SharePoint Saturday The Conference 2011 - Extranets & Claims Authentication Presentation Transcript

  • 1. SharePoint 2010 Extranets & Authentication
  • 2. Welcome to SharePoint Saturday—The Conference Thank you for being a part of the first SharePoint Saturday conference • Please turn off all electronic devices or set them to vibrate. • If you must take a phone call, please do so in the hall so as not to disturb others. • Open wireless access is available at SSID: SPSTC2011 • Feel free to “tweet and blog” during the session • Thanks to our Diamond and Platinum Sponsors:
  • 3. About Brian Culver– SharePoint Solutions Architect for Expert Point Solutions– Based in Houston, TX– Author • SharePoint 2010 Unleashed • Various White Papers– Speaker and Blogger
  • 4. Session Agenda• Extranet Definition• Common Extranet Scenarios• Extranet Design Considerations & Challenges• Claims Based Authentication and other Authentication Scenarios• Mixed Mode vs. Multi-Authentication
  • 5. Extranet - Definition• A web application that is shared with external users, such as partners, vendors, and customers• Common attributes for an extranet: • Sharing a private network or secured network • Requires authenticated access, but the identity of the consumer is not always known • Has better security controls than an Internet Web application but usually less secure than the Intranet • Web application
  • 6. Common Extranet Scenarios Line of Business Applications Remote CollaborationEmployees Static Content or Publishing Isolate and segregate internal data. Authorize to use only sites and data that are necessary forPartners their contributions. Restrict partners from viewing other partners’ data. Target ContentVendors & Segment contentCustomers Limit content access and search results based on audience.
  • 7. Extranet Design Considerations & Challenges• Network Topology and Access• Identity Management – Seamless Single Sign-on Experience• Content Security and Access• Antivirus – Client – Server• Rich Client Experience (Office Integration)
  • 8. Edge Firewall Topology
  • 9. Back-to-Back Perimeter Topology
  • 10. Split Back-to-Back Topology
  • 11. Security Terms• Authentication is the mechanism whereby systems may securely identify their users – Creates an identity for security principal – Who am I?• Authorization is the mechanism by which a system determines what level of access a particular authenticated user should have to secured resources controlled by the system. – Determines what resources an identity has access to – What can I access?
  • 12. SharePoint Authentication• SharePoint does not authenticate – Windows authentication via Windows server and IIS (Kerberos/NTLM) – FBA via ASP. NET and authentication providers (SQL, LDAP, etc.) – Web SSO via Active Directory Federation Services (ADFS) and other Identity Management Systems• SharePoint creates user profiles – SPUser object represents security principal – User Profile List in Site Collections track user profiles
  • 13. SharePoint 2010 Security• SharePoint 2010 changes authentication – Uses classic mode and claims based authentication – Classic mode is SharePoint 2007 style legacy mode – Claims-based authentication is the new security model• What are the benefits? – Claims decouples SharePoint from the authentication provider – Allows SharePoint to support multiple authentication providers per URL – Identities can be passed without Kerberos delegation – Allows federation between organizations – ACLs can be configured with – DLs, Audiences and OUs
  • 14. Identity Normalization
  • 15. Claims-Based Terminology• Identity: security principal used to configure the security policy• Claim (Assertion): attribute of an identity (such as Login Name, AD Group, etc.)• Security Token: serialized set of claims (assertions) about an authenticated user.
  • 16. Claim-based Authentication• Security Token Service (STS): builds, signs and issues security tokens. It can receive and submit tokens.• Issuing Authority: identity management system(s) that “knows” the claims (AD, ASP.NET, LiveID, etc.)• Identity Provider: trusted party that creates and submits claims• Relying Party: application that makes authorization decisions based on received claims
  • 17. Claim-based Authentication
  • 18. Claim-based Authentication
  • 19. Mixed Mode Authentication vs Multi- AuthenticationMixed Authentication Multi-Authentication SharePoint SharePoint Farm Farm Web Application Web Application Windows Windows Authentication Zone: Default Authentication Zone: Default Regular label-callout text FBA Authentication Extended Web Application Extended Web Application Zone: Extranet FBA Zone: Extranet SAML Based Authentication Authentication FBA Authentication Extended Web Application Extended Web Application Zone: Intranet ... Zone: Intranet Windows Authentication Extended Web Application Extended Web Application Zone: Internet ... Zone: Internet ... Extended Web Application Extended Web Application Zone: Custom ... Zone: Custom ...
