GI & Liver Malignancies Bushra Ibnauf Sulieman, MD MS Consultant, Gastroenterology & Hepatology Department of Medicine Kin...
Question <ul><li>A 45 year old man was referred by his PCP because of new onset of dysphagia of 4 weeks duration. The pati...
Question <ul><li>A 45 year old man was referred by his PCP because of new onset of dysphagia of 4 weeks duration. The pati...
Pathogenesis of Adenocarcinoma GERD Reflux Esophagitis Intestinal metaplasia (Barrett’s esophagus) Dysplasia Adenocarcinoma
Barrett’s HGD
Barrett’s Esophagus <ul><li>Intestinal metaplasia of the esophagus : Replacement of the stratified squamous mucosa by spec...

Epidemiology of Esophageal Cancer in the US <ul><li>  Squamous   Adeno </li></ul><ul><li>New cases per year   ~ 6000 ~ 600...
Esophageal AdenoCa: Risk Factors <ul><li>Barrett’s mucosa: most significant (40 fold) </li></ul><ul><li>GERD </li></ul><ul...
Esophageal SCCA: Risk Factors <ul><li>Diet: </li></ul><ul><ul><li>N-nitroso compounds </li></ul></ul><ul><ul><li>Alcohol <...
Clinical Presentation & Symptoms <ul><li>Dysphagia:  </li></ul><ul><ul><li>Most common </li></ul></ul><ul><ul><li>Initiall...
Esophageal Cancer: Diagnosis <ul><li>Endoscopy: </li></ul><ul><ul><li>Location: Distal vs. proximal </li></ul></ul><ul><ul...
Esophageal Cancer: Diagnosis
Question <ul><li>You performed an EGD, with biopsy of the mass. The results confirm your suspicions. You now wish to begin...
Staging Classification: TNM <ul><li>T : Primary tumor </li></ul><ul><ul><li>Tis: Carcinoma in situ / high grade dysplasia ...
Esophageal Cancer Staging <ul><li>Stage 0:  Tis, N0, M0 </li></ul><ul><li>Stage I:  T1, N0, M0 </li></ul><ul><li>Stage II:...
Esophageal Cancer: Survival <ul><li>STAGE   5-Year Survival </li></ul><ul><li>Stage 0:   75% </li></ul><ul><li>Stage I:  5...
Staging Tools <ul><li>Endoscopic Ultrasound (EUS) </li></ul><ul><ul><li>Best modality for locoregional staging </li></ul><...
EUS: Esophageal Cancer <ul><li>T & N staging </li></ul><ul><li>Metastasis: </li></ul><ul><ul><li>Celiac lymph nodes </li><...
7.5 / 12 MHz. 7.5 MHz. UC-30P UM-130 Mechanical Radial Scanning Curved Linear Array Scanning
EUS: Gastrointestinal Wall Mucosa Submucosa Muscularis propria Serosa Lumen Scope
T2N0 T3N0 T4N0
Treatment: Early Disease <ul><li>Stages: T is , I and IIA </li></ul><ul><li>Surgery: </li></ul><ul><ul><li>Mainstay of tre...
Treatment: Locally advanced Disease <ul><li>Stages IIB and III </li></ul><ul><li>Difficult and controvercial </li></ul><ul...
Treatment: Metastatic Disease <ul><li>Palliative  </li></ul><ul><li>Chemotherapy +/- XRT: </li></ul><ul><ul><li>Potential ...
Endoscopic Therapy <ul><li>Limited role </li></ul><ul><li>Endoscopic Mucosal resection </li></ul><ul><li>Coagulation thera...
Palliative Treatment <ul><li>XRT </li></ul><ul><li>Chemotherapy </li></ul><ul><li>Endoscopic dilation </li></ul><ul><li>En...
Screening & Prevention <ul><li>Aggressive treatment of GERD </li></ul><ul><ul><li>Medical  </li></ul></ul><ul><ul><li>Surg...
Question <ul><li>A 72 year old man presents with 10 kg weight loss, early </li></ul><ul><li>satiety and melena. He has a g...
Gastric Cancer <ul><li>Lung (1.4 million deaths) </li></ul><ul><li>Stomach (740 000 deaths) </li></ul><ul><li>Liver (700 0...
Gastric Cancer  <ul><li>Environmental : preserved meats, nitrates </li></ul><ul><li>Genetics: First degree relatives 2-3x ...
Gastric Cancer - Diagnosis
Gastric Cancer- Staging & Prognosis TNM
Other Gastric Tumors
Case  <ul><li>55 y.o. male w/ chronic active HBV, decompensated Child B cirrhosis </li></ul><ul><li>Abdominal pain and jau...
Hepatocellular Carcinoma <ul><li>One million new cases yearly worldwide; 15,000 new cases in the US </li></ul><ul><li>One ...
<ul><li>Clinical Features </li></ul><ul><li>Asymptomatic 23% </li></ul><ul><li>Abdominal pain 32% </li></ul><ul><li>Malais...
Etiology <ul><li>Cirrhosis (60-90%) </li></ul><ul><li>Alcohol </li></ul><ul><li>Hemochromatosis </li></ul><ul><li>Cardiac ...
