Scaling Websites with
   Amazon’s EC2
 Rusty Conover (rconover@infogears.com)

        http://www.infogears.com
About Me

• Co-founder of InfoGears
• NYC via Montana and NJ.
• Computer Science
• Price comparison engine
• @rusty_conover
Audience Survey
Audience Survey
Amazon
Audience Survey
Amazon
Linux
Audience Survey
Amazon
Linux
HTTP
Audience Survey
Amazon
Linux
HTTP
DNS
Audience Survey
Amazon
Linux
HTTP
DNS
Apache
Audience Survey
Amazon
Linux
HTTP
DNS
Apache
TCP/IP
Audience Survey
Amazon
Linux
HTTP
DNS
Apache
TCP/IP
Megabits
Audience Survey
Amazon      “Expires”
            Header
Linux
HTTP
DNS
Apache
TCP/IP
Megabits
Audience Survey
Amazon      “Expires”
            Header
Linux
            Regular
HTTP
            Expressions
DNS
Apache...
Audience Survey
Amazon      “Expires”
            Header
Linux
            Regular
HTTP
            Expressions
DNS
      ...
Audience Survey
Amazon      “Expires”
            Header
Linux
            Regular
HTTP
            Expressions
DNS
      ...
Audience Survey
Amazon      “Expires”
            Header
Linux
            Regular
HTTP
            Expressions
DNS
      ...
The Problems
• If the site’s slow, users leave dissatisfied
  which often means lost sales.
• Bandwidth is relatively expen...
Other Concerns
• Thousands of people all want to watch
  your video at once.
• Viral campaigns
• The unexpected media ment...
The solutions
Content Distribution Networks


       Load Balancers


      Reverse Proxying
Content Distribution
                                           Designer
 Client                          Tokyo


        ...
Load Balancer

Client            Internet                             Designer

                                         S...
Reverse Proxy

Client                  Internet                                      Designer




                        ...
Our Solution
Client          Internet


                         Request for                 Request for
                 ...
Amazon’s EC2
Allows you to have as many virtual machines as
you’d like.
  •   Basic - 1.0 Ghz 2007 Xeon 1.7 GB
      RAM, ...
Bandwidth...
• Amazon EC2’s bandwidth is about 250 -
  1000Mbps.
• You’re only billed for what you use. Making
  it cheap,...
Pricing
      It’s all usage based, with discounts.

      Bandwidth                 CPU Usage
$0.10 per GB (incoming)    ...
Limitations of EC2
• When an instance is shutdown all of the
  disks are wiped. Cache is cleared.
• There are no guarantee...
So what’s it good for?
1. Parallel processing tasks without building
   a server farm.
2. Building cache servers to serve ...
How to scale
 Most websites have both static and dynamic
 content
 Serving separately will increase response
 time.
      ...
Dynamic Proxy/Cache

• Static requests are only sent to the reverse
  proxy/cache.


• Redirects to the real server if the...
The Details                                                            Client
                                            ...
A Little About EC2

• Amazon provides a number of disk images,
  like ISOs for base installs.
• Fedora Core & Windows.
• Y...
Amazon Images

$ ec2-describe-images -o self -o amazon
IMAGE! ami-3c03e655!cache7/image.manifest.xml!314456711494
! availa...
Create an instance
Create an instance:
  $ ec2-run-instances ami-2103e648
Showing current instances:
  $ ec2-describe-inst...
DNS
EC2 will go down, when you least expect it.
You don’t want the users to get errors and you
don’t want to be sending re...
DNS Redirection
If you host more then one website, generally you
don’t want to setup instances for every domain.
Setup one...
DNS Flowchart
                                        Reply is CNAME
    Request for
                                     ...
The Cache Stack

       apache

bind            snmpd    sshd       ntpd

          Fedora Core 4 w/Updates
Setup
•   You need to build in mod_cache, mod_proxy &
    mod_rewrite.

•   Keep the server as small as possible, no PHP o...
Logging
It’s good to judge cache hits to make sure your cache is
working.

LogFormat "%{Host}i %h %l %u %t "%r" %>s %b "%{...
Proxy

    ProxyRequests Off
    <Proxy *>
             Order deny,allow
             Allow from all
    </Proxy>

•   Mak...
Rewrite
   RewriteMap lowercase int:tolower
   RewriteMap cachehost txt:/usr/local/apache2/conf/cache-host.map
   RewriteC...
Host Mapping

# Destination Host          Source Host
static-cache.gearbuyer.com! static.gearbuyer.com
images-cache.gearbu...
Cache
   CacheEnable disk /
   CacheRoot /mnt/cache
   CacheDirLevels 3
   CacheDirLength 1
   CacheIgnoreCacheControl Off...
Scaling
   ServerLimit 600
   StartServers         20
   MinSpareServers      20
   MaxSpareServers      60
   MaxClients ...
Monitoring
Monitoring is important to make
sure that EC2 can reach your
servers, and your EC2 server is still
running.
I u...
Monitoring                                       Do this forever




