD, we had Lead!, by Wendell
  • Resource-oriented Design 4. Determine your data schemas User Content id id username owner firstname title lastname file/content Before we had CAD, we had Lead!, by Wendell
  • Resource-oriented Design 5. Choose your content type(s) Before we had CAD, we had Lead!, by Wendell
  • In conclusion... Conclusion, by Mark Cummins
  • Questions? benramsey.com
  • Grokking the REST Architectural Style Copyright © Ben Ramsey. Some rights reserved. This work is licensed under a Creative Commons Attribution-Noncommercial-No Derivative Works 3.0 United States License. For uses not covered under this license, please contact the author.
