Graph Databases and the Future of Large-Scale
          Knowledge Management



                  Marko A. Rodriguez
     ...
Abstract

Modern day open source and commercial graph databases can store on the
order of 1 billion relationships with som...
Outline

• The Relational Database vs. the Graph Database

• The World Wide Web vs. the Web of Data




                  ...
Outline

• The Relational Database vs. the Graph Database

• The World Wide Web vs. the Web of Data




                  ...
Our Make Believe World

• Marko is a human and Fluffy is a dog.

• Marko and Fluffy are good friends.




                  ...
Our World Modeled in a Relational Database

    ID      Name     Type    Legs     Fur              ID2            ID2

   ...
Our World Modeled in a Graph Database

           Human                                          Dog



            type  ...
Extending our Make Believe World

• Marko is a human and Fluffy is a dog.

• Marko and Fluffy are good friends.

• Human and...
Our Extended World Modeled in a Relational Database

     ID      Name     Type    Legs   Fur       ID2          ID2      ...
Our Extended World Modeled in a Graph Database
                                         Mammal


                         ...
Extending our Extended Make Believe World
• Marko is a human and Fluffy is a dog.

• Marko and Fluffy are good friends.

• H...
Our Extended Extended World Modeled in a
              Relational Database

   ID      Name     Type     Legs   Fur       ...
Our Extended Extended World Modeled in a
             Graph Database
                                   Mammal


         ...
The Graph as the Natural World Model
• The world is inherently (or perceived as) object-oriented.

• The world is filled wi...
The Graph as the Natural Programming Model

• High-level computer languages are object-oriented.

• Nearly no impedance mi...
The Relational Database vs. the Graph Database

• A relational database’s (e.g. MySQL, PostgreSQL, Oracle) data model
  is...
SQL vs. SPARQL

SELECT OTY.Name FROM Object_Table AS OTX,
        Object_Table AS OTY, Friendship_Table WHERE
   OTX.Name ...
Outline

• The Relational Database vs. the Graph Database

• The World Wide Web vs. the Web of Data




                  ...
Internet Address Spaces

• The Uniform Resource Identifier (URI) is the superclass of the Uniform
  Resource Locator (URL) ...
The Uniform Resource Locator
• The set of all URLs is the address space of all resources that can be
  located and retriev...
The Uniform Resource Name

• The set of all URNs is the address space of all resources within the urn:
  namespace.
    ur...
The Uniform Resource Identifier
• The URI address space is an infinite space for all Internet resources.
    http://markorod...
The “Uniform Resource Graph”

• We can denote where something is, what something is, but how do we
  denote how something ...
The World Wide Web
• The World Wide Web is primarily concerned with the Hyper-Text
  Transfer Protocol (HTTP) and with ret...
The Web of Data

• The Web of Data is primarily concerned with URIs. If the World Wide
  Web is the web of files, the Web o...
The Resource Description Framework

• The Resource Description Framework (RDF) is the standard for
  representing the rela...
lanl:Mammal


                                    rdfs:subClassOf                 rdfs:subClassOf


                   lan...
The RDF Data Model and its Serializations

• RDF is a data model. As such, there exists many serializations (encoding
  fo...
The Web of Data is a Distributed Database

• The URI address space is distributed.

• URIs can denote datum.

• RDF denote...
The World Wide Web vs. the Web of Data

       Web Server                         Web Server




           HTML        hr...
The Current Web of Data
                               homologenekegg                     projectgutenberg
               ...
The Current Web of Data
data set           domain       data set           domain        data set              domain
audi...
Cultural Differences that are Leading to a New World of
          Large-Scale Knowledge Management

• Relational databases ...
Conclusion

• Thank you for your time...
    My homepage: http://markorodriguez.com
    Neno/Fhat: http://neno.lanl.gov
  ...
Upcoming SlideShare
Loading in...5
×

Graph Databases and the Future of Large-Scale Knowledge Management

4,318

Published on

Published in: Technology, Education, Business
0 Comments
10 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
4,318
On Slideshare
0
From Embeds
0
Number of Embeds
1
Actions
Shares
0
Downloads
207
Comments
0
Likes
10
Embeds 0
No embeds

No notes for slide

Transcript of "Graph Databases and the Future of Large-Scale Knowledge Management"