                              Try example proxy
     ...
Hit Rate
Set Expires header on everything you
can.
ExpiresActive   on
ExpiresByType   image/gif "access plus 8 hours"
Expi...
SNMP Monitoring




These graphs are generated by Cacti
Date     Hits        Misses      GB         Mean Hit    Hit Ratio      Hits Per Second
                                   ...
References
• Page Load Time:
 •

• Amazon EC2 Reference:
     http://www.die.net/musings/page_load_time/



 •

• Amazon W...
Amazon Cloudfront

• Price: $0.01 per 10k req, $0.17/gb traffic +
  S3 costs
• Sept: $62/hits, $253.30/traffic = $316 not
  ...
Building your own CDN using Amazon EC2
Upcoming SlideShare
Loading in...5
×

Building your own CDN using Amazon EC2

22,692

Published on

October 14 2009 New York Web Performance Group Session.

Rusty Conover is talking about his experience at InfoGears building Content Delivery Network (CDN) on top of Amazon EC2

Published in: Technology

Transcript of "Building your own CDN using Amazon EC2"

  1. 1. Scaling Websites with Amazon’s EC2 Rusty Conover (rconover@infogears.com) http://www.infogears.com
  2. 2. About Me • Co-founder of InfoGears • NYC via Montana and NJ. • Computer Science • Price comparison engine • @rusty_conover
  3. 3. Audience Survey
  4. 4. Audience Survey Amazon
  5. 5. Audience Survey Amazon Linux
  6. 6. Audience Survey Amazon Linux HTTP
  7. 7. Audience Survey Amazon Linux HTTP DNS
  8. 8. Audience Survey Amazon Linux HTTP DNS Apache
  9. 9. Audience Survey Amazon Linux HTTP DNS Apache TCP/IP
  10. 10. Audience Survey Amazon Linux HTTP DNS Apache TCP/IP Megabits
  11. 11. Audience Survey Amazon “Expires” Header Linux HTTP DNS Apache TCP/IP Megabits
  12. 12. Audience Survey Amazon “Expires” Header Linux Regular HTTP Expressions DNS Apache TCP/IP Megabits
  13. 13. Audience Survey Amazon “Expires” Header Linux Regular HTTP Expressions DNS Proxy Servers Apache TCP/IP Megabits
  14. 14. Audience Survey Amazon “Expires” Header Linux Regular HTTP Expressions DNS Proxy Servers Apache Hash TCP/IP Algorithms Megabits
  15. 15. Audience Survey Amazon “Expires” Header Linux Regular HTTP Expressions DNS Proxy Servers Apache Hash TCP/IP Algorithms Megabits TCP Windowing
  16. 16. The Problems • If the site’s slow, users leave dissatisfied which often means lost sales. • Bandwidth is relatively expensive. • It’s hard to anticipate needs. • Resources (time, money and people) are always limited.
  17. 17. Other Concerns • Thousands of people all want to watch your video at once. • Viral campaigns • The unexpected media mention.
  18. 18. The solutions Content Distribution Networks Load Balancers Reverse Proxying
  19. 19. Content Distribution Designer Client Tokyo Internet Seattle DNS Returns closest server to San Fran client. CDN Master Sydney Client New York Example Providers:
  20. 20. Load Balancer Client Internet Designer Server 1 Server 2 Content is pushed Server 3 to each server. Load balancer sends requests to a server it chooses based on a heuristic. Server 4 All traffic goes through the load balancer. Server 5
  21. 21. Reverse Proxy Client Internet Designer Content placed Actual Server on actual server. Proxy server checks if request is cached, if not it pulls from the actual server and caches for future requests.
  22. 22. Our Solution Client Internet Request for Request for Static Content Dynamic Content Server Farm Proxy/Cache server serves requests at 250mbit/sec. Normal bandwidth is 3mbit/sec.
  23. 23. Amazon’s EC2 Allows you to have as many virtual machines as you’d like. • Basic - 1.0 Ghz 2007 Xeon 1.7 GB RAM, 160 GB storage. • Large - 8 CPUs, 15 GB Ram, 1680 GB storage, 64-bit platform.
  24. 24. Bandwidth... • Amazon EC2’s bandwidth is about 250 - 1000Mbps. • You’re only billed for what you use. Making it cheap, but different than what you’re used to. • Amazon is located closer to peering points. There are East Coast and Europe DC’s.
  25. 25. Pricing It’s all usage based, with discounts. Bandwidth CPU Usage $0.10 per GB (incoming) $0.03 per hour Small $0.17 per GB $0.12 per hour Large (first 10 TB outgoing) Billed the entire time the Free between S3 and EC2 machine is online.
