Tunnel Radio Communications and Tracking

We work where you work!

Complete and Simple TWO TASKS… MINE WIDE PERSONNEL & ASSET COMMUNICATIONS TRACKING  ONE SOLUTION  ONE CABLE

UltraComm System

USA PatentNo. 6,195,561

Basic System Features  Person to Person Wireless Communication Across Network  Surface to Underground Use  Simple to Install and Maintain

Advanced System Features Ethernet Compatible Fully Digital Capable Network Compatible Multi-Channel CapableEnhanced Range for Emergency Use Emergency Operational Features Wireless Data Transmission

Expected Signal Range TR-155 / 159 - VHF System TR-500 - UHF System0 500 1000 1500 2000

Efficiently and effectively troubleshoot Distributed AntennaSystems (DAS). The TMS card is configured to install in all ouramplifier products, however, the device is adaptable to anycompetitive DAS network, VHF or UHF.Agile TMS is designed to be used with our MineAx® serverplatform, which provides a feature rich web-based softwareinterface.TMS Net acts as a simpler platform, with an embedded webserver providing basic TMS information as shown by theUltracomm® head unit.

UltraComm ®/TMS system with separate UltraComm ® and TMS head ends Mine and TMS Operation Headend Diagram MineAx/TMS HeadendMineAx/TMS Head Card Display TR-500B2 TR-500B2 TR-550 TR-550 TR-159 TR-159 TR-155 TR-155 UltraComm Headend TR-IFUX TMS Tail TMS Tail Card Card Data reply from TMS card Amplifier Amplifier Data request from Master card

UltraComm ®/TMS system with integrated Integrated Mine and TMS Operation Headend Diagram UltraComm ® and TMS head end Integrated Ultracom- MineAx/TMS Headend TR-IFUXMineAx/TMS Head Card TR-500B2 TR-500B2UltraComm TR-550 TR-550 Interface Display TR-159 TR-159 Unit TR-155 TR-155 TMS Tail TMS Tail Card Card Data reply from TMS card Amplifier Amplifier Data request from Master card

Agile TMS-NET Features Provides the same information that is displayed on the head end unit, but additionally allows for basic remote (IP) monitoring and control of the network. Provides the ability to initiate a manual system scan, without having to wait for the automatic scan to take place Provides the capability to generate a summary report on the status of all monitored devices. This report will allow the user to spot trends so that potential problems may be anticipated, and thus avoided.

Agile TMS Features  Useful to precisely identify Easily configured and the network area with a programmable for UHF, VHF performance issue, thereby and 220 PTC operations – all reducing troubleshooting and on the same board. repair time. Instant viewing/polling of specific locations. Head automatically scans network and retrieves  Option ports - data, displaying critical serial, TTL, logic and I/O information regarding drivers. Option bus for amplifier voltages and power MineAx tracking RFID levels. card, gas sensor card and remote I/O. Head maintains list of TMS devices and their statuses.  Channel agility also allows Unreachable units will be operation on any Distributed reported to the user. Antenna System (DAS) network, VHF or UHF.

Monitoring Diagnostics Agile TMS # TMS Tail Cards + # MineAx ® ReadersTMS SystemAddress StatusPowerSupplyVoltage Pin 1 Voltage RSSI Values

UHF / VHF AmplifierUHF / VHF Splitter – 3 or 4 way Portable RadioUHF / VHF Splice Box Directional AntennaUHF / VHF End Cable Box Dipole AntennaTunnel Management System Card Conrad AntennaSurge Protection – Line Power Barrier UnitSuppressor Power InsertExplosion Proof Enclosure Power SupplyBarrier Connection Cable BatteryHi-Performance Radiating Cable Portable RadioAir Wall Cable Personnel TagFoam Cable Wireless Tracking ReaderYellow CableCoax Cable

MineAx System

Location of Tag enters miner is receiving displayed zone and stored Software Data enterscompares reader tag ID to network manifest Data Data captured to transmitted host to surface software

Fresh Air TR-ANT-4502-T-M Miner Typical Pillar CoalInstallation Neutral Air TR-MX-PS-8V TR-MX-332C5-3-U Mine Main Entrance Miner Three entrances covered with aTriple Port ReaderTR-MX-332C5-3-U and the Power Supply Return Air TR-MX-PS-8V TR-ANT-4502-T-M Miner

 Connects to Mine Radio Network Head Unit Creates wireless data buss over Digital Antenna System (DAS) network Polls reader units, TMS-C cards for multi-use Retrieves U/G data, passes to tracking server Frequency agile – 120-600 Mhz (VHF or UHF) Compatible with all major manufacturer’s products: including Becker, Varis, MRS, MST and MineCom

 Stores incoming tag data Multi-unit, mesh capable Stores incoming tag data Tag signals are collected via locally mounted or remote antenna(s) Emergency High Intensity LED Flasher – can be activated from server Battery power capable Remotely updatable

 Create greater coverage area by attaching reader to cable

MineAx Bird-Dog System

 Text

 As an additional back-up feature, the head unit incorporates an independent receiver port which will continue to operate ‘post incident,’ to track personnel as they exit the mine.

 All readers are enclosed in an IP66 and UL rated dust and water resistant, capable of surviving impact damage. IS power for reader unit is derived from two independent means – AC and battery Main reader board is thermally protected and epoxy coated for long life.

Power Supply Dimensions: 11” x 14” x 5.5” Weight: 17.5 lbs Voltage: 120 VAC inputTR-PS-8 MSHA Approval :#23-A100002-0

 AC-DC power with  AC – DC Power Supply IS internal battery back-up permissible – MSHA approved for hook up DC intrinsically safe (IS) safety power With TR-PS8  Data provisions include LiON internal battery low power computer option – 90 day life displayed warning Power Options All wireless capability

 (4 and 2) Gas Sensing (active) Vehicle Information Management System (VIMS) High Definition Tracking (HD) Next generation amplifier (fully remote digital control) Digital stench gas release (active) Ethernet tracking capability

 Alpha Natural Resources Amfire Mining Company Barrick Gold Corp. Blue Mountain Energy Carmeuse Lime & Stone Coeur Mining Hecla Mining Company Newmont Mining Corp. Teck Cominco CAM Mining
