HELLO @WORLD #CASSANDRA   APACHE CASSANDRA IN ACTION               WDCNZ 2012    Aaron Morton, Apache Cassandra Committer ...
The Code is at...github.com/amorton/wdcnz-2012-site
Cassandra?
Cassandra?         Started at         Facebook.
Cassandra?  Top Level Apache project since 2010.
Used by...   Netflix, Twitter, Reddit, Rackspace...
Commercial support by...   Data Stax, Acunu,    PalominoDB,      Impetus...
Why Cassandra?             Scale
Why Cassandra?       Operations
Why Cassandra?       Data Model
Cluster
Store ‘foo’ key with Replication Factor 3.                              Node 1 - foo                     Node 4           ...
Consistent Hashing...	 Evenly map keys to       nodes.
Consistent Hashing...	    Minimise keymovements when nodes    join or leave.
Partitioner...     RandomPartitioner   transforms Keys to Tokens           using MD5.         (Default Partitioner, there ...
Keys and Tokens?    key     fop   foo  token 0    10     90      99
Token Ring.                          99   0                  foo            fop              token: 90            token: 10
Token Ranges.                                   Node 1                                   token: 0                         ...
Locate Token Range.                                              Node 1                                              token...
Replication Strategy selectsReplication Factor number of      nodes for a row.
SimpleStrategy with RF 3.                                          Node 1                                          token: ...
Clients connect to any node in the      cluster.
The Client and the Coordinator.                                            Node 1                                         ...
Client specifiedConsistency Level.
Consistency Level...   Any*, One, Two,       Three,
Consistency Level...          QUORUM,       LOCAL_QUORUM,       EACH_QUOURM*
QUOURM at Replication Factor...   Replication                 2 or 3   4 or 5   6 or 7     Factor   QUOURM          2     ...
Node Down.                                     Node 1                                     token: 0             foo        ...
Write ‘foo’ at QUOURM with Hinted Handoff.                                             Node 1                             ...
Read ‘foo’ at QUOURM.                                       Node 1                                       foo              ...
Consistency Levelnodes must agree.
Column Timestamps used to resolve    differences.
Consistent read for ‘foo’ at QUOURM.                    Node 1                                         Node 1             ...
R +W > N(#Read Nodes + #Write Nodes > Replication Factor)
Data Model
Data Model so far.     Row Key:   Column        Column   Column                  (Incomplete.)
Data Model.                           Keyspace               Column Family   Column Family   Column Family                ...
Data Model...                            Keyspace                                Column Family                Column: name...
Code
Tweet Storage...     CF /                     User      User      User      Global              User   Tweet   Row Key    ...
Followers Storage...       CF /                        Ordered                  Relationships                   TweetDeliv...
Data DrivenWellington(It’s a meet-up on MeetUp.Com)
Aaron Morton                     @aaronmorton                   www.thelastpickle.comLicensed under a Creative Commons Att...
