    Scalable systems management with puppet Scalable systems management with puppet Presentation Transcript

    • Scalable Systems Management with Puppet Nick Jones and Stephen McNally HPC Operations Group August 2, 2010
    • National Institute for Computational Sciences
      • NICS is a collaboration between UT and ORNL
      • Awarded the NSF Track 2B ($65M)
      • Phased deployment of Cray XT systems
      • Staffed with 25 FTEs, funding for 15 more
      • Total JICS funding ~$92M
    • #4 Top500 June 2010
    • Topics
      • Challenges that System Administrators Face
      • Why Puppet?
      • Puppet Installation and Configuration
      • Managing Your Infrastructure with Puppet
      • Advanced Puppet Topics
      • Hands On Exercises
    • Wireless
      • GlobalMeetingWireless
      • Passcode: TG10
    • Challenges that System Administrators Face
    • What do Systems Administrators do?
      • Watch YouTube
      • Eat Fritos and Mountain Dew
      • Have big warm fuzzy secret heart
      • Rearrange Netflix queue
    • Case Studies : Your Prototypical SysAdmin
      • Has to manage lots of servers
      • Responsible for installation, maintenance, updates……the whole shebang
      • Let’s call him (or her) “Geppetto”
    • Case Study 1 : Sudo
      • Organization gets new interns
      • Need to give interns sudo privileges on appropriate machines
    • Case Study 1 : Sudo
      • The old way:
        • Edit the sudoers file on one server
        • Use scp, pdsh, rsync or some combination of the above to deploy to necessary systems
      • Pitfalls:
        • What if you have different distros, and they store the sudoers file in different locations?
        • How do you detect errors?
    • Case Study 1 : Sudo
      • The Puppet way:
        • Edit the sudoers file on one server
        • Every other server automatically pulls down the updated Puppet file and installs it into the proper location for its distro
      • Advantages:
        • Easy
        • Centralized
        • Logged
    • Case Study 2 : iptables
      • Need to collaborate with outside group
      • Must allow them SSH access to internal network
    • Case Study 2 : iptables
      • The old way:
        • Update the iptables rules to allow access from the right ip ranges
        • Copy the rules to each machine
        • Restart iptables on each machine, and check that the rule worked
    • Case Study 2 : iptables
      • The Puppet way:
        • Update the iptables rule to allow access from the right ip ranges
        • Tell Puppet to ensure that the iptables service is running
        • Each client machine automatically pulls the updated iptables rule
        • Each client intelligently knows that iptables must be restarted after a rule update, and it does this automatically using dependencies
    • Case Study 3 : Doomsday
      • Centralized web server goes down due to hardware failure
      • Must get the website back up quickly
    • Case Study 3 : Doomsday
      • The old way:
        • Multiple sysadmins get stressed out
        • Reinstall the server and reconfigure by hand
        • Restore Apache configs by hand from tape or other backup (you did backup right?)
    • Case Study 3 : Doomsday
      • The Puppet way:
        • Take any other spare server
        • Change the MAC address in DHCP to the new server
        • Puppet automatically enforces and deploys the new configuration on the new server
        • Installs and updates all necessary configurations, including ensuring that the proper services are running
    • Why Puppet?
    • What is Puppet?
      • Puppet is a configuration management utility
      • Puppet is not the only configuration management utility
    • Puppet Competitors
      • cFengine
      • Bcfg2
      • Chef
      • … ..and the list goes on
    • Puppet vs cFengine
      • cFengine focuses on managing textfiles
      • Puppet focuses on managing constructs like users, services, and packages
    • Puppet vs cFengine
      • Puppet is model driven
        • The lowest layer is responsible for resource modeling
        • Eg. User on Solaris vs User on Linux
      • The language handles high level relationships
        • Think users instead of /etc/passwd
    • Puppet Language
      • Puppet uses Ruby
      • Puppet’s Language is declarative
      • You specify the configuration – Puppet handles the implementation
        • Must use detailed specification
        • Need things like dependencies to get the full power of Puppet
    • Layers Image: Official Puppet Documentation
    • How does Puppet work? Image: Official Puppet Documentation
    • Idempotency
      • Puppet configurations are idempotent – they can safely be run multiple times
      • By default, Puppet runs every 30 minutes
      • Unlike say --- kickstart --- Puppet can detect the current state of the system
      • Won’t make changes unless necessary
    • Cross Platform Abstraction
      • Puppet doesn’t care about specifics unique to your system
      • All handled automatically (facter!)
