Explainer: Animated 3-D Arctic Ice Volume Graph Document Transcript

  • 1. Posted for the Dot Earth blog, this is an explanation by Andy Lee Robinson -- aremarkably interesting mix of engineer, musician and other things -- of how heproduced his three-dimensional graph of changes in Arctic sea ice volume over recentdecades: Im an Englishman in Budapest, a Linux system administrator/programmer/integrator, graphic designer, consultant and pianist/composer passionately interested in everything to do with science, technology and nature. I used to work for Cap Gemini years ago and until recently was CTO of a social networking software development company trying to compete with Facebook in native languages but lost. I designed the server infrastructure and maintained the application platform, and still do out of my own pocket for the few users that are left. Ive been lucky to be relatively financially independent for the last few years beholden to noone, and this gave me freedom to spend far too much time reading and following the state of climate and the denial industry in the mainstream media, twitter, realclimate, skepticalscience, youtube, Nevens blog, thinkprogress etc etc and of course your blog and nytimes. I have been through some battles with denial trolls on youtube and other places, but it gets to be a bit soul destroying after a while, like playing tennis with smoke or playing chess with pigeons and there is no shortage of them! I also became quite fascinated with what was happening in the Arctic. (The closest I have been to it was spending an amazing weekend in Iceland in 1999). After seeing the PIOMAS Sea Ice volume data last year on https://sites.google.com/site/arcticseaicegraphs/ and Jim Pettitts graph on http://iwantsomeproof.com/extimg/sia_5.png it struck me how utterly profound and frightening this was, and that few seemed to be aware of it. While alarmists and deniers were squabbling, this was the real Titanic going down. I read a tweet from Richard Betts last month about an animated gif graph that Tamino did, where he would have liked the x-axis to cross where y=0, so I proactively modified it for him: https://twitter.com/richardabetts/status/236377175912235009 and shared it on my site: http://haveland.com/share/piomas2012.gif followed by: http://haveland.com/share/piomas2012.avi http://haveland.com/share/piomas2012.m4v http://haveland.com/share/piomas2012.mp4 and half-size versions: http://haveland.com/share/piomas2012-50pc.avi http://haveland.com/share/piomas2012-50pc.gif http://haveland.com/share/piomas2012-50pc.m4v http://haveland.com/share/piomas2012-50pc.mp4 After these, I thought it would be nice to see the data in proper 3D, and with some sense of urgency, as it looked like the ice was going to crash.
