Smart Grid for the CSO Jack Danahy Co-Author : The Smart Grid Security Blog October, 2009

Setting the Stage Drivers for an Evolution in Grid infrastructure Introducing the Smart Grid Smart Grid Risks Common Smart Grid Elements and Implications Growing Resources for Smart Grid Content A Simple Smart Grid Checklist Conclusion and Questions Agenda

Setting the Stage

Drivers for an Evolution in Grid infrastructure

Introducing the Smart Grid

Smart Grid Risks

Common Smart Grid Elements and Implications

Growing Resources for Smart Grid Content

A Simple Smart Grid Checklist

Conclusion and Questions

Who would recognize their brainchild? Alexander Graham Bell Father of the Telephone Network Thomas Alva Edison Father of the Grid ( and snappy dresser ) ?

Would today’s phone system ring a bell? Independent providers of services to individual consumers International, regional, national, and local carriers Multiple devices/lines/types per household/business Configurable value-added services Voicemail Text messaging Variable pricing Cell phone as multimedia content-delivery platform Heterogeneous transmission media Traditional copper Cellular VOIP Fiber optic Market-based competition on rates/services/satisfaction Img courtesy mgraves.org then now

Independent providers of services to individual consumers

International, regional, national, and local carriers

Multiple devices/lines/types per household/business

Configurable value-added services

Voicemail

Text messaging

Variable pricing

Cell phone as multimedia content-delivery platform

Heterogeneous transmission media

Traditional copper

Cellular

VOIP

Fiber optic

Market-based competition on rates/services/satisfaction

Grid changes would be much less shocking Major Generation Platforms Power producers Transmission and Distribution Networks and Infrastructure Power management Load balancing and predicting Outage and fail-over protections Regional Regulated Utilities Power to homes/businesses Technology-enabled Not technology-driven img courtesy www.blackhillsenergy.com /customers/lingo/ then now same

Major Generation Platforms

Power producers

Transmission and Distribution Networks and Infrastructure

Power management

Load balancing and predicting

Outage and fail-over protections

Regional Regulated Utilities

Power to homes/businesses

Technology-enabled

Not technology-driven

While the usage profile has changed completely Consumption has risen drastically Power quality has become a big issue Power pricing has stabilized A majority of new technologies require substantial additional power There is no slackening of consumption in sight

Consumption has risen drastically

Power quality has become a big issue

Power pricing has stabilized

A majority of new technologies require substantial additional power

There is no slackening of consumption in sight

What’s wrong with that? The Brittle Grid Grid element Interdependence produces cascading failures Volatility in Energy Costs vary widely for generation fuels Regional conflicts impact fuel price and supply Political pressure to decrease reliance on foreign sources Growing Environmental Impacts Carbon emissions facing public scrutiny and federal/international regulation Increases in traditional generation facilities face local resistance Customer Dissatisfaction Seeking information and flexibility Creating opportunities for new services, revenue, and products img courtesy NOAA Northeast Blackout 2003

The Brittle Grid

Grid element Interdependence produces cascading failures

Volatility in Energy

Costs vary widely for generation fuels

Regional conflicts impact fuel price and supply

Political pressure to decrease reliance on foreign sources

Growing Environmental Impacts

Carbon emissions facing public scrutiny and federal/international regulation

Increases in traditional generation facilities face local resistance

Customer Dissatisfaction

Seeking information and flexibility

Creating opportunities for new services, revenue, and products

Who wants what? A Bidirectional Network A Smarter Infrastructure creates a new generation of Prosumers , producing and consuming energy in a balanced and equitable system to the benefit of customers and utilities alike Customers Demand more information about use and efficiency Are more environmentally sensitized to energy use Want more control over usage rates and schedule Will generate power to sell back to the grid Demand involvement in the evolution of the grid Utilities Must reduce the cost to serve and support customers Are driven to adapt to new technologies Must meet new expectations for services Seek to monetize deployment of new energy services Experiencing massive operations transformation

Demand more information about use and efficiency

Are more environmentally sensitized to energy use

Want more control over usage rates and schedule

Will generate power to sell back to the grid

Demand involvement in the evolution of the grid

Must reduce the cost to serve and support customers

Are driven to adapt to new technologies

Must meet new expectations for services

Seek to monetize deployment of new energy services

Experiencing massive operations transformation

A Smarter Grid IS coming : market forces demand it Expectations of Financials Markets Regulatory & Policy Changes Technological Advancements Customer Expectations Aging Assets & Workforce Dynamics Volatile Energy / Fuel Costs Security Environment & Climate

