NoSQL overviewImplementation free  Benoit Perroud  21. January 2011, 01. March 2011
Disclaimer     Any views or opinions presented in this presentation are    solely those of the author and do not necessari...
Outline    •   Introduction    •   Scalability and Availability    •   Difficulties to scale    •   CAP Theorem    •   NoS...
Introduction4
NoSQL Term    • Mandatory name disambiguation :          NoSQL stands for Not Only SQL.    • The term NoSQL is more or les...
Wikipedia Definition    • [Wikipedia] NoSQL is a term used to designate database      management systems that differ from ...
Tag Cloud7
Why NoSQL ?    • Is there really a problem with SQL and RDBMS ?         No there isnt !         SQL is powerful, ACID (ato...
Scalability and Availability9
Scalability definition     • [Wikipedia] Scalability is a desirable property of a       system, a network, or a process, w...
Availability definition      • [Wikipedia] Availability refers to the ability of the users to access        and use the sy...
Difficulties to Scale12
RDBMS Scalability     • RDBMS are hard to scale. Hard should be understood       as costly          RDBMS licenses, hardwa...
Hardware Scalability     • Commodity hardware and appliances are I/O bound        • But network throughput is cheaper than...
Pioneers in Scaling The Big     • Google : huge amount of data (hundreds of petabytes, do not       fit on a single applia...
CAP Theorem16
Remind of CAP theorem     • Consistency : all nodes see the same data at the same       time     • Availability : node fai...
NoSQL trade-offs     • NoSQL datastores have typically done other trade-offs       than RDBMS to the CAP theorem        • ...
NoSQL Goals19
NoSQL promises     • NoSQL finality is to achieve (horizontal) scalability and       high availability.        • Business ...
NoSQL Taxonomy21
Taxonomy       NoSQL most common types are :     • Document store        • store document which structure can be explored....
Classification23     Picture from http://blog.nahurst.com/visual-guide-to-nosql-systems
Concepts and Patterns24
Implementation side : Consistent Hashing     • [Wikipedia] Consistent hashing is a scheme that       provides hash table f...
Implementation side : Bloom Filter     • [Wikipedia] Bloom filter is a space-efficient probabilistic       data structure ...
Implementation side : Quorum     • [Wikipedia] A quorum is the minimum number of votes       that a distributed transactio...
Implementation side : Vector Clocks     • [Wikipedia] Vector Clocks is an algorithm for generating       a partial orderin...
Implementation side : other Common Concepts     • Replication        • Multi-master (Gossip, agents, P2P)        • Master-...
User side : Map Reduce     • [Wikipedia] MapReduce is a framework for processing       huge datasets on certain kinds of d...
User side : Inverted Indexes     • [Wikipedia] An inverted index is an index data structure       storing a mapping from c...
User side : other Patterns     • Idempotent updates        • Repeating the update twice do not lead to inconsistent data. ...
Existing Implementations33
Non exhaustive list of Existing Implementations     •   Google BigTable, Megastore   •   CouchDB,     •   Amazon Dynamo,  ...
NoSQL in the Real World35
Real World Example     • Facebook new messaging system        • Based on Hbase (consistency model simplier than Cassandra)...
Real World Example (2)     • Digg, Last.fm, NYT, Guardian, Yahoo, Flickr, NetFlix,       Adobe, Mozilla, Github, Linkedin,...
Conclusion38
Conclusion     • NoSQL is not a general purpose datastore !        • Eventually consistent model can be tricky, and can re...
Thanks for listening     Questions ?       Benoit Perroud       bperroud@verisign.com       @killerwhile on Twitter40
Upcoming SlideShare
Loading in...5
×

NoSQL overview implementation free

5,812

Published on

NoSQL overview, concepts and patterns, cap theorem, availability and scalability.

Published in: Technology

Transcript of "NoSQL overview implementation free"

