CSC103 - Object Oriented         Programming             Lecture 19          Engr. M. Anwar-ul-Haq             11th May, 2...
Engr. Anwar, Foundation University (FUIEMS), Islamabad   2
Virtual Functions                       Function Call Binding•       Connecting a function call to a function body is call...
Virtual Functions     Normal Member Functions Accessed with Pointers#include <iostream>using namespace std;class Base {pub...
Virtual Functions     Normal Member Functions Accessed with Pointersvoid main() {       Derv1 dv1;     // object of derive...
Virtual Functions    Normal Member Functions Accessed with Pointers•   Refer to the program given in the last two slides. ...
Virtual Functions     Virtual Member Functions Accessed with Pointers#include <iostream>using namespace std;class Base {pu...
Virtual Functions     Virtual Member Functions Accessed with Pointersvoid main() {       Derv1 dv1;     // object of deriv...
Virtual Functions    Virtual Member Functions Accessed with Pointers•   Refer to the program given in the last two slides....
Abstract Base Classes and                     Concrete Classes•       An abstract class is often defined as one that will ...
Abstract Base Classes and               Concrete Classes …•   If a class is derived from a class with a pure virtual    fu...
Polymorphism•       Poly mean many and morph means forms – thus polymorphism        means to take up many forms.•       C+...
Exploiting Inheritance• What can be done with different classes related by  inheritance?   – Any child of a class, can be ...
How does polymorphism work?• When a base class pointer is used to  store one of it’s children, any method  declared in the...
How does polymorphism work?• By default when a function is called using the  base class pointer, the method called will be...
Polymorphism Defined• The ability to take on different forms.• Ability for different objects to interpret functions  diffe...
Polymorphism• - extending inheritance• Polymorphism means using the same syntax to do  different things depending on the c...
Polymorphism• Why Is this Important?  – Allow subclasses to be treated like instances of their    super classes  – Flexibl...
Using Base Class Pointerclass Box   {    };class Carton : public Box   { };class Contents   { };class CerealPack : public ...
Using Base Class PointerCerealPack breakfast;//You can store the address of the breakfast object in  any base pointerCarto...
Using Base Class Pointerclass Box  {   };class Carton : public Box  { };class ToughPack : public Box  { };              En...
Using Base Class PointerCarton acarton(10, 10 , 5);Box * pBox=&acarton;ToughPack hardcase(2, 2, 2)pBox=&hardcase;• The poi...
Polymorphism• Static and dynamic binding   – In most programming languages and in most cases the     variables are bound t...
Virtual Functions• A virtual function is a function that is declared with  the keyword virtual in a base class and then re...
Virtual Functions• Used to support polymorphism with pointers and  references• Ensures derived class function definition i...
Polymorphism   Ability to manipulate derived objects using the interface     defined in the base class• Example:   class E...
Example   Employee *ep;   ep = new SalariedEmployee;   Ep->CalcPay();• Which function is called?  – The function in Employ...
Polymorphism   Ability to manipulate derived objects using the interface     defined in the base class• Example:   class E...
Example   Employee *ep;   ep = new SalariedEmployee;   ep->CalcPay();• Which function is called?  – The function in Salari...
Example: Virtual Functions  class Employee {  public:    virtual void CalcPay ();  };  class SalariedEmployee :public Empl...
ExamplesEmployee *p0 = new Employee;Employee *p1 = new SalariedEmployee;p0->CalcPay(); // calls employee::CalcPay()p1->Cal...
Requirements for Virtual                Functions• Not every function can be declared virtual.• Following functions cannot...
Requirements for Virtual                 Functions• For a function to behave virtually you must declare  and define it wit...
Requirements for Virtual Functions• If you try to use different parameters for  virtual function then the virtual function...
Combinations of virtual and non-            virtual functions• Non-virtual function can call virtual function   class Empl...
Examplevoid Employee::Display(){ cout<<“pay of emp”;   CalcPay();};void SalariedEmployee::Display(){   cout<<“pay of salri...
Access Specifers in Virtual Functions:                       Exampleclass Box{   public:        Box();        void showVol...
class ToughPack:: public Box{   public:        ToughPack();   protected:        double volume() const;};Double ToughPack :...
Using References with Virtual                     Functionsclass Biomolecule{        virtual int Mweight();        .      ...
Polymorphism vs. Inheritance• Inheritance is required in order to achieve  polymorphism (we must have class hierarchies). ...
Virtual functions  • Function of derived class is called even if you have    only a pointer to the base class             ...
How a virtual function worksShape vtable                                        Circle vtablevfunc1 addr                  ...
What is the penalty of a virtual              function?• Space:  – one vtable per class with virtual function(s)  – one po...
Pure virtual function• Pure virtual function   – Function intentionally undefined   – Same penalty as regular virtual func...
class A {public:                      Virtual Functions   A () {cout<<" A";}                                        • Used...
class A {public:              Virtual Functions   void x() {cout<<"A:x";};                                  •   virtual vo...
class A {public:         Pure Virtual Functions   virtual void x() = 0;   virtual void y() = 0;};                         ...
Early binding• The term early binding means resolving a function  call at compile-time.• Examples of early binding include...
Late binding• The term late binding means resolving a function call  at run-time.• Late binding is used when some of the i...
Summary: Tips on Polymorphism• Push common code and variables up into base classes• Use public inheritance for polymorphis...
