  • 1. Finding Meaning in Points, Areasand Surfaces: Spatial Analysis in R Revolution Analytics Wednesday 13th June 1300 EST
  • 2. The instructor• Dave Unwin• Retired Geography professor• University of London, UK• Spatial analysis & GIS in environmental sciences
  • 3. Geography is everywhere?• Everything happens somewhere• Interest is on geo-spatial data at scales from a few meters to the planet Earth
  • 4. Spatial analysis is the name given to avariety of methods of analysis in which weuse LOCATION as an explanatory variableNB: Not all spatial analysis is spatialstatistical analysis and not all spatialanalysis is geospatial
  • 5. Typical Questions• Is there an unusual clustering of point objects such as crimes/cases of a disease/trees/whatever here that we need to worry about? If so does the point pattern help explain why?• Does this phenomenon in these areas (counties, states, countries) show spatial variation I need to know about? Does the pattern help explain why?• What is the most probable value for a continuous variable at this location?
  • 6. Characteristics of spatial data?• Almost always given: typically the analyst has no choice in their acquisition, sometimes even their formatting;• They have additional structure that defines their geometry (point, line/network, area/lattice, surface/field/geostatistical)
  • 7. Types of spatial data Objectscan be points, lines/networks or areas/lattices with L0,L1 and L2 dimension of length Fieldsare self-defining and spatially continuous: everywherehas a value (e.g. temperature, mean annual rainfall, …)
  • 8. Locating things on Planet Earth• There are many ways by which we measure our location (place name, address, ZIP/Post code , latitude/longitude, grid reference etc)• How we locate depends on context and scale• Spatial resolution of location measurements vary• For analysis we (usually) need (x, y) co-ordinates in a projected system• Need for keys to provide these data, often added after the data have been collected• GPS & GPS-enabled devices are changing this and LBS is a massive and growing industry that is changing our spatial behaviour
  • 9. Why R?• A consistent environment for statistical computing and graphics• Relative proximity to the data• Easy links to code in numerous languages and to DBMS• Easier development of new methods• Packages available to perform most analyses• Immensely supportive community
  • 10. The sp SpatialClass and its subclasses
  • 11. > library(sp)> getClass("Spatial")Class "Spatial" [package "sp"]Slots:Name: bbox proj4stringClass: matrix CRSKnown Subclasses:Class "SpatialPoints", directlyClass "SpatialLines", directlyClass "SpatialPolygons", directlyClass "SpatialPointsDataFrame", by class "SpatialPoints", distance 2Class "SpatialPixels", by class "SpatialPoints", distance 2Class "SpatialLinesDataFrame", by class "SpatialLines", distance 2Class "SpatialGrid", by class "SpatialPoints", distance 3Class "SpatialPixelsDataFrame", by class "SpatialPoints", distance 3Class "SpatialGridDataFrame", by class "SpatialPoints", distance 4Class "SpatialPolygonsDataFrame", by class "SpatialPolygons", distance 2
  • 12. What extra?• A data matrix called • A spatial data frame turbines: called turbines_spdf> turbine_df that adds three bits of lon lat ‘geography’1 -0.8716027, 52.39353 1. lon/lat become spatial2 -0.8781694, 52.393403 -0.8656111, 52.39398 coordinates4 -0.8795611, 52.39626 2. A coordinate reference5 -0.8804666, 52.39913 system (CRS) to which6 -0.8726833, 52.39631 these relate, and7 -0.8643472, 52.39723 3. A bounding box (for display)
  • 13. Why bother?You can do a lot of spatialanalysis using a simpleCartesian co-ordinatesystem such as a unitsquare, but what happenswhen you want to mergewith other geographicdata?Here is a simple example inwhich turbines_spdf hasbeen written out in KMLand then ‘mashed ‘ ontoGoogle Earth to create a‘pin’ map
  • 14. Packages for spatial dataContributed packages with spatial statisticsapplications:• Utilities: rgdal, sp, maptools• Point patterns: spatstat, VR:spatial, splancs;• Geostatistics: gstat, geoR, geoRglm, fields, spBayes,• RandomFields, VR: spatial, sgeostat, vardiag;• Lattice/area data: spdep, DCluster, spgwr, ade4.