  1. 1. NoSQL overviewImplementation free Benoit Perroud 21. January 2011, 01. March 2011
  2. 2. Disclaimer Any views or opinions presented in this presentation are solely those of the author and do not necessarily represent those of Verisign.2
  3. 3. Outline • Introduction • Scalability and Availability • Difficulties to scale • CAP Theorem • NoSQL Goals • NoSQL Taxonomy • Concepts and Patterns • Existing implementations • NoSQL in the Real World • Conclusion3
  4. 4. Introduction4
  5. 5. NoSQL Term • Mandatory name disambiguation : NoSQL stands for Not Only SQL. • The term NoSQL is more or less attributed to Eric Evans, a Rackspace employee, who used it in early 2009 when Johan Oskarsson, a Last.fm employee, wanted to organize an event to discuss open-source distributed databases.5
  6. 6. Wikipedia Definition • [Wikipedia] NoSQL is a term used to designate database management systems that differ from classic relational database management systems (RDBMS) in some way. These data stores may not require fixed table schemas, usually avoid join operations, do not attempt to provide ACID (atomicity, consistency, isolation, durability) properties and typically scale horizontally.6
  7. 7. Tag Cloud7
  8. 8. Why NoSQL ? • Is there really a problem with SQL and RDBMS ? No there isnt ! SQL is powerful, ACID (atomicity, consistency, isolation, durability) properties are well-established, developers and DBAs have dominated it. • So why the hell need we NoSQL ? • What was the motivations of Google and Amazon to invest huge amount in research around NoSQL ? • Why “social sites” are so hard to scale ?8
  9. 9. Scalability and Availability9
  10. 10. Scalability definition • [Wikipedia] Scalability is a desirable property of a system, a network, or a process, which indicates its ability to either handle growing amounts of work in a graceful manner or to be readily enlarged. In summary : handle load and peaks. • Scalability in two dimensions : • Scale up → scale vertically (increase RAM in an existing node) • Scale out → scale horizontally (add a node to the cluster)10
  11. 11. Availability definition • [Wikipedia] Availability refers to the ability of the users to access and use the system. If a user cannot access the system, it is said to be unavailable. Generally, the term downtime is used to refer to periods when a system is unavailable. In summary : minimize downtime. Availability % Downtime per year Downtime per month Downtime per week 90% ("one nine") 36.5 days 72 hours 16.8 hours 95% 18.25 days 36 hours 8.4 hours 99% ("two nines") 3.65 days 7.20 hours 1.68 hours 99.9% ("three nines") 8.76 hours 43.2 minutes 10.1 minutes 99.99% ("four nines") 52.56 minutes 4.32 minutes 1.01 minutes 99.999% ("five nines") 5.26 minutes 25.9 seconds 6.05 seconds 99.9999% ("six nines") 31.5 seconds 2.59 seconds 0.605 seconds11
  12. 12. Difficulties to Scale12
  13. 13. RDBMS Scalability • RDBMS are hard to scale. Hard should be understood as costly RDBMS licenses, hardware, DBAs and operational costs grow non linearly with the load. RDBMS have either : • single point of failure (SpoF) → the master DB • or replication latency → distributed transactions : two-phase commit, paxos algorithm.13
  14. 14. Hardware Scalability • Commodity hardware and appliances are I/O bound • But network throughput is cheaper than hard disk throughput. • Hard disks is (was?) the main bottleneck in todays computing. • Random access have a high latency (disk seek) • Throughput have increased, but not proportionally with the storage → Distributing data across a network of small computers (and applying the data locality concept) scale better (cheaper) than a huge appliance.14
  15. 15. Pioneers in Scaling The Big • Google : huge amount of data (hundreds of petabytes, do not fit on a single appliance) • need to be partitioned MTBF is proportional to number of machines. → BigTable. • Amazon : high availability (99.999%) • need to have redundancy and write scalability → Dynamo • Facebook, Twitter, "social sites” • no cluster of data to be partitioned, • long tail (old data still time to time accessed), • lots of users connected in the same time, • user specific content (predictions hard to achieve, few static pages)15
  16. 16. CAP Theorem16
  17. 17. Remind of CAP theorem • Consistency : all nodes see the same data at the same time • Availability : node failures do not prevent survivors from continuing to operate • Partition Tolerance : the system continues to operate despite arbitrary message loss According to the theorem, a distributed system can satisfy any two of these guarantees at the same time, but not all three.17
  18. 18. NoSQL trade-offs • NoSQL datastores have typically done other trade-offs than RDBMS to the CAP theorem • Most of them gave up the “C” of the theorem, giving up the ACID properties in the same way. • NoSQL datastores also have a more simpler data access pattern • value = get(key) • put(key, value) • remove(key)18
  19. 19. NoSQL Goals19
  20. 20. NoSQL promises • NoSQL finality is to achieve (horizontal) scalability and high availability. • Business goal : Keep cost growing proportionally with the load (tight provisioning). • Operational goal : • Scale the system by simply adding node (or removing). • The system runs on commodity hardware.20
  21. 21. NoSQL Taxonomy21
