Doctrine and NoSQL

  1. 1. Doctrine NoSQLBenjamin Eberlei (SimpleThings GmbH)
  2. 2. About me Benjamin Eberlei Working at SimpleThings GmbH http://www.simplethings.de Open Source contributor Doctrine2, Symfony2 (Zeta Components, PHPUnit, ...) Twitter @beberlei Blog http://www.whitewashing.de
  3. 3. The Doctrine Projectwww.doctrine-project.orgThe Doctrine Project is the home of a selectedset of PHP libraries primarily focused onproviding persistence services and relatedfunctionality.
  4. 4. Doctrine Subprojects DBAL and ORM Document Mapper (MongoDB, CouchDB, PHPCR) Annotations XML What is next?
  5. 5. Doctrine Philosophy Separate Persistence and Model
  6. 6. Doctrine Philosophy Similar look and feel
  7. 7. Doctrine Philosophy Embrace Differences
  8. 8. Why NoSQL Mapper?Schemaless storage allows: Arbitrary associations Embedded objects Lists and Associative ArraysNo duplicate schema-maintenance!
  9. 9. Doctrine NoSQL History MongoDB Mapper early 2010 (OpenSky) CouchDB Mapper started in October 2010 (Liip) PHPCR ODM started in early 2011 (Liip) APIs heavily inspired from ORM
  10. 10. SQL and NoSQL Similarities Extracted common persistence interfaces Covering roughly 10-20% of the use-cases Simple Finder Methods Insert/Update/Delete Metadata API Support for Annotations/XML/YAML/PHP Mapping
  11. 11. Persistence Interfaces<?phpinterface ObjectManager{ function find($class, $id); function getReference($class, $id); function persist($object); function remove($object); function flush(); function getClassMetadata($class); function getRepository($class);}
  12. 12. Persistence Interfaces<?phpinterface ObjectRepository{ function find($id); function findAll(); function findBy(array $criteria, $orderBy = null, $limit = null, $offset = null ) function findOneBy(array $criteria);}
  13. 13. Sample Document<?php/** @Document */class Message{ /** @Id */ public $id; /** @Field(type="string") */ public $text;}$message = new Message();$message->setText("Hello World!");
  14. 14. NoSQL benefits<?php/** @Document */class Product{ /** other fields */ /** @Field(type="array") */ public $attributes; /** @Field(type="array") */ public $translations;}$product->attributes["isbn"] = "A-B-C-D";$product->translations["de"]["name"] = "Ein Produkt";
  15. 15. Working with Objects 1Creating a new document:<?php/** @var $dm DocumentManager */$message = new Message();$message->setText("I am new!");$dm->persist($message);$dm->flush();echo "ID: " . $message->getId();
  16. 16. Working with Objects 2Find and update document:<?php/** @var $dm DocumentManager */$message = $dm->find("Message", 1);$message->setText("New Message");$dm->flush();
  17. 17. Working with Objects 3Find and remove documents:<?php/** @var $dm DocumentManager */$repository = $dm->getRepository("User");$criteria = array("status" => "inactive");$users = $repository->findBy($criteria);foreach ($users AS $user) { $dm->remove($user);}$dm->flush();
  18. 18. Persistence API Use-Cases Focus on "in memory" object workflows Specialized reusable Modules Symfony2: User Management Comment Admin Generators lichess.org
  19. 19. Associations in NoSQLPros Embedded Documents References between arbitrary typesCons No referential integrity No support for transactions
  20. 20. Association Mappings<?php/** @Document */class Blog{ /** @ReferenceMany */ private $articles; /** @ReferenceOne(targetDocument="User") */ private $owner;}
  21. 21. Association keys<?php$id = "1";$articleSlug = "hello-world";$blog = $dm->find("Blog", $id);$blog->articles[$articleSlug]->getHeadline();
  22. 22. Embedded Mappings<?php/** @Document */class User{ /** @EmbedMany */ private $phonenumbers; /** @EmbedOne(targetDocument="Address") */ private $address;}
  23. 23. CouchDB and Doctrine JSON Datastorage HTTP/REST API MVCC, eventually consistent (Conflicts) Replication Attachments Views and Map/Reduce in Javascript CouchDB Lucene Doctrine CouchDB 1.0 Alpha 1
  24. 24. JSON Document{ "_id": "716104ac33c797b12d50c0a6483f1661", "_rev": "1-32db404b78f130fd8f7575905859e19b", "doctrine_metadata": { "type": "MyProject.Document.Message", "associations": { "user": "055fe8a3ab06c3998d27b6d99f5a9bdd" } }, "message": "I am a message"}
  25. 25. Document VersionImplement Optimistic-Locking<?phpclass Article{ /** @Version */ private $version;}$article = $dm->find( "Article", $id, $expectedVersion);
  26. 26. Attachments CouchDB supports Attachments to documents Doctrine converts into Attachment object Lazy Load binary data from the server Stream support planned<?phpclass Article{ /** @Attachments */ public $attachments = array();}
  27. 27. Attachments 2<?phpuse DoctrineCouchDBAttachment;$article = $dm->find("Article", 1);$data = $article->attachments["teaser.jpg"]->getContent();$a = Attachment::createFromBase64data($data, "image/jpg");$article->attachments["author.jpg"] = $a;$dm->flush();
  28. 28. ViewsDoctrine CouchDB maps filesystem to design document:application/ couchdb/ views/ username/ map.js reduce.jsUse javascript syntax highlighting in your IDE/Editor.
