Xamarin   Seminar     22nd March 2012    Copyright 2012 © Xamarin Inc. All rights reserved
Announcements http://xamarin.com/seminars                                                           Xamarin       Copyrigh...
AgendaiCloud with MonoTouch                      Craig Dunn                      Technical Writer                      Xam...
IntroductionThis session discusses Apple’s new iOS5 iCloudfunctionality and how to implement iCloud featureswith MonoTouch...
iCloud Basics (i)   • Remote storage & backup   • Synchronization of data across devices (iOS     & Mac OS X) but NOT confl...
iCloud Basics (ii)• 4 ways to utilize iCloud:   • Key-Value Pairs           today’s                                topic  ...
iCloud Setup (i)• App ID & Provisioning Profile (developer.apple.com)   • grants iCloud support (tick the box!)   • linked ...
iCloud Setup (iii)• MonoDevelop Entitlements UI with placeholder   expansion:     • $(TeamPrefixIdentifier) automatically ad...
iCloud Setup (iv)• Don’t forget the devices!  • Same AppleID on each device
Key-Value Pairs (i)• Similar to NSUserDefaults• Simple types only (whatever works in a plist):  text, number, date• Limite...
Key-Value Pairs (ii)Example creates a ‘key’ for each  device, plus a   Shared one.
Key-Value Pairs (iii)• SetString• GetString• Synchronize() returns false if no iCloud OR  if no updates are required• Your...
Key-Value Pairs (iv)           • Change Notifications                                   Register for notificationServerChang...
Files in the Cloud  • NSFileCoordinator & NSFilePresenter work    with the iCloud to prevent contention on the    local co...
UbiquityContainer                               Ru                                                                 ki     ...
UIDocument (spoilers)• Where are iCloud documents stored?                          UbiquityContainer   Asyn               ...
UIDocument (example)
Finding UbiquityContainerThis one line iskey to getting                                     Asyn                          ...
Subclassing UIDocument• Override the ‘read’ and ‘write’ methods: • Actually called LoadFromContents() and    ContentsForTy...
Subclassing UIDocument                       url to UbiquityContainer location                                            ...
Create a UIDocPut user-generated files inthe /Documents/ directory                                                Has the ‘...
Open UIDoc Open specific filenamefrom the /Documents/ directory                                 Asyn                        ...
Changes Applied & SavedUpdateChangeCount() is                   Update the model withall that is required to              ...
Changes ElsewhereListen for notification sent bythe UIDocument subclasswhen it is changed When that notificationoccurs, we a...
Enumerate UIDocs (i)CloudUIDoc exampleLooking for a single,specific filename                                Special Predicat...
Enumerate UIDocs (ii)When the NSMetadataQuery is done,we stop it (it could keep running/monitoring) and remove our listene...
Debugging Tips (i)• The /Documents/ directory can be  managed by the user (and you, for  testing)
Debugging Tips (ii)    • Check your iCloud-linked Mac, sync’d files will       be there if everything is working correctly/...
iOS Data StorageGuidelines (for iCloud)• Only documents that are user-generated should  go into /Documents/• Data that can...
Other examples• Key-Value ~ chat2self
Other examples• UIDocument ~ TaskCloud
References (i)Introduction to iOS 5 (currently being updated)http://docs.xamarin.com/ios/tutorials/Introduction_to_iOS_5Wh...
References (ii)NSFilePresenter Protocol Referencehttp://developer.apple.com/library/mac/#documentation/Foundation/Referenc...
Xamarin    Seminar   Please give us your feedback  http://bit.ly/xamfeedback      Follow us on Twitter        @XamarinHQ  ...
