Cassandra troubleshooting:
    out of the shadows

      Benjamin Black, b@b3k.us
Introducing: This Guy
The Allegory of the Cave
Most people start
troubleshooting problems
interpreting shadows on the
wall.
Common shadows.
Paths out of the cave.
Combination of
basic system tools
&
nodetool/JMX
I’m using RP.
My ring is very unbalanced.
I’m using RP.
My ring is very unbalanced.




                   WTF?
nodetool ring
Address   Status   Load       Range                  Ring
                      148873535527910577765226390751398592511
10...
Address   Status   Load       Range                  Ring
                      148873535527910577765226390751398592511
10...
Autobootstrap
+
Automatic token assignment
Automatic token algorithm:

Assign a token that will give me
half the range of
the most loaded node.
32
16 16
8 8 16
8888
44888
444488
Address   Status   Load       Range                  Ring
                      148873535527910577765226390751398592511
10...
nodetool move
+
Manual token assignment
0-(2**127 - 1)
def tokens(nodes)
 0.upto(nodes - 1) do |n|
  p (n * (2**127 - 1) / nodes)
 end
end
=> tokens(6)
0
283568639100782052886145506193140
17621
567137278201564105772291012386280
35242
850705917302346158658436518...
YES:

This means you need to change tokens on
most of the nodes in your cluster whenever
you add a node.
Writes are fast.
Reads keep getting slower.
Writes are fast.
Reads keep getting slower.




                   WTF?
iostat -x
look at %util
nodetool tpstats
Pool Name                    Active   Pending      Completed
STREAM-STAGE                      0         0              0
...
Pool Name                    Active   Pending      Completed
STREAM-STAGE                      0         0              0
...
Pool Name                    Active   Pending      Completed
STREAM-STAGE                      0         0              0
...
Pool Name                    Active   Pending      Completed
STREAM-STAGE                      0         0              0
...
YOU ARE OUT OF
DISK BANDWIDTH
You can:
Throttle reads at clients
Adjust memtable settings
    (size/ops/time)
Less frequent memtable flush

 Less frequent compaction

Less disk bandwidth demand
Add more nodes
Add more spindles per node
Switch to SSDs
I inserted a bunch of data.
Now my nodes are flapping.
I inserted a bunch of data.
Now my nodes are flapping.




                  WTF?
iostat -x
look at %util
vmstat
look at swap
INFO 13:27:35,309
DiskAccessMode 'auto' determined to be mmap,
indexAccessMode is mmap
mmap() in Cassandra
consumes up to 2GB.
mmap() in Cassandra
consumes up to 2GB.
Per segment.
NOT tracked as JVM heap.




           *See: https://issues.apache.org/jira/browse/CASSANDRA-1214
NOT tracked as JVM heap.
JVM heap not locked in
memory.

           *See: https://issues.apache.org/jira/browse/CASSANDRA-...
When your data set exceeds
memory,
this is likely.
Swapping can delay gossip
long enough to cause a
node to be marked down.
<DiskAccessMode>mmap_index_only</
DiskAccessMode>
or
disk_access_mode: mmap_index_only
On Linux: swappiness=0
INFO 13:27:35,309
DiskAccessMode isstandard,
indexAccessMode is mmap
Most people start
troubleshooting problems
interpreting shadows on the
wall.
You can now see the path
and the sunlight outside.
YOU CAN HELP!
What things have confused
you?
What problems have you
solved?
What tools have you used to
solve them?
GET INVOLVED!
http://wiki.apache.org/cassandra
#cassandra on freenode