  26. 26. Limitations of EC2 • When an instance is shutdown all of the disks are wiped. Cache is cleared. • There are no guarantees that a particular machine will remain up.
  27. 27. So what’s it good for? 1. Parallel processing tasks without building a server farm. 2. Building cache servers to serve your content on quickly and cheaper than you can. 3. Bragging about how your infrastructure is in “the cloud”.
  28. 28. How to scale Most websites have both static and dynamic content Serving separately will increase response time. Static Dynamic Images,Videos, CSS, JS ASP, PHP, Perl, CGI, HTML Files that don’t change. Files that do change Larger Smaller
  29. 29. Dynamic Proxy/Cache • Static requests are only sent to the reverse proxy/cache. • Redirects to the real server if there an error http://www.foo.com/movie.mpg to http://cache.foo.com/movie.mpg
  30. 30. The Details Client PowerBook G4 Failover Server EC2 Cache (redirects) Request address of cache. Dynamic Content Requests HTTP Requests pulled into the cache and streamed to client. DNS Servers Real Servers Populate the active address Monitoring for the cache Test that the cache is live and returning good results. DNS HTTP Traffic Types DNS Update HTTP Redirect
  31. 31. A Little About EC2 • Amazon provides a number of disk images, like ISOs for base installs. • Fedora Core & Windows. • You can customize your own install but start with something small.
  32. 32. Amazon Images $ ec2-describe-images -o self -o amazon IMAGE! ami-3c03e655!cache7/image.manifest.xml!314456711494 ! available private! IMAGE! ami-20b65349!ec2-public-images/fedora-core4- base.manifest.xml amazon! available! public!
  33. 33. Create an instance Create an instance: $ ec2-run-instances ami-2103e648 Showing current instances: $ ec2-describe-instances RESERVATION! r-9a8076f3! 314456711494!default INSTANCE! i-4603fc2f! ami-3c03e655 ! ec2-72-44-35-86.z-2.compute-1.amazonaws.com ! domU-12-31-35-00-09-C2.z-2.compute-1.internal ! running! ! 0! ! m1.small ! 2008-02-20T22:07:13+0000 Stopping and cleaning up an instance: $ ec2-terminate-instances i-4603fc2f INSTANCE! i-4603fc2f! terminated! terminated
  34. 34. DNS EC2 will go down, when you least expect it. You don’t want the users to get errors and you don’t want to be sending requests to a down server for very long. Use dynamic DNS updates and keep very short TTL times for the records. Or EC2’s static addresses. Monitoring and DNS code needs to be reliable, use more then once separate network.
  35. 35. DNS Redirection If you host more then one website, generally you don’t want to setup instances for every domain. Setup one caching instance, and then create CNAME records for all of your other domains. For instance to cache requests at www.prolitegear.com I can use cache.prolitegear.com which is a CNAME for c.cache.infogears.com.
  36. 36. DNS Flowchart Reply is CNAME Request for c.cache.infogears.com cache.icebreaker.com TTL: 4 Hrs Request for c.cache.infogears.com Is Amazon server online? Yes No Reply is 4.4.4.4 Reply is 7.7.7.7 TTL: 10 seconds TTL: 10 seconds
  37. 37. The Cache Stack apache bind snmpd sshd ntpd Fedora Core 4 w/Updates
  38. 38. Setup • You need to build in mod_cache, mod_proxy & mod_rewrite. • Keep the server as small as possible, no PHP or mod_perl. • You can set it up to use a memory or disk cache. ./configure --enable-cache --enable-mem-cache --enable-disk-cache --enable-proxy --enable-proxy- http --enable-status --enable-info --enable-rewrite --disable-proxy-ftp --disable-proxy-ajp -- disable-proxy-balancer --enable-deflate --disable-cgi --disable-cgid --disable-userdir --disable- alias --disable-cgid --disable-actions --disable-negotiation --disable-asis --disable-info -- disable-filter --disable-static --enable-headers
  39. 39. Logging It’s good to judge cache hits to make sure your cache is working. LogFormat "%{Host}i %h %l %u %t "%r" %>s %b "%{Referer}i" "% {User-Agent}i" %{Age}" proxy The Age header contains the age of the cached result in seconds, if not found it logs “-”. Logs should be sent back to reliable storage every so often.