  • 20. Auth Scenarios - Mixed Modes
  • 21. Authentication Scenarios Mixed Mode: When to Use It
  • 22. Auth Scenarios - Multi Authentication s
  • 23. Authentication ScenariosMulti Authentication: When to Use It
  • 24. Authentication Scenarios Multi Authentication & Mixed Mode
  • 25. FBA Claims Configuration1. Run C:WindowsMicrosoft.NETFrameworkv2.0.50727 aspnet_regsql.exe2. Enable Claims Authentication on Web Application via Central Administration3. Modify web.config for the FBA Web Application4. Modify web.config for Central Administration
  • 26. FBA Claims Configuration5. Modify web.config for Security Token Service – %programfiles%common filesMicrosoft Sharedweb server extensions14WebServicesSecurityToken – Changes need to be made to the Security Token Service virtual directory on each server hosting CA or the claims-based web application6. Configure FBA Provider in Central Administration7. Create Web Application Policy to give SQL Auth User(s) access to site
  • 27. Claims Configuration
  • 28. FBA Claims ConfigurationWeb Application web.config<roleManager defaultProvider="c" enabled="true" cacheRolesInCookie="false"> <providers><add name="c" type="Microsoft.SharePoint.Administration.Claims.SPClaimsAuthRoleProvider, Microsoft.SharePoint, Version=14.0.0.0, Culture=neutral, PublicKeyToken=71e9bce111e9429c" /><add connectionStringName="SQLConnectionString" applicationName="/" description="Stores and retrieves roles from SQL Server" name="SQL-RoleManager" type="System.Web.Security.SqlRoleProvider, System.Web, Version=2.0.3600.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" /></providers></roleManager> <membership defaultProvider="i“> <providers><add name="i" type="Microsoft.SharePoint.Administration.Claims.SPClaimsAuthMembershipProvider, Microsoft.SharePoint, Version=14.0.0.0, Culture=neutral, PublicKeyToken=71e9bce111e9429c" /><add connectionStringName="SQLConnectionString" passwordAttemptWindow="5" enablePasswordRetrieval="false" enablePasswordReset="false" requiresQuestionAndAnswer="true" applicationName="/" requiresUniqueEmail="true" passwordFormat="Hashed" description="Stores and Retrieves membership data from SQL Server" name="SQL-MembershipProvider" type="System.Web.Security.SqlMembershipProvider, System.Web, Version=2.0.3600.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" /></providers> </membership> </system.web>
  • 29. FBA Claims ConfigurationCentral Admin Web.config<roleManager defaultProvider="AspNetWindowsTokenRoleProvider" enabled="true" cacheRolesInCookie="false"><providers><add connectionStringName="SQLConnectionString" applicationName="/" description="Stores and retrieves roles from SQL Server" name="SQL-RoleManager" type="System.Web.Security.SqlRoleProvider, System.Web, Version=2.0.3600.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" /></providers></roleManager><membership defaultProvider="SQL-MembershipProvider"><providers><add connectionStringName="SQLConnectionString" passwordAttemptWindow="5" enablePasswordRetrieval="false" enablePasswordReset="false" requiresQuestionAndAnswer="true" applicationName="/" requiresUniqueEmail="true" passwordFormat="Hashed" description="Stores and Retrieves membership data from SQL Server" name="SQL-MembershipProvider" type="System.Web.Security.SqlMembershipProvider, System.Web, Version=2.0.3600.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" /></providers></membership>
