Hybrid Apps (Native + Web) via QtWebKit

Hybrid Apps (Native + Web) via QtWebKit SF BAY MEEGO NETWORK JUNE 22, 2011 ARIYA HIDAYAT ENGINEERING DIRECTOR

whoami

Overview

Going Hybrid? Platform Integration Security App Store/ Advanced Technologies Marketplace

WebKit Everywhere Browser DevicesRuntime

~2000 commits/month History 90000 80000 70000 60000Revisions 50000 40000 30000 20000 10000 0 0 1 2 3 4 5 6 7 8 9 10 Years

Extensive Tests ≈ 20,000 tests tests 904 MB the rest 229 MB

Workﬂow quality control 1 Every commit needs to be reviewed 2 Broken commit must be reverted zero-regression policy

Level of Involvement Contributor after 10-20 patches after 80 patches Committer ≈ 150 Reviewer checks in reviewed patches ≈ 90 accept or reject patches

WebKit Reviewers Apple 39 Google 25 Misc 11 1 RIM Nokia 7 7

Components of WebKit DOM CSS WebCore SVG HTML rendering JavaScriptCore WebKit Library

Platform Abstractions Network Unicode Clipboard Graphics Theme Events Thread Geolocation Timer

WebCoreDi erent “Ports” graphicsGraphicsContext Mac Chromium Qt Gtk Skia Cairo CoreGraphics QPainter graphics stack

Web Browsers Arora Demo Browser http://arora.googlecode.com demos/browser

QWebView, QWebPage, QWebFrame QWebView (widget) QWebPage (object) QWebFrame (object) At least one, i.e. the main frame of the page

Using WebView QWebView webView; webView.show(); webView.setUrl(QUrl("http://meego.com"));

Contents via String QWebView webView; webView.show(); webView.setContent("<body>Hello, MeeGo!</body>");

Contents via Resource <RCC> <qresource prefix="/"> <file>content.html</file> </qresource> </RCC>QWebView webView;webView.show();webView.setUrl(QUrl("qrc:/content.html"));

Capture to ImageQWebPage page;QImage image(size, QImage::Format_ARGB32_Premultiplied);image.fill(Qt::transparent);QPainter p(&image);page.mainFrame()->render(&p);p.end();image.save(fileName); http://labs.qt.nokia.com/2009/01/15/capturing-web-pages/

SVG Rasterizer http://labs.qt.nokia.com/2008/08/06/webkit-based-svg-rasterizer/

Search + Preview http://labs.qt.nokia.com/2008/11/04/search-with-thumbnail-preview/

Bridging the Two Worlds

Exposing to the Web worldQWebFrame::addToJavaScriptWindowObject(QString, QObject*) Public functions Object properties Child objects

Exposing to the Web worldpage()->mainFrame()->addToJavaScriptWindowObject("Dialog", new Dialog); class Dialog: public QObject { Q_OBJECT public: Dialog(QObject *parent = 0); public slots: void showMessage(const QString& msg); };

Exposing to the Web world <input type="button" value="Try this" onClick="Dialog.showMessage(You clicked me!)"> instance of public slot Dialog object

Signal and Slot signal foobar.modified.connect(refresh); QObject instance JavaScript function foobar.modified.connect(obj, refresh); any object

Triggering Action from Nativeclass Stopwatch: public QObject{ Stopwatch::Stopwatch(QObject *parent) Q_OBJECT : QObject(parent) , m_index(0)public: { Stopwatch(QObject *parent = 0); QTimer *timer = new QTimer(this); timer->setInterval(1000);signals: connect(timer, SIGNAL(timeout()), SLOT(update())); void tick(int t); timer->start(); }private slots: void update(); void Stopwatch::update() {private: emit tick(m_index++); int m_index; }};

Triggering Action from Native instance of Stopwatch object signal <script> Stopwatch.tick.connect(function(t) { document.getElementById(tick).innerText = t; }); </script>

Coming back to the Native QVariant QWebFrame::evaluateJavaScript(QString) mostly key-value pair (like JavaScript objects)

Other Bridging Solutions Custom network protocol QNetworkAccessManager http://labs.qt.nokia.com/2010/11/16/some-webkit-hybrid-stu /

Platform Integration Menu and Menu Bar Dialogs Application System Access Notiﬁcations

Debugging Web Inspectorsettings()->setAttribute(QWebSettings::DeveloperExtrasEnabled, true);

Deployment O ine Packaging Cache Manifest QtWebKit boilerplate Local Storage Tools PhoneGap AppUp Encapsulator

Real-world Hybrid Apps Ext Designer Sencha Animator

Technologies

Key Technologies

JavaScript

Libraries and Frameworks

Content Editing http://labs.qt.nokia.com/2009/03/12/wysiwyg-html-editor/

Consume Web 2.0http://labs.qt.nokia.com/2009/03/08/creating-a-google-chat-client-in-15-minutes/

Vector Graphics http://raphaeljs.com/polar-clock.html

Canvas-based Game http://ariya.blogspot.com/2010/09/invade-destroy.html

Diagrams & Visualization JavaScript InfoVis Toolkit http://thejit.org/

CSS3 Animations http://mozillademos.org/demos/planetarium/demo.html

GPU FTWAccelerated Composition Element GL texture Movement Transformation matrixhttp://www.webkit.org/blog-ﬁles/leaves/

Sencha Animator

Device Access http://ariya.github.com/js/marblebox/

WebGL for 3-D http://webglsamples.googlecode.com/hg/aquarium/aquarium.html

PhiloGL: WebGL Framework http://senchalabs.github.com/philogl/

Web Inspector


Typical Scenario This is awesome! un t to r f orge ests the t

Test Frameworkspecrunner SpecRunner.html5 specs, 0 failures in 0.013sspecrunner SpecRunner.htmlFAIL: 5 specs, 1 failure in 0.014s Selenium, Watir, Squish Web, JSUnit, Jasmine, QUnit, ...

Headless WebKitif (phantom.state.length === 0) { phantom.state = pizza; phantom.open(http://www.google.com/m/local?site=local&q=pizza+in+new+york);} else { var list = document.querySelectorAll(div.bf); for (var i in list) { console.log(list[i].innerText); } phantom.exit();} http://phantomjs.org

UI Designer

IDE: AKShell

IDE: Cloud9

Recorder and Replayer

Get + Compile

Using git git clone git://git.webkit.org/WebKit.git cd WebKit ≈ 1.2 GB .git

BuildTools/Scripts/build-webkit --qt --debug for “Debug” mode

LaunchTools/Scripts/run-launcher --qt

Conclusion

Today Web technologies are moving really fastVarious frameworks and libraries boost the productivity Hybrid approach helps the migration Tools need to catch-up

Future More bindings to the native world Platinum-grade productivity toolsUbiquitous mesh and cloud solutions

THANK YOU! ariya.hidayat@gmail.com ariya.blogspot.com ariyahidayat