  22. 22. Taxonomy NoSQL most common types are : • Document store • store document which structure can be explored. • Key/value store • simple hash map data access pattern. • Column oriented store • Something between simple key/value and complex document store • Graph database • store node and edges, walk-through data access • Object database22
  23. 23. Classification23 Picture from http://blog.nahurst.com/visual-guide-to-nosql-systems
  24. 24. Concepts and Patterns24
  25. 25. Implementation side : Consistent Hashing • [Wikipedia] Consistent hashing is a scheme that provides hash table functionality in a way that the addition or removal of one slot does not significantly change the mapping of keys to slots.25 Picture from http://www.lexemetech.com/2007/11/consistent-hashing.html
  26. 26. Implementation side : Bloom Filter • [Wikipedia] Bloom filter is a space-efficient probabilistic data structure that is used to test whether an element is a member of a set.26 Picture from http://en.wikipedia.org/wiki/File:Bloom_filter.svg
  27. 27. Implementation side : Quorum • [Wikipedia] A quorum is the minimum number of votes that a distributed transaction has to obtain in order to be allowed to perform an operation in a distributed system. A quorum-based technique is implemented to enforce consistent operation in a distributed system. • Quorum : R + W > N N : number of replica, R : number of node read, W : number of node written. • R = 1, W = N • R = N, W = 1 • R = N/2, W = N/2 (+1 if N is even)27
  28. 28. Implementation side : Vector Clocks • [Wikipedia] Vector Clocks is an algorithm for generating a partial ordering of events in a distributed system and detecting causality violations.28 Picture from http://en.wikipedia.org/wiki/File:Vector_Clock.svg
  29. 29. Implementation side : other Common Concepts • Replication • Multi-master (Gossip, agents, P2P) • Master-slave (+failover) • Merkle Tree • The main use of hash trees is to make sure that data blocks received from other peers in a peer-to-peer network are received undamaged and unaltered • Multiversion concurrency control • MVCC is a concurrency control method commonly used by database management systems to provide concurrent access to the database and in programming languages to implement transactional memory. • SEDA • Staged Event-Driven Architecture • LMT (Log Merge Tree) • Efficient replacement of B-Tree that require less disk seeks.29
  30. 30. User side : Map Reduce • [Wikipedia] MapReduce is a framework for processing huge datasets on certain kinds of distributable problems using a large number of computers (nodes). It is inspired by the map and reduce functions commonly used in functional programming.30 Picture from http://code.google.com/edu/parallel/mapreduce-tutorial.html
  31. 31. User side : Inverted Indexes • [Wikipedia] An inverted index is an index data structure storing a mapping from content, such as words or numbers, to its locations in a database file, or in a document or a set of documents. The purpose of an inverted index is to allow fast full text searches, at a cost of increased processing when a document is added to the database (data denormalization).31 Picture from http://developer.apple.com/library/mac/
  32. 32. User side : other Patterns • Idempotent updates • Repeating the update twice do not lead to inconsistent data. • Offline (asynchronous) processing • Push on change (vs. pull on demand), batches • SOA and services isolation • Service failure resilience. Product is a mash-up of back-end services. • Schemaless (ColumnFamily-based data model) • Schema update is no more required • Data locality • Processing is sent to data instead of data sent do workers.32
  33. 33. Existing Implementations33
  34. 34. Non exhaustive list of Existing Implementations • Google BigTable, Megastore • CouchDB, • Amazon Dynamo, • MongoDB, • Apache Hbase, • Tokyo Cabinet, • Apache Cassandra, • SimpleDB, • Riak, • Redis, • Project Voldemort, • Memcached, • Flockdb, • Infinispan, • Neo4j, • Scalaris, • Hypertable, • Terrastore, • Jackrabbit, • Mysql HandlerSocket, • Solr, ElsaticSearch, ... • Almost a new project every week ...34
  35. 35. NoSQL in the Real World35
  36. 36. Real World Example • Facebook new messaging system • Based on Hbase (consistency model simplier than Cassandra) • Amazon shopping cart • Based on Dynamo, never delete a row. Only add delta (+1, +2, -1) in the cart. • Twitter • Use Cassandra for real time analytics • Google Megastore • ACID within partitions, lower consistency across partitions • Synchronous replication with Paxos algorithm36
  37. 37. Real World Example (2) • Digg, Last.fm, NYT, Guardian, Yahoo, Flickr, NetFlix, Adobe, Mozilla, Github, Linkedin, StumbleUpon, ... • MapReduce usage is increasing daily • Google and Amazon have sat their domination in being the first to masterize big data. • Can your business jump into the NoSQL wave ?37
  38. 38. Conclusion38
  39. 39. Conclusion • NoSQL is not a general purpose datastore ! • Eventually consistent model can be tricky, and can reserve nasty surprises if not used carefully. • MapReduce search job have high latency • SQL and NoSQL are complementary • Knowing both allow to put the right technology to the right place. • NoSQL has challenged RDBMS supremacy • New ideas for RDBMS are emerging • See HandlerSocket, a mysql NoSQL plugin.39
  40. 40. Thanks for listening Questions ? Benoit Perroud bperroud@verisign.com @killerwhile on Twitter40