  • 30. FBA Claims ConfigurationSecure Store Web Service web.config<connectionStrings><add name="SQLConnectionString" connectionString="Integrated Security=SSPI;Persist Security Info=False;Initial Catalog=aspnetdb;Data Source=.sharepoint" /></connectionStrings><system.web> <roleManager defaultProvider="c" enabled="true" cacheRolesInCookie="false“> <providers><add name="c" type="Microsoft.SharePoint.Administration.Claims.SPClaimsAuthRoleProvider, Microsoft.SharePoint, Version=14.0.0.0, Culture=neutral, PublicKeyToken=71e9bce111e9429c" /><add connectionStringName="SQLConnectionString" applicationName="/" description="Stores and retrieves roles from SQL Server" name="SQL-RoleManager" type="System.Web.Security.SqlRoleProvider, System.Web, Version=2.0.3600.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" /></providers> </roleManager> <membership defaultProvider="i"> <providers><add name="i" type="Microsoft.SharePoint.Administration.Claims.SPClaimsAuthMembershipProvider, Microsoft.SharePoint, Version=14.0.0.0, Culture=neutral, PublicKeyToken=71e9bce111e9429c" /><add connectionStringName="SQLConnectionString" passwordAttemptWindow="5" enablePasswordRetrieval="false" enablePasswordReset="false" requiresQuestionAndAnswer="true" applicationName="/" requiresUniqueEmail="true" passwordFormat="Hashed" description="Stores and Retrieves membership data from SQL Server" name="SQL-MembershipProvider" type="System.Web.Security.SqlMembershipProvider, System.Web, Version=2.0.3600.0, Culture=neutral, PublicKeyToken=b03f5f7f11d50a3a" /></providers> </membership> </system.web>
  • 31. Claims Configuration
  • 32. Claims Configuration
  • 33. Claims Configuration
  • 34. Claims Configuration
  • 35. Claims Configuration
  • 36. Issues using Claims Authentication• "Search Alerts only work with Windows Classic Authentication“ – http://technet.microsoft.com/en-us/library/cc288475.aspx• Performance Point Dashboard Designer doesnt work directly against a web application with multiple authentication providers – http://technet.microsoft.com/en-us/library/ee748637.aspx
  • 37. Issues using Claims Authentication• Some issues have been reported with Infopath Forms Services, PowerPivot and Performance Point Services• Project Server wont create new sites on a claims- based authentication web app but dont see a reference for it
  • 38. Welcome to SharePoint Saturday—The Conference Thanks to our SponsorsThanks to Our Other Sponsors!
  • 39. Questions
  • 40. Brian Culver, MCMTwitter:@spbrianculverE-mail:brian.culver@expertpointsolutions.comBlog:spbrian.blogspot.com
  • 41. Welcome to SharePoint Saturday—The Conference Session Evaluation Please complete and turn in your Session Evaluation Form so we can improve future events. Survey can be filled out at: http://app.fluidsurveys.com/surveys/spstc2011- and add the Session number to the URL Presenter: Brian Culver Session Name: SharePoint 2010 Extranets and Authentication: How will SharePoint Connect you to your Partners? Session No.: Sat-S5A-101
  • 42. Useful Links• SharePoint 2010 FBA User Management• SharePoint 2010 Forms Based Authentication Configuration Manager http://blogs.technet.com/b/speschka/archive/2010/07/28/sharepoint-2010- forms-based-authentication-configuration-manager.aspx SharePoint 2010: transparent login with mixed authentication http://www.orbitone.com/en/blog/archive/2010/06/23/sharepoint-2010-mixed- authentication-automatic-login.aspx Steve Peschka article’s on Forms Authentication » Forms Authentication in SharePoint Products and Technologies (Part 1): Introduction » Forms Authentication in SharePoint Products and Technologies (Part 2): Membership and Role Provider Samples » Forms Authentication in SharePoint Products and Technologies (Part 3): Forms Authentication vs. Windows Authentication