  1. 1. Graph Databases and the Future of Large-Scale Knowledge Management Marko A. Rodriguez T-5, Center for Nonlinear Studies Los Alamos National Laboratory http://markorodriguez.com April 8, 2009
  2. 2. Abstract Modern day open source and commercial graph databases can store on the order of 1 billion relationships with some databases reaching the 10 billion mark. These developments are making the graph database practical for applications that require large-scale knowledge structures. Moreover, with the Web of Data standards set forth by the Linked Data community, it is possible to interlink graph databases across the web into a giant global knowledge structure. This talk will discuss graph databases, their underlying data model, their querying mechanisms, and the benefits of the graph data structure for modeling and analysis. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  3. 3. Outline • The Relational Database vs. the Graph Database • The World Wide Web vs. the Web of Data Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  4. 4. Outline • The Relational Database vs. the Graph Database • The World Wide Web vs. the Web of Data Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  5. 5. Our Make Believe World • Marko is a human and Fluffy is a dog. • Marko and Fluffy are good friends. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  6. 6. Our World Modeled in a Relational Database ID Name Type Legs Fur ID2 ID2 0001 Marko Human 2 false 0001 0002 0002 Fluffy Dog 4 true 0002 0001 Object_Table Friendship_Table Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  7. 7. Our World Modeled in a Graph Database Human Dog type type 0001 friend 0002 name name legs fur legs fur 2 Marko false 4 Fluffy true Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  8. 8. Extending our Make Believe World • Marko is a human and Fluffy is a dog. • Marko and Fluffy are good friends. • Human and dog are a subclass of mammal. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  9. 9. Our Extended World Modeled in a Relational Database ID Name Type Legs Fur ID2 ID2 Type1 Type2 0001 Marko Human 2 false 0001 0002 Human Mammal 0002 Fluffy Dog 4 true 0002 0001 Dog Mammal Object_Table Friendship_Table Subclass_Table Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  10. 10. Our Extended World Modeled in a Graph Database Mammal subclassof subclassof Human Dog type type 0001 friend 0002 name name legs fur legs fur 2 Marko false 4 Fluffy true Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  11. 11. Extending our Extended Make Believe World • Marko is a human and Fluffy is a dog. • Marko and Fluffy are good friends. • Human and dog are a subclass of mammal. • Fluffy peed on the carpet. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  12. 12. Our Extended Extended World Modeled in a Relational Database ID Name Type Legs Fur ID2 ID2 Type1 Type2 0001 Marko Human 2 false 0001 0002 Human Mammal 0002 Fluffy Dog 4 true 0002 0001 Dog Mammal 0003 My_Rug Carpet N/A N/A Friendship_Table Subclass_Table Object_Table ID1 ID2 0002 0003 Pee_Table Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  13. 13. Our Extended Extended World Modeled in a Graph Database Mammal subclassof subclassof Human Dog Carpet type type type 0001 friend 0002 peedOn 0003 name name name legs fur legs fur 2 Marko false 4 Fluffy true My_Rug Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  14. 14. The Graph as the Natural World Model • The world is inherently (or perceived as) object-oriented. • The world is filled with objects and relations among them. • The multi-relational graph is a very natural representation of the world. undirected single-relational graph x z directed single-relational graph x z directed multi-relational graph x y z Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  15. 15. The Graph as the Natural Programming Model • High-level computer languages are object-oriented. • Nearly no impedance mismatch between the multi-relational graph and the programming object. • It is easy to go from graph database to in-memory object. Human marko = new Human(); marko.name = "Marko"; marko.addFriend(fluffy); marko.setHasFur(false); marko.setLegs(2); Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  16. 16. The Relational Database vs. the Graph Database • A relational database’s (e.g. MySQL, PostgreSQL, Oracle) data model is a collection interlinked tables. • A graph database’s (e.g. OpenSesame, AllegroGraph, Neo4j) data model is a multi-relational graph. Relational Database Graph Database 127.0.0.1 127.0.0.2 Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  17. 