iHome Security & Automation System
Home Automation System Home Automation  is a field specializing in the specific automation requirements of  homes and in t...
Home Automation <ul><li>HAS can also be defined as remote or automatic control of things around the home.  </li></ul><ul><...
Home Automation <ul><li>HAS can also be defined as remote or automatic control of things around the home.  </li></ul><ul><...
iHome Security & Automation System
Smart Home has been “coming” for 30 years – Why Now..??  <ul><li>Emergence of wireless technologies for home automation so...
iHome Security & Automation System
Home Automation Systems <ul><li>Security </li></ul><ul><li>Heating, Ventilation and Air Conditioning (HVAC) </li></ul><ul>...
The elements of a domotics system are- <ul><li>Controllers </li></ul><ul><li>Sensors  </li></ul><ul><li>Actuators </li></u...
Hardware Overview <ul><li>The automation system will use four levels of ‘nodes’ to control different aspects of the automa...
iHome Security & Automation System iHome Automation Overall Flowchart
Hardware Description-Level 0 Nodes <ul><li>Features controlled by Level 0 nodes are mostly sensors, such as sound, tempera...
iHome Security & Automation System iHome Automation Overall Flowchart
iHome Security & Automation System L1 Device Interface <ul><li>Eight TTL Output Ports (5V) </li></ul><ul><li>Four TTL Inpu...
<ul><li>Level 1 nodes connect to the system by either X10 cable or wirelessly.  </li></ul><ul><li>Level 1 nodes control Le...
iHome Security & Automation System iHome Automation Overall Flowchart
<ul><li>The Base Station bridges the central server to the L1 node network.  </li></ul><ul><li>It connects to the central ...
iHome Security & Automation System MCU TI MSP430F149 Touch Sensors RS-485 Transceiver 1 Mb Flash LCD Display USB Endpoint ...
Hardware Description-Level 2 Nodes <ul><li>Level 2 nodes are designed for audio / communications, and have no user interfa...
A standard 8P8C (often called RJ45) Ethernet connector. iHome Security & Automation System
iHome Security & Automation System MCU Atmel AT91SAM7S256 (ARM7TDMI Core) RJ45 Connector MP3/WAV Encoder/Decoder VLSI1003 ...
iHome Security & Automation System iHome Automation Overall Flowchart
Hardware Description-Level 3 Nodes <ul><li>Level 3 nodes may or may not (depending on time constraints) be included in hom...
iHome Security & Automation System iHome Automation Overall Flowchart
Interconnections <ul><li>By wire :  </li></ul><ul><li>DSL(digital subscriber line) </li></ul><ul><li>Optical fiber cable  ...
Technology Transmission medium Transmission speed Maximum distance to the device Ethernet Fibre optics 10 Mbit/s – 1 Gbit/...
What is X10? <ul><li>X10 is a communications &quot;language&quot; that allows compatible products to talk to each other us...

X10 Addressing Code Dials
Examples X10 PRO Receiver Modules   Wall Switch Fixture Module Lamp Module
eHome Concept <ul><li>Controls home appliances through a WML(Wireless Markup Language) browser on a remote cellular phone ...
iHome Security & Automation System WML Browser Screens
iHome Security & Automation System
iHome Security & Automation System
iHome Security & Automation System
INTRODUCTION  OF <ul><li>S MARTPHONES </li></ul>
iHome Security & Automation System
iHome Security & Automation System
Bibliography <ul><li>www.smarthome.com </li></ul><ul><li>www.x10.com </li></ul><ul><li>www.google.com </li></ul>iHome Secu...
iHome Security & Automation System ?
