Reverse Engineering     Architectural Feature Models                            Case Study:      software architect       ...
Case Study: FraSCAti• Open source implementation of Service Component Architecture (SCA)    •   An OASIS’s standard progra...
FraSCAti Extensible Architecture in SCA (excerpt)                                              3
What we want : FraSCAti « à la carte »• 256Kb   FraSCAti reflective kernel            • API + membrane controllers• 2,4Mb ...
“the ability of a system to be  efficiently  extended, changed, customized  or configured for use in a  particular context...
Managing variability   of software systemsmodeling the variability and managing its evolution        sound basis    automa...
How to reverse engineer the variability       model of an architecture?Variability Model          Architecture            ...
Defacto standard for modeling variabilityFormal semantics, reasoning techniques, tools                                    ...
Feature Model• Hiearchy of Features + Variability (incl. constraints)• Compact representation of a set of configurations  ...
Feature Model                                                             FraSCAti Architecture FM1                       ...
Set of Safe               Scope is                                                              Variants                  ...
Illegal Variant                  12
Set of Safe                  Scope is                                                           Variants                  ...
Unused flexibility                     14
How to obtain the Feature Model   of FraSCAti Architecture?            FM1                                   FraSCAti     ...
Variability Modeling: Pros and Cons  - Error-prone                     - Documentation of Software Artefacts  - Time Consu...
Variability Modeling:Human Vs Machine?                        17
Extraction Process                          Software                          Artefacts                                   ...
Extraction Process                 Software                 Artefacts                             Variability             ...
Automated Extraction150%: rough over                  Software                                    Mapping betweenapproxima...
Projection by Example  FMFull     FMArch150                            FtAggregation                                FMPlug...
22
Extraction Process                 Software                 Artefacts                             Variability             ...
Consistency of the Extracted Feature Model?                              50 features,                      more than 106 c...
FMArch Enforced                                                                 FMSA            Software      Architectura...
Reconciliation of Feature Models• Vocabulary differs  – 32 “common” features automatically detected  – 5 manual correspond...
Lessons Learned• The gap between the two feature models is  manageable but reconciliation is time consuming• Extraction pr...
Practical Solution: FAMILIARhttps://nyx.unice.fr/projects/familiar/                                          28
Summary• Reverse Engineering the Variability Model of An  Architecture   – Reverse Engineering the Feature Model of FraSCA...
Current and ongoing work• Feature Model Differences• Evolution of Feature Models and FraSCAti• Applicability to other soft...
Feature Model Differences           Submitted to CAiSE’12     Syntactic differences do not scale                          ...
Evolution of Feature Models and FraSCAti                                                                                  ...
Managing variability   of software systemsmodeling the variability and managing its evolution        sound basis    automa...
?http://frascati.ow2.orghttps://nyx.unice.fr/projects/familiar/   34