  • 15. Making sense of it all …• This is the standard work, written by the authors of sp and some of the packages• It contains just about all you might want to know about spatial analysis in R circa 2008• Useful new packages have emerged since then
  • 16. For spatial and spatial statistical analysis?
  • 17. Three use case examples• Each illustrates the analysis of a particular class of spatial data -- points L0, area L2 and surfaces L3
  • 18. Patterns in drumlins? Our bitA ‘drumlin’ A ‘swarm of them in NI
  • 19. Adding an ‘edge’ ….Is the pattern CSR as predicted by Smalley and Unwin (1968) over forty years ago?
  • 20. Visualizing the pattern using kernel density estimation
  • 21. Simple tests against CSR ….Using Baddeley’s spatstat package ….• > # nearest neighbor tests for comparison• > clarkevans(drumlin_ppp)• naive Donnelly cdf• 1.249917 1.215380 1.233599• > clarkevans(drumlin_rr)• naive Donnelly cdf• 1.238626 NA 1.215134
  • 22. Ripleys K(d) function …NB: Modification to L(est) on RHS due to Mark Rosenstein
  • 23. In this case we conclude that the pattern ismore regular than random at short range,but then we have no evidence that it isother than CSR at longer ranges The generic question is Is there an unusual clustering of point objects such as crimes/cases of a disease/trees/ whatever here that we need to worry about? If so does the point pattern help explain why?
  • 24. Patterns in disease incidence• Where does this disease occur?• Although disease affects individuals, almost always the available information will be aggregated into some areal unit such as a postal code, electoral district, county, state or country• Such data are called lattice data and they are visualized using choropleth (‘area-value’) maps• Our questions are essentially the same as before
  • 25. Lip cancer incidencein the Districts andIslands of Scotland(Clayton and Kaldor,1987)> lips <-readShapePoly("C:scotlip",IDvar="RECORD_ID")> plot(lips)Note this is an ESRI‘shapefile’ a de factostandard for suchlattice data
  • 26. Plotting the rawnumbers?>library(sp)>spplot (lips,“CANCER”) This is a complete NO NO NO
  • 27. Plotting the rates?The data are basicallyPoisson and the numbersare low, which means thatthese rates are unstable toquite small changes
  • 28. Two alternativesProbabilities Bayesian weighting
  • 29. Chi-square mapping using ‘Pearsonian’ Residuals> sum(lips$CANCER)[1] 536> sum(lips$POP)[1] 14979894>pop_exp<-536*(lips$POP/14979894)> chisq <- (lips$CANCER-pop_exp)/sqrt(pop_exp)> lips_chi <- spCbind(lips, chisq)>spplot(lips_chi,"chisq")
  • 30. But is does it have a ‘geography’? Moran’s I is used globally  w11 w12  w1n  w w22  W =  21          wn1   wnn 
  • 31. We conclude that we are not fooling ourselves!Geographic Structure Moran’s I Expected value Variance of (E) z-score Scheme Simple contiguity 0.363263693 -0.019230769 (n=52) 0.006769752 4.6488 Delauney 0.519599336 -0.018181818 0.005068704 7.5537 Distance k=3 0.543587908 -0.018181818 0.008287442 6.1709Sphere of influence 0.483547126 -0.018181818 0.006087487 6.4306 Gabriel graph 0.371846634 -0.022222222 (n=45) 0.007022745 4.7024 Relative neighbors 0.38126027 -0.02500000 (n=40) 0.01206414 3.6988
  • 32. We conclude that the pattern is ‘real’, the disease has a geography of interest The generic question is:Does this phenomenon in these areas (counties,states, countries) show spatial variation I need toknow about? Does the pattern help explain why?
