Working with Portlets
in Oracle ADF & Webcenter
     Presenter: Zeeshan Baig
      www.baigzeeshan.com
    www.youtube.com/baigsorcl

              Session # 288     1
A little about me….
• Currently working as Senior Architect Developer at Northwestern
  Memorial Hospital in Chicago.
• 12+ years of experience in Oracle Development tools (Database,
  Forms, APEX, ADF, Fusion)
• Oracle ACE, OCP DBA certified in 8, 8i and 10g
• Technical blog on ADF and other fusion technologies at
  www.baigzeeshan.com
• YouTube channel http://youtube.com/baigsorcl
Disclaimer: The views expressed are my own and does not affiliates with my employer
             Images used in this presentation courtesy of Google images and Oracle Documentation



                                                               Session # 288                       2
Agenda
•   ADF & Webcenter Overview
•   What is Portlet?
•   Portlets Producer Types and Modes
•   ADF Task flows v/s Portlets
•   Developing Portlets in ADF
•   Testing and Deploying Portlets
•   Consuming Portlets in Webcenter Portal and Spaces
•   Portlet Communication
•   Tips & Guidelines
•   Demo
•   Q&A
                                Session # 288           3
Survey


• How many people are familiar with Java?

• How many people are working with
 Oracle ADF OR WebCenter?

• How many people have worked with Portlets?



                              Session # 288    4
ADF & Webcenter
What is ADF?
   End to end framework builds on JEE standard
platform to develop Web 2.0 Applications

What is Webcenter?
  Extensional framework builds on top of ADF to
develop Enterprise 2.0 portals with features like
Portlets, RSS, Discussion forums and Content
management

What is Jdeveloper?
  A free integrated tool to build Java-SOA based
applications
                                           Session # 288   5
Things to do

• Download and Install Oracle
database i.e. Oracle XE

• Download and Install Oracle
Jdeveloper version 11.1.1.5 (PS4)

• Download and Install Oracle
Webcenter Extensions for Jdeveloper



                                      Session # 288   6
What is Portlet?
• As per Wikipedia
      "Portlets are pluggable user interface software components
            that are managed and displayed in a web portal."
• Reusable component visible on page
• Draws content from different sources
• Often compare to web-services and ADF task flows
• Can be local or remotely deployed
• Can display excerpts from other sites
• May or may not be rendered in in-line IFRAME
• Can display elements of HTML, formatted text, images

                                Session # 288                       7
Portlets




 Session # 288   8
Portlet Producers Types
      Works as a communication link between Portal and Portlets

WSRP Producer
  Uses WSDL, allows any standard web-based application to work as portlet.

PDK-Java Producer
  Uses Industry standards like XML, SOAP, HTTP.

Portal-Tools Producer
  Allows to create/consume portlets on Portal without known complex programming

                                     Session # 288                           9
Portlets Modes
VIEW       Defines how portlet will be visible on page. All portlets
           must have View mode.
EDIT       Allow authorized user to personalize portlet e.g. Title,
           appearance, content
EDIT –     Allow to change system-level personalization on the
DEFAULTS   portlet
HELP       Allow to display information about functionality of the
           portlet
ABOUT      Display information like version, copyright, contact
           author
                           Session # 288                           10
Task Flows v/s Portlets
       Local Task Flow               Remote Task Flow               ADF Based Portlet
Use same Skin as consumer       Use its own skin. opens in    Renders in iFrames uses its
portal                          pop or different window       own skin
Support Transactions            No Support for Transactions   No Support for Transactions
Interaction between task        Input output parameters       inter-portlet communication
flows via Contextual events,
Input output parameters
Deployed with consumer app      Deployed separately           Deployed separately
Full ADF / Webcenter security   Requires Single Sign-on       WS-Security with OWSM is
                                                              used for authentication

                                         Session # 288                                11
Portlet Types

• JSF Portlets
• Programmable Portlets
  •   Standard Java Portlet
  •   PDK-Java Portlet

• Web clipping
• Omni Portlet



                                  Session # 288   12
JSF Portlets

• Oracle JSF Portlet Bridge allows to convert
existing JSF applications into Portlets

• Same code for both portlets and app

• Right click Task flow or Page and choose
“Create Portlet Entry”

• File portlet.xml file contains all metadata


                                         Session # 288   13
Programmable Portlets

• Standard based JSR 286 Portlets uses
WSRP and WSDL

• PDK Java Portlets uses standard
technologies

• Ideal for Integration with other apps

• Usually Deployed as WAR

                                          Session # 288   14
Web Clipping
• Clips a complete or section of web
page as a portlet

• No Coding experience required

• Leverage single sign-on solution with
sites requires authentication

• Some limitations exists


                                       Session # 288   15
Omni-Portlet
• Allow to add portlet to your application at
design time, and customize at runtime.

• Supports many Data sources
including SQL, XML, web services,
spreadsheets, and web pages.

• Supports different layouts like tables
and charts

• Allows personalization
                                           Session # 288   16
Testing & Deployment

• Test in Integrated Weblogic Server


• Deploy to Weblogic server
   • Create WAR deployment description
   • Right click portlet and create WAR file
   OR
   • Deploy directly to Application server




                                         Session # 288   17
Consuming Portlets
          In Webcenter Portal

• Get portlet WSDL or Provider URL end-
  point
• Create Connection in Resource Palette or
  Webcenter Portal application to register
  the portlet
• Drag and Drop the Portlet from connection
  to JSF Page
• Set necessary Portlet tags and parameters

                                    Session # 288   18
Consuming Portlets
        In Webcenter Spaces

• Get portlet WSDL or Provider URL end-
  point
• Open Enterprise Manager Fusion
  middleware Control
• Register Portlet with Webcenter Spaces
• Edit Webcenter spaces JSF page in
  Composer mode
• Add Portlet from Resource catalog
• Enter portlet parameters and Save
                                    Session # 288   19
Portlets Communication
• Wiring Portlets at Design Time
   – Edit Page Binding for Portlet 2
   – Set source of parameter as source of Portlet 1
   – Set Partial triggers
• Wiring Portlets at Runtime
   –   Log in as Administrator on Portal
   –   Edit the page and go to Portlet properties
   –   Use EL Expression to set the parameter values
   –   Set partial triggers to portlet Id
• Contextual Wiring of Portlets using Events
   – Uses payLoad instead of parameter values
   – Set payLoad values at Event tab of portlet properties
                                           Session # 288     20
Tips & Guidelines
• Use Standard HTML and CSS
• Keep content concise
• Test in different browsers with window resizing behavior
• Never use JavaScript to do redirect inside Portlet.
  Open a new browser window instead
• Pop-ups, Input date, Input color are not supported inside ADF
  based portlet
• Use database persistence store in web.xml specially in cluster
  environment
• Access using HTTP server instead of direct link to WLS


                                       Session # 288               21
DEMO




Session # 288   22
Thank you

Congratulations!! You are now Portlet Certified…




                      Session # 288                23
Session # 288   24
My Contact
BLOG
http://baigzeeshan.com

YouTube Channel
http://youtube.com/baigsorcl

LinkedIn:
http://www.linkedin.com/in/baigzeeshan

Email
zeeshan.baig82@gmail.com
                                     Session # 288   25
