ably                                 probWhats comingin Java Message Service 2.0Arun Gupta, Java EE & GlassFish Guyblogs.o...
The following is intended to outline our general product direction. It isintended for information purposes only, and may n...
Agenda   •  JSR 343 Update   •  Whats in the JMS 2.0 Early Draft            –  Simplifying the JMS API            –  Impro...
JMS   •  Java Message Service (JMS) specification            –  Part of Java EE but also stands alone            –  Last m...
JMS 2.0•  March 2011: JSR 343 launched to   develop JMS 2.0•  Target: to be part of Java EE 7 in Q2   2013•  Early Draft r...
JSR 343 Expert Group                                                                              ...6 | Copyright © 2012,...
Initial goals of JMS 2.0•  Simpler and easier to use                                                    •  Standardise int...
JMS 2.0 Timeline     ✔	                              Forma0on	  of	  expert	  group	        Q2	  2011	       ✔	           ...
Whats in the Early Draft   •  Here are some items in the JMS 2.0 Early Draft            –  Based on Expert Group members p...
Simplifying the JMS API10 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reserved. |
Whats wrong with the JMS API?    Not a lot...11 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reserved. |
Receiving messages in Java EE         @MessageDriven(mappedName = "jms/inboundQueue")         public class MyMDB implement...
Sending messages in Java EE      @Resource(lookup = "jms/connFactory")      ConnectionFactory cf;      @Resource(lookup="j...
Sending messages in Java EE      @Resource(lookup = "jms/connFactory")                                    Need to create  ...
Sending messages in Java EE        @Resource(lookup = "jms/connFactory")        ConnectionFactory cf;                     ...
Sending messages in Java EE      @Resource(lookup = "jms/connFactory")      ConnectionFactory cf;      @Resource(lookup="j...
Sending messages in Java EE      public void sendMessage (String payload) throws JMSException {         try {            C...
Sending messages in Java EE      public void sendMessage (String payload) {         Connection conn = null;         try { ...
Approaches to simplification    •  Simplify the existing API    •  Define new simplified API    •  Use CDI annotations to ...
Simplify the existing API•  Need to maintain backwards compatibility limits scope for change   –  New methods on javax.jms...
Sending a Message (Java EE)    Standard API        @Resource(lookup = "jms/connectionFactory ")        ConnectionFactory c...
Sending a Message (Java EE)    New Simplified API        @Resource(mappedName="jms/contextFactory")        ContextFactory ...
Sending a Message (Java EE)    New Simplified API (With Injection)        @Inject        @JMSConnectionFactory("jms/contex...
Receiving a Message Asynchronously    Standard API        @Resource(lookup = "jms/connectionFactory")        ConnectionFac...
Receiving a Message Asynchronously    New Simplified API        @Resource(lookup = "jms/connectionFactory")        Connect...
Receiving a Message Asynchronously    New Simplified API (With Injection)        @Inject        @JMSConnectionFactory("jms...
Some other simplifications27 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reserved. |
Making durable subscriptions easier to use    •  Durable subscriptions are identified by       {clientId, subscriptionName...
New features for PaaS29 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reserved. |
Annotations to create resources in Java EE    •  Currently no standard way for an application to define       what JMS res...
Annotations to create resources in Java EE    •  JSR 342 (Java EE 7) will define new annotations    •  Possible new SPI to...
Improving Integration    with    Application Servers32 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reser...
Defining the interface between    JMS provider and an application server    •  Requirement: allowing any JMS provider to w...
JMS 1.1 Chapter 8    JMS Application Server Facilities    •  Interfaces all optional, so not all vendors implement them   ...
Java EE Connector Architecture (JCA)    •  Designed for integrating pooled, transactional resources       in an applicatio...
Defining the interface between    JMS provider and an application server    •  JMS 2.0 will make provision of a JCA adapto...
Improvements to MDBs    •  Proposals being sent to JSR 342 (EJB 3.2)    •  Fill "gaps" in MDB configuration    •  Surprisi...
Defining the destination used by a MDB    •  annotation...               @MessageDriven(messageDestinationLookup="jms/inbo...
Defining the connection factory used by a MDB    •  annotation...          @MessageDriven(connectionFactoryLookup="jms/myC...
Defining the clientId and    durable subscription name used by a MDB    •  Define as standard activation config properties...
New API Features41 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reserved. |
New API features    •  Delivery delay    •  Send a message with async acknowledgement from server    •  JMSXDeliveryCount ...
Delivery delay    •  Allows a JMS client to schedule the future delivery of a message    •  New method on MessageProducer ...
Send a message with async    acknowledgement from server    •  Send a message and return immediately without blocking unti...
Make JMSXDeliveryCount mandatory    •  JMS 1.1 defines an optional JMS defined message       property JMSXDeliveryCount.  ...
Multiple consumers on a topic subscription    •  Allows scalable consumption of messages from a topic subscription        ...
Get involved!    •  Early Draft Already Available    •  Mailing lists, issue tracker and wiki:             –  jms-spec.jav...
Questions & Answers48 | Copyright © 2012, Oracle and/or it’s affiliates. All rights reserved. |
