LMAX Architecture LMAX Architecture Presentation Transcript

  • Die LMAX-Architecture withDisruptors:6M Transactions per SecondStephan Schmidt, Vice CTO, brands4friends
  • MeStephan SchmidtVice CTO brands4friends@codemonkeyismwww.codemonkeyism.comstephan.schmidt@brands4friends.de
  • 3
  • brands4friends No.1 Shopping Club in Germany > 360k daily visitors > 4.5M Users eBay company5 20.04.12 WJAX 2011
  • 6
  • 7
  • Development atbrands4friendsTeamJava and web developers,data warehouse developersProcessScrum since 2009Kanban for DWH since2012
  • LMAX - The London Multi-Asset Exchange "We aim to build the highest performance financial exchange in the world"9 20.04.12 Fußzeilentext
  • High Performance Transaction Processing10 20.04.12 Fußzeilentext
  • Business Receive Unmarshal Journal Replicate Marshall Send LogicService / Transaction Processor
  • Business Receive Unmarshal Journal Replicate Marshall Send Logic Queue Queue Queue Queue Queue QueueService / Transaction Processor
  • Cores Ghz CPU
  • Actors? SEDA?14 20.04.12 Fußzeilentext
  • Stuff that did not work for various reasons 1.  RDBMS 2.  Actors Receive Unmarshal Journal Replicate Business Logic Marshall Send Queue Queue Queue Queue Queue Queue 3.  SEDA Service / Transaction Processor 4.  J2EE …15 20.04.12 Fußzeilentext
  • LMAX Architecture16 20.04.12 Fußzeilentext
  • Business Receive Unmarshal Journal Replicate Marshall Send Logic Queue Queue Queue Queue Queue QueueService / Transaction Processor
  • SizeLinked List Queue Node Node Node NodeAdd Remove Add Remove Array Queue Cache Line Cache Line
  • Queue as a data structure Problems with Queues 1.  Reading (Take) and Writing (Add) are both write access => Write Contention 2.  Write Contention solves with Locks 1.  Other solutions include Deques 3.  Locks lead to context switches to the kernel 1.  Context switches lead to CPU cache misses etc. 2.  Kernel might use opportunity to do other stuff as well19
  • Locks Costs according to LMAX Paper Method Time in ms Single Thread 300 Single Thread mit Lock 10.000 Zwei Threads mit Lock 224.000 Single Thread mit CAS 5.700 Zwei Threads mit CAS 30.000 Single Thread/ 4.700 Volatile Write “Compare And Swap” Atomic Reference etc. in Java => No Context Switch Memory Read/Write Barrier20
  • LMAX Data Structure – Ring Buffer Event Publisher Processor Ring Buffer21
  • Pre-Allocation of Buckets 31 30 29 28 0 27 1 26 2 25 3 24 4 23 5 22 Event Publisher 6 21 Processor 7 20 8 19 9 18 10 17 11 16 12 15 13 14 Ring Buffer2^5 •  No (less) GC problems •  Objects are near each other in memory22 => cache friendly
  • Coordination 31 30 29 28 0 27 1 26 2 25 3 24 4 23 5 22 Event Publisher 6 21 Processor 7 20 Claim 8 19 Wait Strategy 9 18 Strategy 10 17 11 16 12 15 13 14 Ring Buffer2^5 1.Claim 2.Write 3.Make Public by advancing sequence23
  • Latency Business Receive Unmarshal Journal Replicate Marshall Send Logic Queue Queue Queue Queue Queue QueueService / Transaction Processor
  • JournalReceive Replicate BusinessMessage Logic Unmarshall
  • Business Receive Unmarshal Journal Replicate Marshall Send Logic Datenstruktur DatenstrukturService / Transaction Processor
  • LMAX Architektur Input Disruptor Ouput Disruptor Ouput Disruptor Ouput Disruptor Business Logic Handler
  • HA Node Publisher Receiver Replicator Marshaller Journaler Un- Marshaller Output Disruptor Input Disruptor File SystemJede Stagekann mehrere Business Logic HandlerThreads haben28
  • Receiver writes on 31. Journaler and Replicator read on 24 and can move up the Receiver sequence to 30. Journaler 31 Replicator 24 Un-Marshaller can move beyond Un- Journaler and Replicator up to Marshaller 30. 19 18 Business Logic Handler needs Business Logic to stay behind all others. Handler29
  • Java API30 20.04.12 Fußzeilentext
  • C1P1 C2 C3 C4
  • C2P1 C1 C3 C4
  • C1 C2P1 C3 C4
  • C2P1 C1 C4 C3
  • P1 C1P2
  • Demo38 20.04.12 Fußzeilentext
  • LMAX Low Level Ideas 1.  Simple Code 2.  Everything in memory 3.  Single threaded per CPU for business logic 4.  Business logic has no I/O, I/O is done somewhere else 5.  Scheduler “knows” dependencies of handlers39 20.04.12 Fußzeilentext
  • 6M TPS? How did LMAX do it? x 10 x 10 3 billions of 1000K+ TPS instructions on modern Custom, cache friendly CPU collections 100K+ TPS Performance Testing Clean organized code Controlled GC Standard libraries 10K+ TPS Very well modeled domain If you dont do anything stupid40
  • We’re looking for very good developers
  • Thanks!@codemonkeyismstephan.schmidt@brands4friends.de
  • Images CC from Flickr: nimboo, imjustcreative, gremionis, justonlysteve, John_Scone, Matthias Wicke, irisgodd3ss, TunnelBug, alandd, seasonal wanderer, raulbarraltamayo, Gilmoth, Dunechaser, graftedno143
  • Sources “Disruptor: High performance alternative to bounded queues for exchanging data between concurrent threads”, Martin Thompson, Dave Farley, Michael Barker, Patricia Gee, Andrew Stewart, 2011 "The LMAX Architecture”, Martin Fowler, 2011 http://martinfowler.com/articles/lmax.html “How to do 100K+ TPS at less than 1ms latency”, Martin Thompson, Michael Barker, 201044 20.04.12 Fußzeilentext
