    A Peek At The Future: Going Beyond JavaServer Faces 2.0 With RichFaces 4 A Peek At The Future: Going Beyond JavaServer Faces 2.0 With RichFaces 4 Presentation Transcript

    • 1
    • JSF 2 And Beyond With RichFaces Jay Balunas Alex Smirnov RichFaces Project Lead RichFaces Architect JBoss, by Red Hat Inc. Exadel Inc. JavaOne September, 2010 2
    • Who We Are: • Jay Balunas o RichFaces Project Lead o JBoss Core Developer o http://in.relation.to/Bloggers/Jay o http://twitter.com/tech4j o jbalunas@jboss.org Co-author of the RichFaces Dzone RefCard 3
    • • Alexander Smirnov o RichFaces Project Architect o Ajax4Jsf Project Creator o JSR-314 ( JSF 2.0 ) Expert Group Member o http://alexsmirnov.wordpress.com/ o asmirnov@exadel.com 4
    • Beyond JSF 2.0 with RichFaces • An Introduction • Built in Ajax • Built in Resource Handling • Component Development • Client Side Bean Validation • Project Updates 5
    • RichFaces Lighting Review • Ajax enabled component library o 100+ components • Two tag libraries o a4j: Page level ajax support & utility components o rich: Self contained rich components • More than just components: o Skinning & themes o Dynamic resources o Component development kit (CDK) 6
    • Beyond JSF 2.0 with RichFaces • An Introduction • Built in Ajax • Built in Resource Handling • Component Development • Client Side Bean Validation • Project Updates 7
    • JSF 2.0 Built in Ajax <h:inputText id="name_input" value="#{userBean.name}" /> <f:ajax event="keyup" execute=”@this” render="name_out" /> </h:inputText> <h:outputText id="name_out" value="#{userBean.name}" /> 8
    • Ajax Attributes event="keyup" • DOM event to trigger Ajax request • Default values o ActionSource == "action"  Typically "onclick" o Editable ValueHolders == "valueChange"  Depends on type  ex. "onblur" for inputText 9
    • Ajax Attributes Both accept component IDs, or the new keywords execute=”@this” • Components to process on server o validation, model updates, listeners, etc... • Default == "@this" render="name_out" • Components to update on request return • Default == "@none" 10
    • JSF 2.0 Ajax Keywords Define a set of component identifiers • No need to explicitly state component IDs @none Smallest to largest scope @this @form @all 11
    • RichFaces makes it better with... • a4j:region • a4j:outputPanel • a4j:queue • Partial updates for complex components 12
    • Ajax Region & Output Panel a4j:region No need to set Set areas of the page to be "execute=x,y,z" processed on the Server! a4j:outputPanel No need to set Set area's of the page to be "render=x,y,z" rendered for any Ajax request! 13
    • RichFaces Ajax Region <!-- Verify Address as part of a large form --> <a4j:region> <h:inputText id="addr_01" ... /> <h:inputText id="city" ... /> <h:inputText id="state" ... /> <h:inputText id="zip" ... /> ... <h:commandLink action="#{registerBean.verifyAddress}" > <a4j:ajax/> <!--<f:ajax execute="addr_01 city state zip"/>--> </h:commandLink> </a4j:region> 14
    • RichFaces Output Panel <!-- Will always be updated with any ajax request --> <a4j:outputPanel ajaxRendered="true"> <h:outputText value="Score : #{gameBean.score}" /> </a4j:outputPanel> No need to set "render" attribute 15
    • JSF 2.0 Request Queue • Specification added Ajax requests • Requests need to be queued to preserve state • Good, but limited o Very few options o No client side api • Can lead to traffic jams... 16
    • RichFaces Request Queues • Adds a logical queue o Usability & customizations • Options o requestDelay & request grouping o IgnoreDupResponses (in development) • Client side API o <queueObj>.getSize() o <queueObj>.isEmpty() o <queueObj>.set/getQueueOptions() o etc... 17
    • RichFaces Request Queues <h:form id="form"> <!-- Queue applied to whole form --> <a4j:queue requestDelay="500"/> <h:inputText id="team1" value="#{gameBean.team1}" /> <a4j:ajax event="keyup" .../> </h:inputText> <h:inputText id="team2" value="#{gameBean.team2}" /> <a4j:ajax event="keyup" .../> </h:inputText> ... </h:form> 18
    • RichFaces Request Queues <!-- Player lookups are more costly, send less often --> <a4j:queue name="player_queue" requestDelay="1000"/> ... <h:inputText id="player" value="#{gameBean.cur_player}" /> <a4j:ajax event="keyup" ...> <!-- Requests from here will use player_queue --> <a4j:attachQueue name="player_queue"/> </a4j:ajax> </h:inputText> 19