So what is a Smart Grid? A future power delivery grid that meets the needs of the next generation of Americans: Enable active participation by consumers Accommodate all generation and storage options Enable new products, services and markets Provide power quality for the range of needs in a digital economy Optimize asset utilization and operating efficiency Anticipate and respond to system disturbances in a self-healing manner Operate resiliently against physical and cyber attacks, and natural disasters

A future power delivery grid that meets the needs of the next generation of Americans:

Enable active participation by consumers

Accommodate all generation and storage options

Enable new products, services and markets

Provide power quality for the range of needs in a digital economy

Optimize asset utilization and operating efficiency

Anticipate and respond to system disturbances in a self-healing manner

Operate resiliently against physical and cyber attacks, and natural disasters

What does a Smart Grid look like? Img courtesy: www.smartgrid.epri.com

The Smart Grid is NOT without risks Risk to Critical Infrastructure Inconsistent information sharing and collaboration among stakeholders Private sector controls over 90% of critical infrastructures High degree of social, economic dependence on digital systems Deperimeterization and new customer touch points into networks Uneven application of security engineering to increasingly complex systems Growing capability of adversaries and growing number of exploits

Security challenges from/for the new Smart Grid Complexity : As systems are added and increase functionality, security is more difficult to address Connectivity : Increasing connection to previously isolated systems and networks expands the threat surface Internetworking: Connections between networks permit more rapid spread of any corruption or breach Communications Dependency : Reliance on networking technologies introduces new risk based on network stability Confidentiality : Critical and sometimes private data drives the “smart” in Smart Grid, creating a new area of concern

Complexity : As systems are added and increase functionality, security is more difficult to address

Connectivity : Increasing connection to previously isolated systems and networks expands the threat surface

Internetworking: Connections between networks permit more rapid spread of any corruption or breach

Communications Dependency : Reliance on networking technologies introduces new risk based on network stability

Confidentiality : Critical and sometimes private data drives the “smart” in Smart Grid, creating a new area of concern

Where are specific areas of concern? Img courtesy: www.smartgrid.epri.com System security Vulnerable software Lack of access control Mis-configuration of options Data Vulnerability Weak/No encryption Inappropriate storage Installation of malcode Potential Fraud Invalid credentials Weak authorization Insufficient tamper protection Downtime Denial of service risk System corruption o o o o o o o o o o o

System security

Vulnerable software

Lack of access control

Mis-configuration of options

Data Vulnerability

Weak/No encryption

Inappropriate storage

Installation of malcode

Potential Fraud

Invalid credentials

Weak authorization

Insufficient tamper protection

Downtime

Denial of service risk

System corruption

Thus there are multiple scenarios to plan for… External Threat Insider Threat Accidental Event Intentional Event Malware Denial of service Sophisticated, organized attacks Natural disasters Economic upheaval Changing Political Climate Unpatched systems Code vulnerability Lack of change control Human error or carelessness Undiscovered back doors Information theft Insider fraud

Issues and Items to Understand Terms, Technologies, and Tough Questions

Smart Meters Legacy power meters were simple Mechanical devices Displayed a rolling record of usage Read by roaming utility personnel Smart meters are more functional Additional sensors monitor for outages, power quality, temperature, etc. notification Tag readings with time/date/location Can communicate wirelessly to aggregation pts or to remote readers Ordinarily one-way communication outbound You should know where and how Smart Meters will be deployed

Legacy power meters were simple

Mechanical devices

Displayed a rolling record of usage

Read by roaming utility personnel

Smart meters are more functional

Additional sensors monitor for outages, power quality, temperature, etc. notification

Tag readings with time/date/location

Can communicate wirelessly to aggregation pts or to remote readers

Ordinarily one-way communication outbound

You should know where and how Smart Meters will be deployed

Advanced Metering Infrastructure (AMI) Advanced Metering Infrastructure (AMI) includes hardware, software, communications, customer associated systems and meter data management (MDM) software AMI Meters support two-way communications and conforms to AMI standards You must know: Where and how are you using AMI meters? What kinds of data and/or control are you passing to and receiving from the utilities? Which products and services companies are involved in this AMI implementation? Have the components been tested for security? Are you protected from eavesdropping and attack? Img courtesy: http://seclab.uiuc.edu

Advanced Metering Infrastructure (AMI) includes hardware, software, communications, customer associated systems and meter data management (MDM) software

AMI Meters support two-way communications and conforms to AMI standards

You must know:

Where and how are you using AMI meters?

