WebLogic for DBAs                   Simon Haslam                  Veriton Limited1 (1.0)
Simon Haslam / Veriton     Consultant & Oracle Partner,     established for 15 years     I mainly work on demanding web & ...
Agenda1.   WebLogic Architecture and Components2.   Installing WLS & Configuring a Domain3.   Oracle Enterprise Manager – ...
Recap.                HTTP(S)                                           HTTP(S)                                           ...
Key WebLogic Terms          • Domain            – Grouping of config/resources for an environment            – Has one set...
Example Architecture                             machine      node                                         manager  app   ...
Component Notes          • A domain only ever has one admin server            – it looks after the master config.xml      ...
Quick Demo          • WebLogic Console            –   machines            –   servers            –   data sources         ...
Typical Enterprise Application                         Load Balancers               Web Server                 Web Server ...
Enterprise Manager GC/CC           • Actually a fairly straightforward java             application           • Runs an Or...
EM Grid/Cloud Control (HA)                            Load Balancer                   Web Server             Web Server   ...
Agenda1.   WebLogic Architecture and Components2.   Installing WLS & Configuring a Domain3.   Oracle Enterprise Manager – ...
Install             • Middleware Home                 – ‘binaries’ which may include various Oracle                   laye...
WebLogic Installation Steps           1. Install JVM (typically JRockit)           2. Install a Middleware Home and WebLog...
1) Install JVM           • Sun HotSpot or JRockit (will converge), or             JVM for your platform (e.g. IBM)        ...
2) Install WebLogic           • e.g. java -jar wls1036_generic.jar           • Only most relevant screens follow…16 (1.0)
17 (1.0)
18 (1.0)
3) Configure a Domain           • You use the config wizard to create domains             – $WL_HOME/common/bin/config.sh ...
20 (1.0)
21 (1.0)
22 (1.0)
Agenda1.   WebLogic Architecture and Components2.   Installing WLS & Configuring a Domain3.   Oracle Enterprise Manager – ...
OEM Grid Control 11g           • 11g GC was first OEM release to use             WebLogic instead of OC4J           • You ...
25 (1.0)
EM 12c – most relevant screens26 (1.0)
27 (1.0)
Note: this is the current list of plug-ins for           12.1 BP1 but will probably increase over time28 (1.0)
Configure29 (1.0)
30 (1.0)
32 bit Gotcha!           • If you’re installing on Oracle Linux 5.7 see:             https://forums.oracle.com/forums/thre...
Agenda1.   WebLogic Architecture and Components2.   Installing WLS & Configuring a Domain3.   Oracle Enterprise Manager – ...
33 (1.0)
Managing WebLogic           • Admin console is usually starting point           • Processes to check             – java fo...
Log Files           • Managed server logs are under:             – DOMAIN_HOME/servers/<name>/logs             – Accessibl...
Quick Demo           • Processes           • Log files36 (1.0)
WLST Exampledef create_ds(DS_NAME, DS_PARAMS, TARGETS, JNDI, DB_USER, DB_PASS,DB_SERVICE, DB_HOSTS, ONS_HOSTS):           ...
38 (1.0)
• WebLogic is a java application server              – typically delivers HTML over HTTP(S)           • All WLS processes ...
Thanks for listening!                 Twitter: @simon_haslam           Oracle Fusion Middleware Admin blog:               ...
Upcoming SlideShare
Loading in...5
×

WebLogic for DBAs 1.0h

2,157

Published on

Slides from the presentation I first gave in Dublin on 21/3/12 at the OUG Ireland conference

Published in: Technology
0 Comments
0 Likes
Statistics
Notes
  • Be the first to comment

  • Be the first to like this

No Downloads
Views
Total Views
2,157
On Slideshare
0
From Embeds
0
Number of Embeds
1
Actions
Shares
0
Downloads
201
Comments
0
Likes
0
Embeds 0
No embeds

