AJAX for ScalabilityErik SchultinkPHP Barcelona – 30 Oct, 2009<br />
AJAX<br />What is AJAX?<br />“Asynchronous JavaScript and XML”<br />Paradigm for client-server interaction<br />Change sta...
Traditional HTML Browsing<br />User clicks link<br />Browser sends request<br />Server receives, parses request, generates...
AJAX Browsing<br />User clicks link<br />Browser sends request<br />Server receives, parses request, generates response<br...
Why Asynchronous?<br />Not always necessary to wait for server response<br />Most of response is predictable<br />
Scalability?<br />Through-put, not speed<br />Ideally, capacity is linear function of machines<br />In practice, linear be...
What is Tuenti.com?<br />
Tuenti.com<br />Started 2007<br />More than 20 billion pageviews/month<br />More than 20k/second at peak<br />Based in Mad...
How does Tuenti use AJAX?<br />Only pageloads are login and home page<br />Loader pulls in all JS/CSS<br />Afterwards stay...
How does Tuenti use AJAX?<br />PHOTO UPLOAD<br />
How does Tuenti use AJAX?<br />CHAT<br />
How does Tuenti use AJAX?<br />CHAT<br />
How does Tuenti use AJAX?<br />
How does Tuenti use AJAX?<br />
Traditional Systems Architecture<br />www.tuenti.com<br />Load Balancer<br />Web server farm<br />Web server farm<br />Web...
Traditional Systems Architecture<br />www.tuenti.com<br />12.45.34.179<br />12.45.34.178<br />Load Balancer<br />Load Bala...
Client-side Routing<br />www.tuenti.com<br />wwwb3.tuenti.com<br />wwwb2.tuenti.com<br />wwwb1.tuenti.com<br />wwwb4.tuent...
Client-side Routing<br />www.tuenti.com<br />wwwb3.tuenti.com<br />wwwb2.tuenti.com<br />wwwb1.tuenti.com<br />wwwb4.tuent...
Client-side Routing<br />www.tuenti.com<br />wwwb3.tuenti.com<br />wwwb2.tuenti.com<br />wwwb1.tuenti.com<br />wwwb4.tuent...
Client-side Routing<br />www.tuenti.com<br />wwwb3.tuenti.com<br />wwwb2.tuenti.com<br />wwwb1.tuenti.com<br />wwwb4.tuent...
Client-side Routing<br />www.tuenti.com<br />wwwb3.tuenti.com<br />wwwb2.tuenti.com<br />wwwb1.tuenti.com<br />wwwb4.tuent...
Internal network savings<br />
Balancing Load<br />Top-level requests to www.tuenti.com<br />Each request tells client which farm it should be using, bas...
Robust Browsing<br />Don’t tightly couple layers<br />Client and server are separate layers<br />
Robust Browsing<br />Client-side code should be robust against server-side failures<br />What can go wrong?<br />Client lo...
Robust Browsing<br />Options:<br />Retry (carefully)<br />Switch to alternate farm (carefully)<br />Detect error, give use...
Caching<br />Think like server-side scalability<br />Cache data that is likely to be requested in the future<br />Doesn’t ...
Cache Data in Client Browser<br />More responsive for user<br />Fewer requests to your servers<br />
Some details<br />Lots of dependencies to load initially<br />Loading can be brittle and slow<br />Browser performance<br />
Some details<br />Beware of external libraries<br />Google JS lib are not static, not indefinitely cacheable<br />
Some details<br />Friends do have consistency issues<br />Add/remove friends<br />Change avatar (rare)<br />
Image Serving<br />Tuenti serves ~2.5 billion images/day<br />At peak, this is &gt;6 Gbps and &gt;70k hits/sec<br />We use...
What is a CDN?<br />Content Delivery Network<br />
What is a CDN?<br />Examples: Akamai, Limelight<br />also dozens more, including Amazon<br />Big distributed, object cache...
What is a CDN?<br />Advantages:<br />Outsource dev and infrastructure<br />Geographically distributed<br />Economies of sc...
What affects image load time?<br />Client internet connection<br />Response time of CDN<br />CDN cache hit rate<br />Respo...
What affects image load time?<br />Client internet connection<br />Response time of CDN<br />CDN cache hit rate<br />Respo...
Monitor Performance from Client<br />Closer to performance experienced by end-user<br />Only way to get view of network is...
Good Monitoring<br />Percentiles &gt; averages <br />Less noise, more stable<br />Comparable to SLA terms<br />Establish b...
How to fix slow ISP?<br />Choose better transit provider<br />Set-up peering (or get CDN too)<br />Traffic management<br />
What affects image load time?<br />Client internet connection<br />Response time of CDN<br />CDN cache hit rate<br />Respo...
Quality of End-User Experience<br />vs.<br />Cost<br />
We use multiple CDNs, and shift content based on price/performance.<br />
Know your content<br />
Know your content<br />
Know your content<br />
Know your content<br />30<br />75<br />200<br />
Know your content<br />600<br />
Know your content<br />120<br />
Know your content<br />
Pre-fetch Content<br />Exploit predictable user behavior<br />Ex: clicking to next photo in an album<br />Simple solution ...
Pre-fetch Content<br />More complex solution<br />Pre-fetch next canvas (full html), render in background – rotate in on N...
Pre-fetch Content<br />Problems:<br />Rendering still takes time<br />Increases browser load<br />Need to set cache header...
Image delivery<br />Small images: High request, low volume<br />Most cost-effective to cache in memory<br />Large images: ...
What affects image load time?<br />Client internet connection<br />Response time of CDN<br />CDN cache hit rate<br />Respo...
Monitor Performance from Client<br />cold servers online<br />
What affects image load time?<br />Client internet connection<br />Response time of CDN<br />CDN cache hit rate<br />Respo...
Deploy cache layers (squid, varnish)<br />Optimize web servers for static content delivery<br />More machines<br />Avoid R...
Summary<br />Cache and pre-fetch content<br />Client-side routing<br />Client-side monitoring<br />
General caveats<br />Be careful with browser performance<br />Look carefully at what’s in the worst 5%<br />Don’t assume t...
More<br />jobs.tuenti.com<br />Presentation<br />Saturday 14:20<br />Challenge (win a PS3)<br />Talk: Continuous Integrati...
More? Ask us!<br />
More? Ask us!<br />
Q & A<br />