    • Partial Updates for Complex Components • RichFaces adds updates within complex components o Table supports: @body, @header, @footer, @row & @cell o Collections of rows Track updates, and render as group o Others, like tree & tabPanel in the future ex. @node, @tab, etc... 20
    • Partial Updates for Iteration Components <!-- Will render only the body of the table --> <a4j:ajax render="table_id@body"/> <!-- Will render only the current row --> <rich:column> <a4j:commandButton render="@row"/> </rich:column> 21
    • Beyond JSF 2.0 with RichFaces • An Introduction • Built in Ajax • Built in Resource Handling • Component Development • Client Side Bean Validation • Project Updates 22
    • JSF 2.0 Loading Images <!-- Loads from <web-root>/resources --> <h:graphicImage name="banner.jpeg /> <!-- Loads from /META-INF/resources/site --> <h:graphicImage name="banner.jpeg" library="site"/> <!-- EL notation --> <h:graphicImage value="#{resource['site:banner.jpeg]}" /> 23
    • JSF 2.0 Loading JavaScript & CSS Two new resource components <!-- Loads where you put it --> <h:outputScript name=”project.js”/> <!-- Loads in the <h:head> --> <h:outputScript name=”project.js” target=”head”/> <!-- CSS always loads in <h:head> --> <h:outputStylesheet name=”frontpage.css” library=”site”/> 24
    • What if you need to manipulate resources... 25
    • Dynamic Resources in RichFaces • Extends JSF 2.0 resource handler • Used by RichFaces internally o Skinning o CSS with embedded EL o Java2D • Make your own!! o Custom icons with state info o Dynamic CSS & JS 26
    • @DynamicResource public class GameAiResource implements UserResource{ private boolean easyGame; public InputStream getInputStream() throws IOException { byte[] data; if (easyGame) { data = easyScript; } else{ data = hardScript; } return new ByteArrayInputStream(data); } .... 27
    • Now Go Get It... Define mapping in resource property file: #Maps dynamic resource end-point aiScript=foo.bar.GameAiResource <!-- Retrieved like any other resource --> <h:outputScript name="aiScript"/> 28
    • Sending in the Parameters... @ResourceParameter protected boolean easyGame; #Create resource mapping easyScript= foo.bar.GameAiResource?easyGame=true <!-- Always returns the easyScript resource --> <h:outputScript name="easyScript"/> 29
    • Beyond JSF 2.0 with RichFaces • An Introduction • Built in Ajax • Built in Resource Handling • Component Development • Client Side Bean Validation • Project Updates 30
    • JSF 2.0 Component Development JSF 2.0 simplifies component development: • New annotations o @FacesComponent, @FacesRenderer o Helper methods, StateHelper • Still necessary to : o Extend UIComponentBase class o Create Renderer  Implement the decode/encode*() methods o Create tag handlers and tag lib files o Component functionality classes o Maintain it all... 31
    • JSF 2 Component Development ResponseWriter writer = context.getResponseWriter(); assert(writer != null); String formClientId = RenderKitUtils.getFormClientId(command, context); if (formClientId == null) { return; } Just part of CommandLinkRenderer.java //make link act as if it's a button using javascript writer.startElement("a", command); (it's 272 lines total ) writeIdAttributeIfNecessary(context, writer, command); writer.writeAttribute("href", "#", "href"); RenderKitUtils.renderPassThruAttributes(context,writer,command, ATTRIBUTES, getNonOnClickBehaviors(command)); RenderKitUtils.renderXHTMLStyleBooleanAttributes(writer, command); String target = (String) command.getAttributes().get("target"); if (target != null) { target = target.trim(); } else { target = ""; } Collection<ClientBehaviorContext.Parameter> params = getBehaviorParameters(command); RenderKitUtils.renderOnclick(context, command, params, target, true); writeCommonLinkAttributes(writer, command); // render the current value as link text. writeValue(command, writer); 32