  40. 40. Proxy ProxyRequests Off <Proxy *> Order deny,allow Allow from all </Proxy> • Make sure you don’t make an open proxy. • Our proxy requests will only be the result of rewrite rules.
  41. 41. Rewrite RewriteMap lowercase int:tolower RewriteMap cachehost txt:/usr/local/apache2/conf/cache-host.map RewriteCond ${lowercase:%{SERVER_NAME}} ^(.+)$ RewriteCond ${cachehost:%1} ^(.+)$ RewriteRule ^/(.*.(gif|jpg|jpeg|png))$ http://%1/$1 [P,L,NC] RewriteRule ^/$ http://www.infogears.com [R,L] The rewrite rule is what changes the cached url into the real url to pull for the request. The map file just lists the cache host name [TAB] destination host name.
  42. 42. Host Mapping # Destination Host Source Host static-cache.gearbuyer.com! static.gearbuyer.com images-cache.gearbuyer.com! images.gearbuyer.com cache.gearbuyer.com! ! www.gearbuyer.com
  43. 43. Cache CacheEnable disk / CacheRoot /mnt/cache CacheDirLevels 3 CacheDirLength 1 CacheIgnoreCacheControl Off CacheDefaultExpire 7200 CacheMaxExpire 604800 CacheMaxFileSize 2000000000 Make sure that the cache root exists before Apache starts, otherwise it won’t start. /mnt is a good place. Make sure you have the correct permissions so Apache can write to the directory. Change the directory levels and limits to suit your needs.
  44. 44. Scaling ServerLimit 600 StartServers 20 MinSpareServers 20 MaxSpareServers 60 MaxClients 500 MaxRequestsPerChild 0 MaxKeepAliveRequests 1000 KeepAlive On KeepAliveTimeout 10 SendBufferSize 98303 Since you’re serving static requests it won’t take much RAM to scale out more processes. Keep alive connections should persist as they prevent another TCP handshake.
  45. 45. Monitoring Monitoring is important to make sure that EC2 can reach your servers, and your EC2 server is still running. I use Perl for this since it has everything I need: a way to update DNS and a way to send web requests. SNMP Traffic Monitoring is also essential.
  46. 46. Monitoring Do this forever Try example proxy request using Amazon Did it succeed? No Yes Has Amazon address already been set? Set address to No failback server Yes Set Amazon address Sleep
  47. 47. Hit Rate Set Expires header on everything you can. ExpiresActive on ExpiresByType image/gif "access plus 8 hours" ExpiresByType image/png "access plus 8 hours" ExpiresByType image/jpeg "access plus 8 hours" ExpiresByType text/css "access plus 8 hours" ExpiresByType application/x-javascript "access plus 8 hours" ExpiresByType application/x-shockwave-flash "access plus 8 hours" ExpiresByType video/x-flv "access plus 8 hours" ExpiresByType application/pdf "access plus 8 hours" You can force refreshes by doing a reload, or using wget --no-cache
  48. 48. SNMP Monitoring These graphs are generated by Cacti
  49. 49. Date Hits Misses GB Mean Hit Hit Ratio Hits Per Second Size Oct 1, 2008 44,156,082 4,559,317 936 22 89.7% 16.8 Nov 1, 2008 61,403,833 3,475,474 1,291 22 94.3% 23.3 Dec 1, 2008 66,850,143 3,896,923 1,342 21 94.2% 25.4 Jan 1, 2009 67,415,819 3,877,521 1,302 20 94.2% 25.6 Feb 1, 2009 59,252,656 3,817,855 1,107 20 93.6% 22.5 Mar 1, 2009 67,494,160 4,391,207 1,452 23 93.5% 25.7 Apr 1, 2009 58,472,655 4,823,061 1,277 23 91.8% 22.2 May 1, 2009 57,608,518 4,719,774 1,327 24 91.8% 21.9 Jun 1, 2009 55,105,350 4,658,961 1,326 25 91.5% 21.0 Jul 1, 2009 53,533,558 4,993,568 1,626 32 90.7% 20.4 Aug 1, 2009 59,870,784 5,642,222 1,371 24 90.6% 22.8 Sep 1, 2009 62,931,209 5,519,812 1,490 25 91.2% 23.9
  50. 50. References • Page Load Time: • • Amazon EC2 Reference: http://www.die.net/musings/page_load_time/ • • Amazon Web Services: http://docs.amazonwebservices.com/AWSEC2/2007-08-29/GettingStartedGuide/ • • Perl http://aws.amazon.com • • Bind Dynamic Updates http://www.perl.org • • Apache http://www.isc.org/sw/bind/arm93/Bv9ARM.ch04.html • http://httpd.apache.org
  51. 51. Amazon Cloudfront • Price: $0.01 per 10k req, $0.17/gb traffic + S3 costs • Sept: $62/hits, $253.30/traffic = $316 not counting S3 costs. • Have to preload all resources to S3. Cache has about 2.2 million objects in 36 gigs.