What kinds of data and/or control are you passing to and receiving from the utilities?

Which products and services companies are involved in this AMI implementation?

Have the components been tested for security?

Are you protected from eavesdropping and attack?

Net Metering Img courtesy cr.middlebury.edu Net Metering refers to the “net” result of considering the production and consumption of electrical power by an organization or a building Meaning "what remains after deductions" ... the deduction of any energy outflows from metered energy inflows Under net metering, system owners receive credit for the electricity they generate Home or small business power generation generally includes: solar, wind, fuel cell and micro co-generation (MCG) or Micro combined heat and power (MCHP) You need to know whether your organization is going to invest in power generation to create positive net metering img courtesy of hilaroad.com Provided – Generated $$ COST

Net Metering refers to the “net” result of considering the production and consumption of electrical power by an organization or a building

Meaning "what remains after deductions" ... the deduction of any energy outflows from metered energy inflows

Under net metering, system owners receive credit for the electricity they generate

Home or small business power generation generally includes: solar, wind, fuel cell and micro co-generation (MCG) or Micro combined heat and power (MCHP)

You need to know whether your organization is going to invest in power generation to create positive net metering

Demand Management Demand Management refers to the proactive reduction of power demand during periods when energy-supply systems are constrained This does not necessarily decrease total energy consumption, it time shifts it Can reduce costs for participants Reduces the need for addition power generation Companies participate in order to achieve savings through reduced consumption during mutually agreed periods You must know: How will the systems be configured to comply with the expected reductions in service? How have the management systems been secured against corruption or inadvertent reductions in power? Who will be empowered to reduce available power? Peak period Off Peak Off Peak

Demand Management refers to the proactive reduction of power demand during periods when energy-supply systems are constrained

This does not necessarily decrease total energy consumption, it time shifts it

Can reduce costs for participants

Reduces the need for addition power generation

Companies participate in order to achieve savings through reduced consumption during mutually agreed periods

You must know:

How will the systems be configured to comply with the expected reductions in service?

How have the management systems been secured against corruption or inadvertent reductions in power?

Who will be empowered to reduce available power?

Energy Storage Energy Storage is a critical enabler of the Smart Grid capability to integrate renewable power Existing grid is a just in time/use it or lose it system Many renewables are variable (wind/no wind, sun/no sun) and storage smoothes the cycle Energy storage technologies are arriving: Battery arrays Compressed air, flywheels, pumped water systems V2G automobiles You need to know: How much storage will be in place to support power requirements? How is that storage managed and controlled? Who has access to the systems controlling and monitoring the storage functions? img courtesy upei.ca

Energy Storage is a critical enabler of the Smart Grid capability to integrate renewable power

Existing grid is a just in time/use it or lose it system

Many renewables are variable (wind/no wind, sun/no sun) and storage smoothes the cycle

Energy storage technologies are arriving:

Battery arrays

Compressed air, flywheels, pumped water systems

V2G automobiles

You need to know:

How much storage will be in place to support power requirements?

How is that storage managed and controlled?

Who has access to the systems controlling and monitoring the storage functions?

Microgrids Microgrids are small-scale power supply and consumption units Generating sufficient or nearly sufficient power for use in served community Connected to traditional power infrastructure for back-up and for surplus power trade Organizations, campuses, bases, and small communities can be served via Microgrid You must know: The security of components and control systems that will manage and monitor the microgrid The nature of data sharing/interconnect with other Microgrids, Smart Grids, or traditional utility control elements img courtesy of ieses.fsu.edu

Microgrids are small-scale power supply and consumption units

Generating sufficient or nearly sufficient power for use in served community

Connected to traditional power infrastructure for back-up and for surplus power trade

Organizations, campuses, bases, and small communities can be served via Microgrid

You must know:

The security of components and control systems that will manage and monitor the microgrid

The nature of data sharing/interconnect with other Microgrids, Smart Grids, or traditional utility control elements