  • 33. Spatial interpolation of a continuous field In effect we take a sample of ‘heights’ and use these to estimate the value EVERYWHERE across the surface
  • 34. Spatial interpolation• The key property of the variable is that it is spatially continuous (everywhere has a value and the gradient is likewise a continuous vector field)• Given a scatter of sample measurements of the ‘height’ of some continuous variable, what is the value of this field variable at this location?• There are domain-dependent sub-questions such as: what is the gradient of the field at this point? Or : how much of the variable is below the surface (e.g. rainfall totals)• Examples might be air temperature, rainfall over some period, values of some mineral resource, ground height etc., etc.• Sometimes results can be verified by further sampling, but equally often there is no external way to test the results• The process is called spatial interpolation and there are a great many ways of doing it automatically
  • 35. Interpolation by Inverse Distance Weighting (IDW)• Estimate each and every location on a very fine grid using an inverse distance weighted sum of the height values of neighboring control points• Uses the gstat package:• A parameter ‘e’ controls the degree of smoothing
  • 36. Rendering IDW e=2.0 IDW e=1.0 IDWe=3.0
  • 37. Issues in IDW• Produces ring contours or bull’s eyes• No way of assessing the likely errors involved• No theoretical reason for the choice of the distance exponent to be used• Undesirable side effects if the control data are clustered• But it corresponds fairly well to what a human might draw
  • 38. Geostatistics: making use of spatial dependence in interpolation• For points and areas spatial dependence can complicate any statistical analysis using standard methods• Can we characterise the spatial dependence across a field and use it to produce better interpolations?
  • 39. Variography: the semi-variogram ‘cloud’
  • 40. Summary semi-variogramWe fit one or other ofthe plausible modelsto these data to derivea function thatdescribes the spatialdependence
  • 41. Interpolation by KrigingError of the estimates can alsobe mapped:
  • 42. We have our estimates over the entire area The generic question is:What is the most probable value for acontinuous variable at this location?
  • 43. Some R-fun (1) : using dismo>library(XML) #needs this> library(rgdal) #and this>library (dismo)> place<-geocode("Maidwell, > size<-extent(unlist(place[4:7]))Northamptonshire, UK") #the #what does this do?address needs to have enough to be > map<-gmap(size,type="satellite")recognized > plot(map)> place # the place object is a vector > map<-gmap(size,type="roadmap")of length 7 with a bounding box: > plot(map) ID lon lat lonmin lonmaxlatmin latmax To find places and plot1 1 -0.9030642 52.38524 -0.938073 them using Google-0.8710494 52.37016 52.40107 Earth and Maps™ location1 Maidwell, Northamptonshire, UK
  • 44. Where I live … Google Maps™Aerial photography
  • 45. Or (slightly) better known?> place<-geocode("The WhiteHouse, Washington, USA")> size<-extent(unlist(place[4:7]))> map<-gmap(size,type="satellite")> plot(map)
  • 46. Some R Fun (2): exporting KML• Due to James Cheshire UCL• The London Bicycle Hire system> library(maptools)> library(rgdal)> cycle <-read.csv("London_cycle_hire_locs.csv", header=TRUE)> plot(cycle$X,cycle$Y)
  • 47. Some R Fun (2): exporting KML (continued)• > coordinates(cycle)<- c("X","Y")• > BNG<-CRS("+init=epsg:27700")• > proj4string(cycle) <- BNG• >p4s <- CRS("+proj=longlat +ellps=WGS84 +datum=WGS84")• > cycle_wgs84 <- spTransform(cycle,CRS=p4s)• > writeOGR(cycle_wgs84, dsn="london_cycle_docks.kml", layer= "cycle_wgs84", driver="KML", dataset_options=c("NameField= name"))
  • 48. The End• Taking it further:• Applied Spatial Data Analysis with R (Bivand, Pebesma and Gomez-Rubio (2008)• Spatial Statistics with R commences 14th December 2012 at Statistics.com ™QUESTIONS ARE WELCOME

×