No notes for slide

WebLogic for DBAs 1.0h

  1. 1. WebLogic for DBAs Simon Haslam Veriton Limited1 (1.0)
  2. 2. Simon Haslam / Veriton Consultant & Oracle Partner, established for 15 years I mainly work on demanding web & contact-centre applications Architecture planning to installation Middle Admin ware to troubleshooting (and most things istrati on in between!)2 (1.0)
  3. 3. Agenda1. WebLogic Architecture and Components2. Installing WLS & Configuring a Domain3. Oracle Enterprise Manager – 11g & 12c4. Managing WebLogic
  4. 4. Recap. HTTP(S) HTTP(S) used Web Server to return HTML HTTP(S), AJP etc Application Server e.g. SQL*Net Database etc4 (1.0)
  5. 5. Key WebLogic Terms • Domain – Grouping of config/resources for an environment – Has one set of administrators/security privileges – Can be in Production or Development mode • Admin Server – Only one per domain – Runs the Admin Console – Can be relocated for HA • Managed Server – The server(s)/JVM that run your app(s) – Cluster(s) distribute your app over several MS • Node Manager – Small java program that (re)starts your servers (MS & AS)5 (1.0)
  6. 6. Example Architecture machine node manager app managed requests webserver server plug-in managed server admin console machine admin server managed server domain node managerEND6 (1.0)
  7. 7. Component Notes • A domain only ever has one admin server – it looks after the master config.xml • The admin server doesn’t actually need to be running all the time – Managed Server Independence – the MS can start up/run on its own – AS primarily used for changing configuration or deploying apps • You want Node Manager running all the time to stop/start WebLogic servers7 (1.0)
  8. 8. Quick Demo • WebLogic Console – machines – servers – data sources – deployed applications8 (1.0)
  9. 9. Typical Enterprise Application Load Balancers Web Server Web Server WebLogic WebLogic App App Managed Server Managed Server Cluster Oracle Database Web Web (RAC and/or DG) Services Services Services Layer9 (1.0)
  10. 10. Enterprise Manager GC/CC • Actually a fairly straightforward java application • Runs an Oracle Management Service (OMS) which OEM Agents (server processes running on remote machines you want to manage) connect to over HTTPS • Has a web application that provides the main EM console10 (1.0)
  11. 11. EM Grid/Cloud Control (HA) Load Balancer Web Server Web Server OMS OMS 1 2 WebLogic WebLogic EMGC_OMS1 EMGC_OMS2 Managed Server Managed Server Repository Database My My (DG and/or RAC) Oracle Oracle Support Support Services Layer11 (1.0)
  12. 12. Agenda1. WebLogic Architecture and Components2. Installing WLS & Configuring a Domain3. Oracle Enterprise Manager – 11g & 12c4. Managing WebLogic
  13. 13. Install • Middleware Home – ‘binaries’ which may include various Oracle layered products (such as SOA Suite or Forms) – read-only* • Domain Home – configuration and logs – can live happily outside the middleware home: nice! – one middleware home / WebLogic installation can be used to run several separate domains * a few parts of Oracle ignore this13 (1.0)
  14. 14. WebLogic Installation Steps 1. Install JVM (typically JRockit) 2. Install a Middleware Home and WebLogic 3. Configure a Domain • Note: I usually install the JVM and use the generic .jar installer (i.e. same for all platforms) rather than using installer bundled with a JVM14 (1.0)
  15. 15. 1) Install JVM • Sun HotSpot or JRockit (will converge), or JVM for your platform (e.g. IBM) • JRockit specific: – don’t install demos & samples/source code – Windows latest – you probably don’t want JRockit as the public JRE15 (1.0)
  16. 16. 2) Install WebLogic • e.g. java -jar wls1036_generic.jar • Only most relevant screens follow…16 (1.0)
  17. 17. 17 (1.0)
  18. 18. 18 (1.0)
  19. 19. 3) Configure a Domain • You use the config wizard to create domains – $WL_HOME/common/bin/config.sh (.cmd) – there are several other methods too • There’s a good chance your app will configure a domain for you (though you may wish to standardise) • Only most relevant screens follow…19 (1.0)
  20. 20. 20 (1.0)
  21. 21. 21 (1.0)
  22. 22. 22 (1.0)
  23. 23. Agenda1. WebLogic Architecture and Components2. Installing WLS & Configuring a Domain3. Oracle Enterprise Manager – 11g & 12c4. Managing WebLogic
  24. 24. OEM Grid Control 11g • 11g GC was first OEM release to use WebLogic instead of OC4J • You had to install WebLogic yourself first, then use SmartUpdate (BSU) to apply WDJ7 set of patches – online or offline – see http://www.veriton.co.uk/roller/fmw/entry/ offline_patching_of_weblogic_server • If you’re installing now you’ll probably go straight to EM 12c ☺24 (1.0)
  25. 25. 25 (1.0)
  26. 26. EM 12c – most relevant screens26 (1.0)
  27. 27. 27 (1.0)
  28. 28. Note: this is the current list of plug-ins for 12.1 BP1 but will probably increase over time28 (1.0)
  29. 29. Configure29 (1.0)
  30. 30. 30 (1.0)
  31. 31. 32 bit Gotcha! • If you’re installing on Oracle Linux 5.7 see: https://forums.oracle.com/forums/thread.jspa? messageID=10220015 • Need to lower memory usage in <ORACLE_HOME>/oms/sysman/omsca/scripts/ wls/create_domain.py • You wouldn’t use 32 bit in production now but may do for laptop or lab VM31 (1.0)
  32. 32. Agenda1. WebLogic Architecture and Components2. Installing WLS & Configuring a Domain3. Oracle Enterprise Manager – 11g & 12c4. Managing WebLogic
  33. 33. 33 (1.0)
  34. 34. Managing WebLogic • Admin console is usually starting point • Processes to check – java for admin server & managed server – java for nm • Node manager (only use java version) • Log files…34 (1.0)
  35. 35. Log Files • Managed server logs are under: – DOMAIN_HOME/servers/<name>/logs – Accessible through console too • Diagnostics • Console monitor35 (1.0)
  36. 36. Quick Demo • Processes • Log files36 (1.0)
  37. 37. WLST Exampledef create_ds(DS_NAME, DS_PARAMS, TARGETS, JNDI, DB_USER, DB_PASS,DB_SERVICE, DB_HOSTS, ONS_HOSTS): cd(/) cmo.createJDBCSystemResource(DS_NAME) cd(/JDBCSystemResources/+DS_NAME+/JDBCResource/+DS_NAME) cmo.setName(DS_NAME) cd(JDBCDataSourceParams/+DS_NAME) set(JNDINames,jarray.array([String(JNDI)], String)) ...etc...37 (1.0)
  38. 38. 38 (1.0)
  39. 39. • WebLogic is a java application server – typically delivers HTML over HTTP(S) • All WLS processes run on a JVM • Middleware home is static, domain home contains config and logs • WLS Console is usually first point of contact (though don’t forget about WLST for automation) • OEM 12c runs on WebLogic but the installer now does the WLS set up work for you39 (1.0)
  40. 40. Thanks for listening! Twitter: @simon_haslam Oracle Fusion Middleware Admin blog: http://simonhaslam.co.uk40 (1.0)