    • JSF 2.0 Composite Components • Reusable, easy to create • Declarative XML language • Create custom components from existing ones Limitations: • Available in Facelets VDL only. • Limited place for custom logic. • Limited ability to process JSF events • Does not help to create Behaviors, Converters, Validators, and EL Functions. For complex components, you still require Java. 33
    • JSF 2.0 composite <composite:interface> <composite:attribute name="value" required="false"/> </composite:interface> <composite:implementation> <h:outputText value="#{cc.attrs.value}" style="background-color: yellow"/> </composite:implementation> 34
    • RichFaces Component Development Kit • Does much of the leg work for you! • Coding by convention • In the best case you only need two things: o Abstract component class o Renderer template in xml/xhtml • Integrates into your build o Maven-plugin o Java Annotations Processor • IDE support o Standard xml files & schema o Type safe 35
    • JSF 2.0 composite <composite:interface> <composite:attribute name="value" required="false"/> </composite:interface> <composite:implementation> <h:outputText value="#{cc.attrs.value}" style="background-color: yellow"/> </composite:implementation> 36
    • RichFaces Renderer Template <composite:interface> <!-- <cdk:component-family> org.richfaces.Out </cdk:component-family/> --> <composite:attribute name="value" required="false"/> </composite:interface> <composite:implementation> <div id="#{clientId}" style="background-color: yellow"> #{component.attributes.value} </div> </composite:implementation> 37
    • RichFaces Component Development • Abstract component class o Only implement component functionality o CDK will extend it based on:  Annotations  Naming Conventions  Template  Config options • CDK will compile template for renderer o Including concrete component class  Getters/setters, etc.. o Tag handlers, tab lib, and faces-config files 38
    • RichFaces Component Development Not limited to JSF components, but also helps to create: • Converters • Validators • Faces Events/Event Listeners • Behaviors. • Behavior Renderers • compile JavaScript into renderer. • EL Functions • Unit tests • Documentation 39
    • Beyond JSF 2.0 with RichFaces • An Introduction • Built in Ajax • Built in Resource Handling • Component Development • Client Side Bean Validation • Project Updates 40
    • What is Bean Validation • Bean Validation JSR-303 o Part of Java EE6 • Generic, tier independent constraints • Custom, and composition constraints possible • Constraint groups, and object graph validation too • Message localization • Define constraints once, apply everywhere* * Not all the way to the browser 41
    • Bean Validation Sample public class User { @NotEmpty @Size(max=100) private String loginname; @NotEmpty @Pattern(regexp = "[a-zA-Z0-9]+@[a-zA-Z0-9]+.[a-zA-Z0-9]+") private String email; @NotEmpty @ValidTeam private String team; } 42
    • JSF 2.0 Bean Validation Integration Login: <h:inputText id="login" value="#{user.login}"/> <h:message for="login"/> <br/> Email: <h:inputText id="email" value="#{user.email}"/> <h:message for="email"/> <br/> Team: <h:inputText id="team" value="#{user.team}"> <f:validateBean disabled="true"/> </h:inputText> <h:message for="team"/> <br/> 43
    • RichFaces Validation • Validate entire object • Takes it to the Client, there possible o Ajax fallback options • Use the same constrains on both sides • JavaScript: o Validation, Converters, Messages • Can be applied to: o Inputs, Commands, Views • Develop you own validators o Client/server JS mapping 44
    • RichFaces Object Validation JSF validation protects your Model from invalid values: • Get client input as String request parameter. • Convert String to target value class using converter. • Mark value as invalid if string doesn't match ( e.g. characters in the number ). • Verify converted object using Validator. • Model updated only if there are no errors on previous steps. 45
    • RichFaces Object Validation JSF validation protects your Model from invalid values, but: • it's hard to validate multiply fields together. • JSR-303 graph validator can verify updated model only. 46
