Solar power packs Solar power packs Presentation Transcript

  • RenewAbility …renewing our sustain ‘ability’ A PRESENTATION ONSOLAR PHOTOVOLTAIC POWER PACKS
  • RENEWABILITYA Social Enterprise committedto promote sustainable living inthe communities.
  • OUR BELIEF• We know how to live sustainably.• We did.• We have just forgotten our time tested abilities.• Let’s renew our Sustain abilities’ through renewable resources.
  • OUR FOCUS- Supply-side management (Renewable Energies) - We support and create the power supply through sustainable sources like Solar energy, small wind and Bio-energy.- Demand-side management (Energy Efficiency ) - We reduce the demand for energy through LED lighting and power saving gadgets making green homes.
  • Business Segments
  • WHY SOLAR ? Sustainable energy resource Abundant Availability Simplicity of operation No-pollution and no-noise Only upfront investment, free power later Hedge against increasing conventional power tariffs.
  • WHAT IS A SOLAR PHOTOVOLTAIC POWER PACK? Solar Photovoltaic Power Pack ElectricityA Solar Photovoltaic Power Pack is a Solar Power Generation systemdesigned for meeting the energy needs of a factory/ building/ residence.It consists of:1. Solar Photovoltaic Modules2. Solar Power Conditioning Unit3. Battery Bank (Optional)
  • SCHEMATIC DIAGRAM OF SOLAR PHOTOVOLTAICPOWER PACK
  • MODELS OF SOLAR POWER PACKS GRID TIED SOLAR POWER PACKS:  DESIGNED TO EXPORT THE POWER PRODUCED FROM SOLAR UNIT TO THE GRID
  • MODELS OF SOLAR POWER PACKS OFF-GRID SOLUTIONS:  STAND ALONE POWER PACK:  MEETS THE POWER REQUIREMENT OF DESIGNED LOADS ON ITS OWN  ALWAYS DESIGNED WITH BATTERY BANK  GRID-SUPPORTIVE POWER PACK:  INTERACTS WITH GRID TO MEET THE POWER REQUIREMENT OF DESIGNED LOADS  CAN BE DESIGNED WITH OR WITHOUT BATTERY BANK  HYBRID POWER PACK:  MORE THAN ONE SOURCE OF POWER:  WIND/ BIO-ENERGY/ D.G.SET  CAN BE DESIGNED WITH OR WITHOUT BATTERY BANK  ASSURED AND UNINTERRUPTED POWER BACKUP 24/7.
  • STANDALONE SOLAR PV POWER PACK Solar Photovoltaic Power Pack which produces electricity only from solar panels and meets the load requirement.Ideal solution to those areas where gridconnection cannot be reached. Utility LoadPayback within 1 year when comparedto diesel generator in such applications Solar PCUSimple, efficient, proved andguaranteed performance for decades tocomeContinuous availability with no pollutionand no noise. Roof top mounted solar Battery Bank panels
  • GRID SUPPORTIVE SOLAR PV POWER PACK CAN BE DESIGNED WITH BATTERY BANK……Utility Load Battery Bank Solar Power Conditioning UnitSolar PV Panels Arrays Electricity board grid
  • …. OR WITHOUT BATTERY BANKUtility Load Solar Power Conditioning UnitSolar PV Panels Arrays Electricity board grid
  • HYBRID SOLAR PV POWER PACK ALSO CAN BE DESIGNED WITH BATTERY BANK……..A solar Photovoltaic power pack which can draw power frommultiple sources is a hybrid solar photovoltaic power pack Utility Load Battery Bank Solar InverterSolar PV Panel Arrays Grid Power Wind Power Diesel Generator Set
  • … OR WITHOUT BATTERY BANKA solar Photovoltaic power pack which can draw power frommultiple sources is a hybrid solar photovoltaic power pack. Utility Load Solar Inverter Grid PowerSolar PV Panel Arrays Wind Power Diesel Generator Set
  • JAWAHARLAL NEHRU NATIONAL SOLAR MISSION AMBITIOUS TARGETS:  20 GW GRID CONNECTED SOLAR POWER BY 2020  2 GW OFF-GRID SOLAR POWER BY 2020 BOUQUET OF INCENTIVES:  CAPITAL SUBSIDY  INTEREST SUBSIDY: THRU’ I.R.E.D.A  TAX BENEFITS; THRU’ FASTER DEPRECIATION ENSURING SYTEM RELIABILTY:  STRICT PRODUCT NORMS  MOST B.O.M TO MEET IEC STANDARDS  PRODUCT WARRANTIES: PANELS FOR 25 YEARS  MANDATORY A.M.C
  • ECONOMICS OF SOLAR PHOTOVOLTAIC POWER PACK SAMPLE CASE STUDY:  MODEL: GRID-SUPPORTIVE  BATTERY BANK: NO  CAPACITY: 50 KWP  ENERGY YIELD: 86,000 UNITS (kWh) PER YEAR  = 235 UNITS (kWh) PER DAY
  • ECONOMICS OF SOLAR POWER PACK (50 KWP, GRID SUPPORTIVE, NO BATTERY BANK) COST RETURNS (in Rs Lakhs) (in Rs Lakhs)  UNITS OF POWER SYSTEM COST: 95 GENERATED/ YEAR: 86000 Less: Subsidy : 28 Less: Tax benefit: 23  AVERAGE COST OF POWER GENERATED: Rs 8 NET COST : 44  AVERAGE SAVINGS PER YEAR : Rs 6.88 Lakhs PAYBACK PERIOD: AROUND 6 YEARS COST OF POWER FOR THE NEXT 19 YEARS: ZERO
  • ADVANTAGES OF SOLAR PHOTOVOLTAIC POWER PACK One time upfront investment Solar power comes with no noise and no pollution Pay to the bank what you pay to the electricity board After payback period, you will get solar power absolutely free every year Hedge against hikes in diesel/ tariff rates Avoid misuse/ risks in diesel usage
  • OUR EXPERTISE IN SOLAR POWER PACKS Siteand Project Analysis System Design and BOM Finalization BOS (Balance of Systems) Selection Erection and Commissioning Project Management Financing Support/ Promotion Operations and Maintenance
  • OUR EXPERIENCE IN SOLAR PHOTOVOLTAIC POWER PACKS Installed Capacity: 237 kWp till date  Educational Institutes  Telecom Towers  Industries  Residential Buildings
  • RENEWABILITY …renewing our sustain ‘ability’CONTACT INFO: Url: www.renewability.in Corp.Office: Plot No 85, II Floor, Phase III, SVCIE, Balanagar, Hyderabad. Phone: +91-40-23772345Regd. Office: 931, Vivekananda nagar colony, Kukatpally, HYDERABAD –72 Email: sekhar@renewability.in Mobile: +91-98662 41474