Groups and resources to know FERC : http://www.ferc.gov Federal Energy Regulatory Commission - Assist consumers in obtaining reliable, efficient and sustainable energy services at a reasonable cost through appropriate regulatory and market means NERC : http://www.nerc.gov North American Electrical Reliability Corporation - Enforces reliability standards with all U.S. users, owners, and operators of the bulk power system. Owns responsibility for Smart Grid security standards NIST : http://www.nist.gov/smartgrid National Institutes of Science and Technology Smart Grid working group – Responsible for creating recommendations for security and interoperability of the Smart Grid DOE : http://www.oe.energy.gov/smartgrid.htm Department of Energy Office of Electricity and Reliability – Driving Smart Grid development and direction Gridwise Alliance : http://www.gridwise.org Gridwise Alliance – Industry group working on cooperative evolution of the Smart Grid Smart Grid News http://smartgridnews.com National Demand Response Potential (FERC) http://www.ferc.gov/legal/staff-reports/06-09-demand-response.pdf NIST Draft Smart Grid Interoperability Standards h ttp://www.nist.gov/public_affairs/releases/smartgrid_interoperability.pdf 21 Steps to Improve Cyber Security of SCADA Networks http://www.oe.netl.doe.gov/docs/prepare/21stepsbooklet.pdf A Systems View of the Modern Grid, Appendix 3 http://www.netl.doe.gov/moderngrid/docs/ASystemsViewoftheModernGrid_Final_v2_0.pdf NERC Memo on Critical Cyber Asset Identification http://online.wsj.com/public/resources/documents/CIP-002-Identification-Letter-040609.pdf

FERC : http://www.ferc.gov

Federal Energy Regulatory Commission - Assist consumers in obtaining reliable, efficient and sustainable energy services at a reasonable cost through appropriate regulatory and market means

NERC : http://www.nerc.gov

North American Electrical Reliability Corporation - Enforces reliability standards with all U.S. users, owners, and operators of the bulk power system. Owns responsibility for Smart Grid security standards

NIST : http://www.nist.gov/smartgrid

National Institutes of Science and Technology Smart Grid working group – Responsible for creating recommendations for security and interoperability of the Smart Grid

DOE : http://www.oe.energy.gov/smartgrid.htm

Department of Energy Office of Electricity and Reliability – Driving Smart Grid development and direction

Gridwise Alliance : http://www.gridwise.org

Gridwise Alliance – Industry group working on cooperative evolution of the Smart Grid

Smart Grid News

http://smartgridnews.com

National Demand Response Potential (FERC)

http://www.ferc.gov/legal/staff-reports/06-09-demand-response.pdf

NIST Draft Smart Grid Interoperability Standards

h ttp://www.nist.gov/public_affairs/releases/smartgrid_interoperability.pdf

21 Steps to Improve Cyber Security of SCADA Networks

http://www.oe.netl.doe.gov/docs/prepare/21stepsbooklet.pdf

A Systems View of the Modern Grid, Appendix 3

http://www.netl.doe.gov/moderngrid/docs/ASystemsViewoftheModernGrid_Final_v2_0.pdf

NERC Memo on Critical Cyber Asset Identification

http://online.wsj.com/public/resources/documents/CIP-002-Identification-Letter-040609.pdf

Where to begin, a checklist. Manage Identities and Access: Create processes for ensuring appropriate access control to planned strategic energy management and monitoring systems Protect Data and Information: Ensure capability for granular protection of unstructured & structured data, data leak prevention and acceptable use policy monitoring Control Software and Application Releases: Process for assuring security, efficiency and integrity of any custom or contracted software development Manage Change and Configuration: Mandate regular process for routine, emergency and out-of-band changes that will minimize or prevent operational outages Understand and Address Threats and Vulnerabilities: Continually monitor systems and expert resources to remain informed on protection for enterprise infrastructure for new and emerging threats Implement Security Information and Event Management: Automate the process of auditing, monitoring and reporting on security and compliance posture across the enterprise Manage Problems and Incidents: Designate responsibility and ownership for any issues in security, reliability, or power quality, and their investigation. Maintain trained event forensics team or create relationship with expert provider Attain visibility into organizational power strategy: Develop and maintain risk profiles and lists of potential and planned partners and technology acquisitions Provide Security Training & Ensure Awareness: Ensure awareness of security issues in ppower and power facilities by providing consistent training to end users and operators

The Smart Grid IS coming … Get Ready

Questions? Jack Danahy Co-Author : The Smart Grid Security Blog smartgridsecurity.blogspot.com [email_address]
