Skeuomorphs,Databases,and Mobile PerformanceArchitecting for performance with devices & APIsgroups.google.com/group/api-cr...
SKEUOMORPHS
A brief history of architecture
Banister FletcherA History of Architecture
“   Greek columns and their entablatures were at    first entirely of timber, with terra-cotta    decorations in the upper...
Skeuomorphs and metaphors
SkeuomorphA skeuomorph is a design feature found on animitation, pastiche or homage that was necessaryonly to the original...
MetaphorIn cognitive linguistics, conceptual metaphor, orcognitive metaphor, refers to the understandingof one idea, or co...
“   The concepts that govern our thought are not just    matters of the intellect. They also govern our everyday    functi...
DATABASES
A brief history of   ^ architecture
Connected                   Devices Smartphone                   N-tier     Web App                Personal               ...
Domain-specific                         Data APIs PrivateCloud DBs              Caching DBs                               ...
We’ve come back to client-server computing
From the perspective of the mobile client,the Internet is a database.
Is that a skeuomorph or a metaphor?
If the Internet is a database,what have we learned from prior eras aboutarchitecting for performance?
MOBILEPERFORMANCE
The classic client-server problem returns
If the database is slow, the app is slow.
Research shows that people will put up withabout 1.5 seconds between interactions.
More than 3 seconds on averageand they’ll stop using the app.
This is a problem.
Let’s dig into our client-server historyto break it down.
Make the application smarterUse the network intelligentlyOptimize the database aggressively
MAKE THEAPPLICATIONSMARTER
application    What makes the app feel fast to the user?
application    Time to first render    Time to first interaction    Time between interactions
application    Three mutually reinforcing techniques:    Code profiling for performance optimization    Threading/concurre...
application    Use the profiler to see where you’re slow    Write faster code where you see big gains    Run long operatio...
application    Concurrency
application    Anticipation
application    Caching
application    What should you be caching locally?    Security credentials or tokens    Last user session data    MRU (Mos...
application    Issues do remain    Can’t hit local cache on first use of app    Receiving the right shape of data
USE THENETWORKINTELLIGENTLY
network   The radio network is a         high-latency,                limited-resource environment.
network   Speed and battery usage   are both important dimensions of   mobile performance
network   Intermittent usage of the radio for   pingbacks   keep-alives   analytics   screen rotations   will slow you dow...
network   A better approach:   Bundling, piggybacking, and pipelining
network                      Connection                       Tail                        setup                         ti...
network   Intermittent analytics and keep-alives                   90 sec of radio use and battery burn   Piggybacking on ...
network   API calls in series     200 ms     200 ms   200 ms    200 ms   200 ms                         1000 ms   API pipe...
Bundling loosely-related requests togetherPiggybacking secondary intermittent trafficPipelining requests to maximize throu...
OPTIMIZE THEDATABASEAGGRESSIVELY
database    What were our old    database optimization tricks    that we can apply to Internet data?
database    Stored Procedures    Queueing    Denormalization    Result Sets
database  What is a Stored Procedure in this world?  Server-side code that executes complex operations  Ones that should h...
database  Where does a Stored Procedure run in this world?
database  Where does a Stored Procedure run in this world?  Probably in a cloud
database    Once you’ve built this architectural layer    you gain a lot of control
database    You can deal with    queueing, denormalization, and manage    result sets properly.
database  Queueing enables you to break the  request/response pair into separate pieces  You may even be able to tell the ...
database  Denormalization refers to writing multiple indexes  in order to optimize query performance  Where your app relie...
database  Managing result sets to save bandwidth and  response time means limiting cursor size by default  This can be com...
database  Managing result sets to save processor time for the  client is an option as well.  What would happen if you coul...
XML in Javascriptvar parseXml;if (typeof window.DOMParser != "undefined"){     parseXml = function(xmlStr) {         retur...
JSON in Javascriptvar json = {"result":true,"count":1},    obj = JSON.parse(json);alert(obj.count);
INCLOSING
There are a few things we canborrow from the pastto help us right now
Make the application smarterUse the network intelligentlyOptimize the database aggressively
What did you decide about the statement“The internet is a database”?
Carpentry in marble?or cognitive tool?
Skeuomorph?or metaphor?
groups.google.com/group/api-craft
THANK YOUQuestions and ideas to:@sramjigroups.google.com/group/api-craft
