Understanding Hardware Acceleration on Mobile       Browsers        Ariya Hidayat
Magical Advice                 Use translate3d for hardware                         acceleration
Challenges
Game vs Web
Game                                    Text                                           Textured objects       Animation   ...
Large but Still Bounded
Web Page                  Images           Text
Challenges    Predictable contents (assets)   ✔    Mostly text                           ✔    Mostly images               ...
Browser Rendering
From Wave to Pixels                       Network stack                                  Layout engine                    ...
WebKit Components                                   Render Engine                                       CSS               ...
Platform Abstraction           Network      Unicode      Clipboard          Graphics       Theme        Events           T...
Graphics Abstraction  GraphicsContext       iOS        Android                                    Skia                    ...
SoC = System-on-a-Chip                         CPU   GPU
GPU Workflow               Matrix  Vertices              Rendered   Textured
Optimized for Games                      “Fixed” geometry                      Transformation                      Texture...
Powerful Capabilities http://epicgames.com/technology/epic-citadel   http://www.rage.com/
http://www.trollquotes.org/619-super-spider-bat-troll-quote/
Fundamental Physical Limitations    Memory     - Can’t store too much stuff    Speed     - Quad-core CPU can do certain ...
Traffic Congestion
Primitive Drawing
Path is Everything                     Triangle   Rectangle             Path                     Ellipse         Polygon
Stroke = Outline            Solid   Dashed   Dotted   Textured
Brush = Fill   None        Solid   Gradient   Textured
Gradient = Non-uniform Pixel Values
Drawing Time: Solid vs Gradient       Only border      Solid color fill                                           14x slow...
Path Approximation          Curves                     Polygon
Smooth via Antialiasing                          Multiple levels of transparency                                        Pe...
Shadow  Involved pixel “blending”   Often obstructed
Drawing Time: Solid vs Blur Shadow                                              20x slower  Solid shadow                  ...
CSS = Box Modelhttp://www.w3.org/TR/CSS2/zindex.html   Appendix E. Elaborate description of Stacking Contexts
Shadow Abuse     12,000 pixels                     Blur shadow
Transformation     Scaling                            Perspective                 Rotation
Text Rasterization
Font Atlas             Buffer                      Bye
From Simple to Complex                                                  ello!                                             ...
Library Instrumentation                     platformInit                     savePlatformState                     transla...
Painting Performance                       16:24:04.070   D/webcoreglue(    273):   drawContent   11   ms                 ...
Backing Store
Maps       Tiles
Responsive Interface             Rendering                         Processor                                     User inte...
Pinch to Zoom  when you pinch...
Rendering vs Interaction          Rendering   Web Page                User interaction
Checkerboard Pattern                       Poor man’s indicator                         of performance
Progressive Rendering       Fast but blurry                         Crisp but slow
Perceived Responsiveness        User pinches                                            Smooth scaled                     ...
Tiling System                               ....                ....                      CPU                             ...
Tile Transformation        Panning = Translation   Zooming = Scaling
Y U NOposition:fixed
Layer & Compositing
Typical Animation              opacity, movement, scaling, rotation, ...
Principles of Fluid Animation               At the beginning, push as many resources         1               as possible t...
Immediate vs Retained                               At the beginning...                                                   ...
Mechanics of Animation                       “Hey, this is good stuff. Cache it as texture #42.”      Initialization      ...
Elements = Layer
Logical 3-D
Compositing By Force                    -webkit-transform: translateZ(0)                    Not needed for CSS animation! ...
Debugging in Safari        defaults write com.apple.Safari IncludeInternalDebugMenu 1
Compositing Indicators                         Texture (number = upload)                                Composited layer  ...
Avoid Texture Reupload            No reupload                            Upload             Opacity             Position  ...
Examples
Color Transition        @-webkit-keyframes box {            0% { -webkit-transform: background-color: blue; }          100...
Color Transition: The Trick                          Blended with
Prepare and Reuse                          Hide the layer offscreen               Viewport
Timer Latency                                                        Depending on                                         ...
Avoid Overcapacity                              Texture upload                       ....               ....              ...
Wrap-up
Hardware Acceleration       Drawing primitives   Backing stores   Layer & compositing
There is no such  Traditional graphicsprogramming has been  always full of tricks.  It will always be.
Thank You       ariya.hidayat@gmail.com    Office Hour                                 Wed 1:45 PM        ariya.ofilabs.com ...
