Share and Share Alike Presentation Transcript

  • 1. Share and Share AlikeUsing System V shared memory constructs inMRI Ruby projects
  • 2. Who Am I?● Jeremy Holland● Senior Lead Developer at CentreSource in beautiful Nashville, TN● Math and Algorithms nerd● Scotch drinker● @awebneck,, freenode: awebneck, etc.
  • 3. The Problem ● FREAKIN ● HUGE ● BINARY ● TREE
  • 4. How huge?● Huge. Millions of nodes, each node holding ~500 bytes● e.g. Gigabytes of data● K-d tree of non-negligible dimension (varied, around 6-10)● No efficient existing implementation that would serve the purposes needed  Fast search  Reasonably fast consistency
  • 5. Things we considered ...and discarded● Index the tree, persist to disk  Loading umpteen gigs of data from disk takes a spell.  Reload it for each query  WAY TOO SLOW
  • 6. Things we considered ...and discarded● Index once and hold in memory  Issues both with maintaining index consistency and balance  Difficult to share among many processes / threads without duplicating in memory.
  • 7. Things we considered ...and discarded● DRb  Simulates memory shared by multiple processes, but not really  While the interface to search the tree is available to many different processes, actually searching it takes place in the single, server-based process
  • 8. Enter Shared Memory● Benefits  Shared segment actually accessible by multiple, wholly separate processes  Built-in access control and permissions  Built-in per-segment semaphore● Drawbacks  With great power comes great responsibility  Acts like a bytearray – manual serialization
  • 9. Ruby-level memory paradigm vs C-level memory paradigm● Ruby:  Everything goes on the heap  Garbage collected - no explicit freeing of memory● C:  Local vars, functions, etc. on the stack  Explicit allocations on the heap (malloc)  Explicit freeing of heap – no GC
  • 10. Ruby● Before start of process
  • 11. Ruby● Process starts● Heap begins to grow
  • 12. Ruby● Process runs● Heap continues to grow with additional allocations
  • 13. Ruby● Process runs● GC frees allocated memory no longer needed...
  • 14. Ruby● it can be reallocated for new objects
  • 15. Ruby● Process ends● Heap freed
  • 16. C● Process starts● Stack grows to hold functions, local vars
  • 17. C● Process runs● Memory is explicitly allocated from the heap in the form of arrays, structs, etc.
  • 18. C● Process runs● A function is called, and goes on the stack
  • 19. C● Process runs● The function returns, and is popped off the stack
  • 20. C● Process runs● The item in the heap, no longer needed, is explicitly freed
  • 21. C● Process runs● A new array is allocated from the heap
  • 22. C● Process ends (untidily)● The stack and heap are reclaimed by the OS as free
  • 23. TRUTHRuby itself has no concept of shared memory.
  • 24. TRUTH C does.
  • 25. Shared Memory● A running process (as viewed from the C level)
  • 26. Shared Memory● A shared segment is created with an explicit size – like allocating an array
  • 27. Shared Memory● The segment is ”attached” to the process at a virtual address
  • 28. Shared Memory● Yielding to the process a pointer to the beginning of the segment
  • 29. Shared Memory● A new process starts, wishing to attach to the same segment.
  • 30. Shared Memory● It asks the OS for the identifier of the segment based on an integer key Are you there? Yup!
  • 31. Shared Memory● ...and attaches it to itself in fashion similar to the original.
  • 32. Shared Memory● Both processes can now - depending on permissions – read and write from the segment simultaneously!
  • 33. Shared Memory● The first process finishes with the segment and detaches it.
  • 34. Shared Memory● And thereafter, ends.
  • 35. Shared Memory ● ...leaving only the second process, still attached
  • 36. Shared Memory ● Now, the second process detaches...
  • 37. Shared Memory ● ...and subsequently ends
  • 38. Shared Memory● Note that the shared segment is still in persisted in memory● Can be reattached to another process with permission to do so
  • 39. Shared Memory● Later, a new process comes along and explicitly destroys the segment, all processes being finished with it.
  • 40. How its done: Configuration● Precisely how much memory can be drafted into service for sharing purposes is controlled by kernel parameters  kernel.shmall – the maximum number of memory pages available for sharing (should be at least ceil(shmmax / PAGE_SIZE))  kernel.shmmax – the maximum size in bytes of a single shared segment  kernel.shmmni – the maximum number of shared segments allowed.
  • 41. How its done: Configuration● To view your current settings:
  • 42. How its done: Configuration● Or...