  29. 29. Views 2<?phpuse DoctrineCouchDBViewFileFolderDesignDocument;$path = "/path/application/couchdb";$designDoc = new FileFolderDesignDocument($path);/* @doc $couch CouchClient */$docName = "myapp";$couch->createDesignDoc($docName, $designDoc);
  30. 30. Query Views<?php/* @var $dm DocumentManager */$query = $dm->createQuery("myapp", "username");$result = $query->setStartKey("b") ->setEndKey("c") ->setLimit(10) ->setSkip(10) ->includeDocs(true) ->execute();Using include docs creates PHP instances for you.
  31. 31. Lucene QueriesSupport for the CouchDB Lucene extension:<?php$query = $dm->createLuceneQuery("lucenedoc", "users");$result = $query->setQuery("John Galt" OR "John Wayne") ->setLimit(10) ->setSkip(10) ->includeDocs(true) ->execute();
  32. 32. MongoDB and Doctrine Indexing and on the fly queries Very fast In-Place Updates² GridFS, Geolocation Sharding Doctrine MongoDB 1.0 Beta2
  33. 33. Complex Associations<?phpclass User{ /** * @ReferenceMany( * targetDocument="Comment", * mappedBy="blogPost", * sort={"date"="desc"}, * limit=5) */ private $last5Comments;}
  34. 34. Query API<?php$qb = $dm->createQueryBuilder(User) ->field(groups) ->all(array(Group 1, Group 2)) ->sort("username", "asc") ->limit(10) ->skip(10) ->execute();
  35. 35. Map/Reduce<?php$qb = $dm->createQueryBuilder(DocumentsUser) ->field(type)->equals(sale) ->map(function() { emit(this.user.$id, 1); }) ->reduce(function(k, vals) { var sum = 0; for (var i in vals) { sum += vals[i]; } return sum; });
  36. 36. Geospatial Queries<?php/** @Document @Index(keys={"coordinates"="2d"}) */class City{ /** @EmbedOne(targetDocument="Coordinates") */ public $coordinates; /** @Distance */ public $distance;}class Coordinates{ public $lat; public $long;}
  37. 37. Geospatial Queries 2Execute a Geospatial query and find locations near a point:<?php/* @var $dm DocumentManager */$cities = $dm->createQuery(City) ->field(coordinates)->near(50, 60) ->execute();
  38. 38. Eventual MigrationHandle simple and complex schema refactorings<?php/** @Document */class Person{ public $id; public $name; // old /** @AlsoLoad("name") */ public $fullName;}
  39. 39. More of Doctrine MongoDB Support for Trees Support for Files in MongoGridFS Capped Collections Tailable Cursors
  40. 40. PHPCR ODMPHPCR: Port of the Java Content Repository APIJackalope: Access to Apache Jackrabbit in PHPDoctrine PHPCR ODM: PHP objects from PHP Content Repositories
  41. 41. Object to XML MapperConvert objects to XML documents and back using metadata<?php$user = new User();$user->setFirstName(John);$user->setLastName(Doe);$user->setAddress(new Address(123 Street, New Haven));$user->addContact(new CustomerContact(no@way.com));$xml = $marshaller->marshalToString($user);$user = $marshaller->unmarshalFromString($xml);
  42. 42. Using Doctrine 2.0.x ORM?Please checkout 2.1 BETA1 Backwards compatible! You win a present if you can prove otherwise.
  43. 43. Thank you!Rate this talk:http://joind.in/talk/view/3515

×