    • RichFaces Object Validation <rich:graphValidator value="#{passwordBean}"> <h:inputText value="#{passwordBean.password}" /> <h:inputText value="#{passwordBean.retypePassword}" /> </rich:graphValidator> public class PasswordBean implements Cloneable { @Size(min=6) @GoodPassword private String password ; @Size(min=6) private String retypePassword ; @AssertTrue(message="Passwords do not match") public boolean match(){ return password.equals(retypePassword); } 47
    • RichFaces Object Validation What does <rich:graphValidator > do ? 1. clone Bean object instance. 2. If there is no per-field errors, update cloned object with submitted values at the end of PROCESS_VALIDATORS phase. 3. Perform JSR-303 validation on cloned object. Record errors ( if any ) and discard cloned object. 4. Go back to JSF lifecycle there model updated only if all constraint violations passed. 48
    • RichFaces Object Validation Limitations: • Model class should properly implement Cloneable interface. • Cannot inquire into EL variable references ( "var" dataTable variable ). 49
    • RichFaces Client Side Validation RichFaces 4.0 ( under development ) performs constraint validation on the client side where possible: • Implemented as JSF 2.0 Behavior • Transparent for application developers • Looks up JavaScript version of JSF Converter and Validator. • If client-side version found, performs validation on client with the same constraints as server-side. • Update RichFaces message component directly on the client. • Otherwise, call Java code using AJAX transport. See https://community.jboss.org/wiki/ClientSideValidation 50
    • RichFaces Client Validation - Inputs Login: <h:inputText id="login" value="#{user.login}"> <rich:clientValidator event="keyup"/> </h:inputText> <rich:message for="login"/> Email: <h:inputText id="email" value="#{user.email}"> <rich:clientValidator event="keyup"/> </h:inputText> <rich:message for="email"/> 51
    • RichFaces Client Validation - Forms <h:form id="register"> Login: <h:inputText id="login" value="#{user.login}"/> <rich:message for="login"/> Email: <h:inputText id="email" value="#{user.email}"/> <rich:message for="email"/> <!-- This will verify when form submitted --> <h:commandButton id="submit" value="Save"> <rich:clientValidator/> </h:commandButton > ...... 52
    • Beyond JSF 2.0 with RichFaces • An Introduction • Built in Ajax • Built in Resource Handling • Component Development • Client Side Bean Validation • Project Updates 53
    • RichFaces 3.3.X • Stable and mature • Community Versions: o Moved into maintenance mode • Enterprise supported versions included with: o Enterprise Application Platform (EAP) o Enterprise Portal Platform (EPP) o Web Framework Kit (WFK) 54
    • RichFaces 4.0.X • In Development o Latest Release: 4.0.0.Milestone2 • Complete JSF 2 integration & more... o Custom Behaviors o Dynamic Resource Extensions o Simplified Component Development Kit o Updated skinning o Completely refactored o Design for long term stability and support 55
    • Rich Components! 56
    • RichFaces 4.0.X • Wrapping up milestone project phase: o 4.0.0.Milestone3 in Early October o 4.0.0.Milestone4 in November o 4.0.0.Milestone5 in December o 4.0.0.CR/Final in January/February • Each release includes: o New & migrated components o Stabilization of core/cdk o Migration& developer guides 57
    • How To Get Started • Project Page: http://richfaces.org • 4.0 Downloads o http://bit.ly/RF_Milestones • Maven Integration o http://bit.ly/RF_Maven • User Wiki/Forums o Great for "how to" questions, and information o http://bit.ly/RF_User_Space • RichFaces Bug Tracker o http://bit.ly/RF_Jira 58
    • More Way To Connect • Project Twitter Account o http://twitter.com/richfaces • Project Calendar o http://bit.ly/RF_Calendar • IRC o #richfaces @ irc.freenode.net • Team Meetings (open to all) o http://bit.ly/RF_Team_Mtgs • Developer Blogs o [Jay] http://in.relation.to/Bloggers/Jay o [Alex] http://alexsmirnov.wordpress.com/ o [Ilya] http://www.jroller.com/a4j/ 59
    • How To Get Involved • Developer Wiki/Forum o Bring up your ideas, or discuss patches! o http://bit.ly/RF_Dev_Space • Anonymous SVN o http://bit.ly/RF_SVN • Sandbox SVN o http://bit.ly/RF_SVN_Sandbox • Directory Structure Explained o http://bit.ly/RF_Build_Structure • Build Options o http://bit.ly/RF_Build_Options • Hudson CI Server o http://bit.ly/RF_Hudson_CI 60
    • Wrap up and Q&A 61