  • 43. How its done: Configuration● Setting the values temporarily can be accomplished with sysctl...
  • 44. How its done: Configuration● ...or more permanently by editing /etc/sysctl.conf
  • 45. How its done: Creating New and Acquiring Existing Segments● int shmget(key_t key, size_t size, int shmflag)  key_t key: integer key identifying the segment or IPC_PRIVATE  size_t size: integer size of segment in bytes (will be rounded up to next multiple of PAGE_SIZE)  int shmflag: mode flag consisting of standard o- g-w and IPC_CREAT (to create or attach to existing) and optionally IPC_EXCL (to throw an error if it already exists)
  • 46. How its done: Creating New and Acquiring Existing Segments● int shmget(key_t key, size_t size, int shmflag)  Returns: valid segment identifier integer on success, or -1 on error
  • 47. How its done: Attaching segments● void * shmat(int shmid, const void *shmaddr,  int shmflag)  shmid: integer identifier returned by a call to shmget  shmaddr: Pointer to the address at which to attach the memory. Almost always want to leave this NULL, so that the system will address the segment wherever theres room for it.
  • 48. How its done: Attaching segments● void *shmat(int shmid, const void *shmaddr, int  shmflag)  shmflag: several flags for controlling the attachment – most importantly, SHM_RDONLY (what it looks like)  returns: a void pointer to the start of the attached segment, or (void *)-1 on error
  • 49. How its done: Detaching segments● int shmdt(const void *shmaddr)  shmaddr: Pointer returned by the call to shmat  returns: 0 or -1 on error
  • 50. How its done: Getting segment information● int shmctl(int shmid, int cmd, struct shmid_ds  *buf)  shmaddr: The identifier returned by shmget  cmd: The command to execute – for this purpose, IPC_STAT  Buf: A shmid_ds struct
  • 51. How its done: Getting segment informationstruct shmid_ds {  struct   ipc_perm;    permissions/ownership  size_t   shm_segsz;   size of segment in bytes  time_t   shm_atime;   last attachment time  time_t   shm_dtime;   last detachment time  time_t   shm_ctime;   last change time  pid_t    shm_cpid;    pid of creator  pid_t    shm_lpid;    pid of last attached  shmatt_t shm_nattch;  # of attached processes}
  • 52. How its done: Destroying segments● int shmctl(int shmid, int cmd, struct shmid_ds  *buf)  shmaddr: The identifier returned by shmget  cmd: IPC_RMID  Buf: A shmid_ds struct (you can ignore it afterwards, but itll throw a fit if you dont provide it)
  • 53. ExamplesExamples
  • 54. Challenges and Caveats● Addressing  Segments are attached wherever there is room for them in the attaching process address space
  • 55. Challenges and Caveats● Maybe here in one process... 0x7f195bda2000
  • 56. Challenges and Caveats● ...maybe here in another 0x73f882c1f000
  • 57. Challenges and Caveats● So if you store an 0x7f195bda2004 absolute pointer in the segment that points somewhere else in the segment...
  • 58. Challenges and Caveats● Its not terribly likely to 0x7f195bda2004 point where you think it should when referenced in a separate process
  • 59. Challenges and Caveats● Addressing  Segments are attached wherever there is room for them in the attaching process address space  Absolute pointers are effectively useless  Relative pointers – i.e. Offsets  BSTs as heaps (the data structure).  Serialization.
  • 60. Challenges and Caveats● Duplication and copying  Ruby primitivesques (numerics, strings, etc) are all allocated on the heap  Shared data must be effectively copied  Diminishes the usefulness of the tool for certain applications (large data sharing)  Not everything is a nail
  • 61. Challenges and Caveats● Duplication and copying  But... fantastic for certain applications  Search  Search the shared structure at c level  Copy and coerce results to ruby objects  |results| << |data to be searched|  Semaphore, interprocess messaging  Built-in to the IPC/SHM lib!
  • 62. Semaphore● Tracking resource allocation  Effectively an integer checked when a process allocates some resource  If nonzero, decrement  If zero, the resource isnt available● Simple, but slightly weird API.
  • 63. Message Queues● Push bytearray/string messages into the queue, shift em off● Simple, slightly less bizarre API
  • 64. In closing...● Quite exciting, this computer magic● Dont just use it because its there  Have a NEED● Dont be afraid to drop to C  Dont know C?  Learn it – a pretty simple language, when alls said and done  Building ruby C extensions is actually pretty painless
  • 65. Questions / Comments In which I probably get trolled
  • 66. Thanks for listening!Enjoy the rest of the conference!