Risk of HCC in Cirrhosis High >15% HCV HBV +iron Moderate Alcohol Low <5% Wilson PBC Autoimmune
Diagnosis <ul><li>AFP </li></ul><ul><ul><li>AFP > 20 ng/mL in > 70% w/ HCC </li></ul></ul><ul><ul><li>AFP 10-500 ng/mL in ...
Trabecular pattern, increased N:C ratio Abnormal nuclei Microtrabecular pattern, irregular hepatocytes Gastroenterology.  ...
Acinar structures, bile  Mixed acinar, trabecular structures Mitros F. Atlas of Liver Pathology. Virtual Hospital
Central vein and portal triad involvement of HCC  Bizzare hepatocyte giant cell Mitros F. Atlas of Liver Pathology. Virtua...
Histology FNH Adenoma Regenerative Nodule Well-differentiated HCC can be confused with FNH, adenoma, and macroregenrative ...
Imaging in HCC <ul><li>Multiple forms </li></ul><ul><ul><li>Rapid enhancement </li></ul></ul><ul><ul><li>Enhancing rim cap...
Radiographics.  2002; 22: 1023-1039   Axial T2, fat-sat, fast spin echo Axial T1, in-phase, gradient echo Axial T1, arteri...
Axial portal phase dynamic enhanced Coronal contrast enhanced Radiographics.  2002; 22: 1023-1039
Early arterial Portal venous Delayed FNH Adenoma Pre-contrast Early contrast No contrast Early contrast Portal venous Dela...
Management <ul><li>Resection </li></ul><ul><li>Tumor ablation </li></ul><ul><ul><li>Radiofrequency ablation </li></ul></ul...
Factors Influencing Treatment <ul><li>Tumor size, number and distribution </li></ul><ul><ul><li>Artery or venous proximity...
Surgical Resection <ul><li>Indications </li></ul><ul><ul><li>Ability to remove all the tumor </li></ul></ul><ul><ul><li>We...
CW Pinson, AASLD 1999, post-grad course
CW Pinson, AASLD 1999, post-grad course
Chemoembolization <ul><li>Technique </li></ul><ul><li>Requires hepatic arteriogram </li></ul><ul><li>Chemo agents: doxorub...
Chemoembolization <ul><li>Applications </li></ul><ul><ul><li>Tumor downsizing for resection </li></ul></ul><ul><ul><li>Pal...
Complications of TACE (197 procedures) Fever 74% Abdominal pain 45% Nausea/emesis 59% Bleeding or hematoma 7% GI bleeding ...
POST- TACE PRE- TACE CW Pinson, AASLD 1999, post-grad course
61 RCT 1 º  treatment of HCC 26 RCT  adequate control arm 14 RCT  Sample size adequate 7 RCT  TAE/TACE 7 RCT  tamoxifen He...
Prospective RCTs of TAE/TACE   #   % Child A   % response   1/2 yr    survival Lin et al. (1988) ? TAE  21    13(70%)   42...
Hepatology.  2003; 37:429-442   <ul><li>TAE improves 2-yr survival – 41% vs 27% (OR 0.53: 95% confidence interval 0.32-0.8...
<ul><li>Technique </li></ul><ul><li>Percutaneous, laparoscopic or open  </li></ul><ul><li>U/S guided probe placement </li>...
Radio-frequency Ablation <ul><li>Well tolerated and safe </li></ul><ul><li>Side effects  </li></ul><ul><li>13% complicatio...
<ul><ul><li>Radiology. 2000; 217(3):633-46 </li></ul></ul>POST-RFA PRE-RFA
Liver Transplantation in HCC <ul><li>Theoretic best treatment  </li></ul><ul><ul><li>Widest resection margins </li></ul></...
<ul><li>Current indications </li></ul><ul><li>Child B/C cirrhosis </li></ul><ul><li>TNM, stage I/II </li></ul><ul><li>Cont...
Liver Transplant for Small HCC in Patients with Cirrhosis N Engl J Med.  1996; 334(11):693-699  <ul><li>Exclusions </li></...
<ul><li>Results </li></ul><ul><li>Overall mortality 17% </li></ul><ul><li>Explanted liver examined </li></ul><ul><ul><li>P...
OLT for HCC <ul><li>Regalia et al. (2001),  122 pts   </li></ul><ul><ul><li>Single tumor <5, 3 tumors < 3cm </li></ul></ul...
Model for End Stage Liver Disease MELD Score = (0.957 x Log e (creatinine mg/dL)  + 0.378 x Log e (bilirubin mg/dL) + 1.12...
(MELD) and Allocation of Donor Livers <ul><li>3437 adult liver transplant candidates  </li></ul><ul><ul><li>Listed as 2A o...
MELD Provisions for HCC <ul><li>UNOS policy 3.6.1 (2/2002) </li></ul><ul><ul><li>T1- MELD score = 15% 3 mo pre-transplant ...
Hepatocellular Cancer Single tumor <5cm 3 tumors, each <3cm Consider liver transplant Resection Local ablation TACE Large ...
SAMA www.sama-sd.org