17. SQL vs. SPARQL SELECT OTY.Name FROM Object_Table AS OTX, Object_Table AS OTY, Friendship_Table WHERE OTX.Name = "Marko" AND Friendship_Table.ID = OTY.ID AND Friendship_Table.Friend = OTX.ID; SELECT ?z WHERE { ?x name "Marko"^^xsd:string . ?y friend ?x . ?y name ?z } Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  18. 18. Outline • The Relational Database vs. the Graph Database • The World Wide Web vs. the Web of Data Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  19. 19. Internet Address Spaces • The Uniform Resource Identifier (URI) is the superclass of the Uniform Resource Locator (URL) and Uniform Resource Name (URN). Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  20. 20. The Uniform Resource Locator • The set of all URLs is the address space of all resources that can be located and retrieved on the Web. URLs denote where a resource is. http://markorodriguez.com/index.html ∗ Domain name server (DNS): markorodriguez.com → 216.251.43.6 ∗ http:// means GET at port 80, ∗ /index.html means the resource to get at that Internet location. Web Server index.html markorodriguez.com 216.251.43.6 Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  21. 21. The Uniform Resource Name • The set of all URNs is the address space of all resources within the urn: namespace. urn:uuid:bd93def0-8026-11dd-842be54955baa12 urn:issn:0892-3310 urn:doi:10.1016/j.knosys.2008.03.030 • Named resources need not be retrievable through the Web. • URNs denote what a resource is. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  22. 22. The Uniform Resource Identifier • The URI address space is an infinite space for all Internet resources. http://markorodriguez.com/index.html urn:issn:0892-3310 ftp://markorodriguez.com/private/markos_secrets.txt http://www.lanl.gov#fluffy • Imporant: URIs can denote concepts, instances, and datum. lanl:fluffy lanl:fluffy_legs Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  23. 23. The “Uniform Resource Graph” • We can denote where something is, what something is, but how do we denote how something relates to something else? • How can we denote what something means, where meaning is determined by its place within a larger relational structure? URIs are like words. They denote things in the real or imaginary world. Linking URIs is like defining words. Similar to how a dictionary defines words in terms of other words. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  24. 24. The World Wide Web • The World Wide Web is primarily concerned with the Hyper-Text Transfer Protocol (HTTP) and with retrievable resources in the URL address space. • These retrievable resources are files: HTML documents, images, audio, etc. The “web” is created when HTML documents contain URLs. http://markorodriguez.com/ index.html href Resume.html href Home.html href Research.html Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  25. 25. The Web of Data • The Web of Data is primarily concerned with URIs. If the World Wide Web is the web of files, the Web of Data is the web of data. In other words, for the World Wide Web, the level of granularity is the retrievable file. For the Web of Data, it is the information in that file. Moreover, this information is not necessarily contained in a file. There existence is predicated on their URI. Their meaning is predicated on their relationship to other URIs. The web of URIs is the Web of Data. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  26. 26. The Resource Description Framework • The Resource Description Framework (RDF) is the standard for representing the relationship between URIs and literals (e.g. float, string, date time, etc.). I would have preferred the name “Uniform Resource Graph” (URG). • Relationships are directed, labeled links between URIs. A subject URI points to an object URI or literal by means of a predicate URI. subject predicate object lanl:marko foaf:knows lanl:fluffy foaf:name foaf:name "Marko A. Rodriguez"^^xsd:string "Fluffy P. Everywhere"^^xsd:string Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  27. 27. lanl:Mammal rdfs:subClassOf rdfs:subClassOf lanl:Human lanl:Dog rdf:type rdf:type lanl:marko foaf:knows lanl:fluffy foaf:knows lanl:fur lanl:legs lanl:fur lanl:legs foaf:name foaf:name "false"^^xsd:boolean "2"^^xsd:integer "true"^^xsd:boolean "4"^^xsd:integer "Marko A. Rodriguez"^^xsd:string "Fluffy P. Everywhere"^^xsd:string Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  28. 28. The RDF Data Model and its Serializations • RDF is a data model. As such, there exists many serializations (encoding formats) of that model. • RDF/XML is not RDF. It is a serialization of RDF. It is smart to, at all costs, avoid learning RDF/XML as it is an unintuitive standard. Other serializations include: N-TRIPLE, N3, TRIX, TRIG, ... <http://www.lanl.gov#marko> <http://www.w3.org/1999/02/22-rdf-syntax-ns#type> <http://www.lanl.gov#Human> . <http://www.lanl.gov#marko> <http://xmlns.com/foaf/0.1/name> "Marko A. Rodriguez"^^<http://www.w3.org/2001/XMLSchema#string> . <http://www.lanl.gov#marko> <http://www.lanl.gov#legs> "2"^^<http://www.w3.org/2001/XMLSchema#integer> . <http://www.lanl.gov#marko> <http://www.lanl.gov#fur> "false"^^<http://www.w3.org/2001/XMLSchema#boolean> . <http://www.lanl.gov#marko> <http://xmlns.com/foaf/0.1/knows> <http://www.lanl.gov#fluffy> . Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  29. 29. The Web of Data is a Distributed Database • The URI address space is distributed. • URIs can denote datum. • RDF denotes the relationships URIs. • The Web of Data’s foundational standard is RDF. • Therefore, the Web of Data is a distributed database. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  30. 30. The World Wide Web vs. the Web of Data Web Server Web Server HTML href HTML 127.0.0.1 127.0.0.2 Web Server Graph Database RDF foaf:knows 127.0.0.1 127.0.0.2 Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  31. 31. The Current Web of Data homologenekegg projectgutenberg symbol homologenekegg libris projectgutenberg cas symbol bbcjohnpeel libris unists diseasome dailymed w3cwordnet chebi hgnc pubchem eurostat mgi geneid omim wikicompany geospecies cas bbcjohnpeel diseasome dailymed drugbank worldfactbook reactome pubmed unists magnatune opencyc w3cwordnet uniparc linkedct chebi freebase taxonomy uniref uniprot geneontology interpro hgnc pubchem eurostat pdb yago umbel pfam mgi dbpedia omim bbclatertotpgovtrack wikicompany geospecies prosite prodom flickrwrappr geneid opencalais reactome uscensusdata drugbank worldfactbook lingvoj linkedmdb surgeradio magnatune pubmed virtuososponger opencyc rdfbookmashup uniparc freebase swconferencecorpus geonames musicbrainz myspacewrapper linkedct dblpberlin uniprot pubguide taxonomy revyu interpro uniref geneontologyjamendo bbcplaycountdata rdfohloh pdb umbel yago semanticweborg siocsites riese pfam dbpedia bbclatertotp govtrack foafprofiles dblphannover openguides audioscrobbler prosite bbcprogrammes prodom crunchbase flickrwrappropencalais doapspace uscensusdata flickrexporter surgeradio budapestbme qdos lingvoj linkedmdb semwebcentral virtuososponger eurecom ecssouthampton pisa dblprkbexplorer newcastle rdfbookmashup geonames musicbrainz rae2001 eprints irittoulouse laascnrs acm citeseer swconferencecorpus myspacewrapper ieee dblpberlin pubguide resex ibm revyu jamendo rdfohloh bbcplaycountdata semanticweborg siocsites riese foafprofiles openguides audioscrobbler bbcprogrammes dblphannover crunchbase Risk Symposium – Santa Fe, New Mexico – April 8, 2009 doapspace flickrexporter qdos
  32. 32. The Current Web of Data data set domain data set domain data set domain audioscrobbler music govtrack government pubguide books bbclatertotp music homologene biology qdos social bbcplaycountdata music ibm computer rae2001 computer bbcprogrammes media ieee computer rdfbookmashup books budapestbme computer interpro biology rdfohloh social chebi biology jamendo music resex computer crunchbase business laascnrs computer riese government dailymed medical libris books semanticweborg computer dblpberlin computer lingvoj reference semwebcentral social dblphannover computer linkedct medical siocsites social dblprkbexplorer computer linkedmdb movie surgeradio music dbpedia general magnatune music swconferencecorpus computer doapspace social musicbrainz music taxonomy reference drugbank medical myspacewrapper social umbel general eurecom computer opencalais reference uniref biology eurostat government opencyc general unists biology flickrexporter images openguides reference uscensusdata government flickrwrappr images pdb biology virtuososponger reference foafprofiles social pfam biology w3cwordnet reference freebase general pisa computer wikicompany business geneid biology prodom biology worldfactbook government geneontology biology projectgutenberg books yago general geonames geographic prosite biology ... Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  33. 33. Cultural Differences that are Leading to a New World of Large-Scale Knowledge Management • Relational databases tend to not maintain public access points. • Relational database users tend to not publish their schemas. • Web of Data graph databases maintain public access points called SPARQL end-points. • Web of Data graph databases tend to reuse and extend public schemas called ontologies. Risk Symposium – Santa Fe, New Mexico – April 8, 2009
  34. 34. Conclusion • Thank you for your time... My homepage: http://markorodriguez.com Neno/Fhat: http://neno.lanl.gov Collective Decision Making Systems: http://cdms.lanl.gov Faith in the Algorithm: http://faithinthealgorithm.net MESUR: http://www.mesur.org Risk Symposium – Santa Fe, New Mexico – April 8, 2009