      • Manage users, files, packages, etc. the same way regardless of OS or distro
    • Providers
      • Providers fulfill resources
        • Example: package management
        • Both ‘yum’ and ‘apt’ are valid package managers
      • Puppet uses ‘providers’ to abstract package management away from the user
    • Facter
      • How does Puppet know about your system?
        • Using the Ruby library Facter
        • Facter supports a large number of predefined facts
        • Custom facts can be defined
      -bash-3.2$ facter architecture => x86_64 domain => nics.utk.edu facterversion => 1.5.7 fqdn => example.nics.utk.edu hardwareisa => x86_64 hardwaremodel => x86_64 hostname => example id => jones interfaces => eth0,eth0_kraken_una,eth1 … .and more
    • Linux
      • Centos
      • Debian 3.1 and later
      • Fedora Core 2-6
      • Fedora 7 and later
      • Gentoo Linux
      • Mandriva Corporate Server 4
      • RHEL 3 and Later
      • Oracle Linux
      • SuSe Linux 8 and later
      • Ubuntu 7.04 and later
    • BSD/*nix/Windows
      • FreeBSD 4.7 and later
      • OpenBSD 4.1 and later
      • Mac OS X
      • Solaris 2.6
      • Solaris 7 and later
      • Windows Support (in beta)
    • Installing Puppet Table credit: Turnbull, Pulling Strings with Puppet
    • Installing Puppet Table credit: Turnbull, Pulling Strings with Puppet
    • Installing Puppet Table credit: Turnbull, Pulling Strings with Puppet
    •
    • Puppet Installation and Configuration
    • Manual Installation of Puppet Puppet is a client / server based application Puppet clients are often referred to as nodes, clients, or hosts The Puppet server is often referred to as the puppetmaster Not:
    • Manual Installation of Puppet Currently Reductive Labs offers support for the following operating systems: Linux : CentOS, Debian, Fedora, Gentoo, Mandriva, RHEL, Oracle Linux, SUSE, and Ubuntu BSD : FreeBSD, and OpenBSD Other Unix : Mac OS-X, and Sun Solaris Windows : None currently Source: http://docs.puppetlabs.com/guides/platforms.html
    • Manual Installation of Puppet
      • The Puppet client must be installed on every system – even your Puppetmaster
      • Most platforms will use the default package manager to install Puppet
      • If you use a package management system (i.e. - yum) you will automatically get most prerequisite libraries
      • Facter is not installed by default when using the package manager
      • Reductive Labs provides source tar balls in case you want to torture yourself
    • Installing Puppet on CentOS / RHEL Ensure that your package manager (yum) is configured to communicate with the EPEL repo. # rpm -Uvh http://download.fedora.redhat.com/pub/epel/5/x86_64/epel-release-5-3.noarch.rpm # yum repolist Should list epel in the left hand column
    • Installing Puppet on CentOS / RHEL # yum install -y puppet (installs the client) # yum install -y puppet-server (installs the server) # yum install -y facter # yum install -y ruby-doc (optional if you want –help to work with ruby commands) These installs will also process other dependencies such as ruby and ruby-libs
    • Configure Puppet on CentOS / RHEL
      • Once yum installation is complete you must configure Puppet
      • The /etc/puppet directory will be created after installation
      • Create a simple manifest in /etc/puppet/manifests/ called site.pp
      • The puppetmaster daemon needs a syntactically correct file to run
      • Example:
      • node default {
      • }
    • Configure Puppet on CentOS / RHEL
      • The default config file is located at /etc/puppet/puppet.conf
      • It is initially created with a basic set of options
      • These options control the behavior of the Puppet suite
    • Configure Puppet on CentOS / RHEL
      • Sample puppet.conf file (to see all values use # puppet –genconfig):
      • # cat /etc/puppet/puppet.conf
      • [main]
          • vardir = /var/lib/puppet
          • logdir = /var/log/puppet
          • rundir = /var/run/puppet
          • ssldir = $vardir/ssl
          • tagmap = /etc/puppet/tagmail.conf
          • reportfrom = puppet@sample.domain.com
          • [puppetd]
          • classfile = $vardir/classes.txt
          • localconfig = $vardir/localconfig
          • report = true
          • [puppetmasterd]
          • reports = tagmail
          • autosign = /etc/puppet/autosign.conf
    • Configure Puppet on CentOS / RHEL
      • The puppet client config looks for a system named “puppet”
      • Add an entry to DNS for the puppet master (recommended)
      • puppet IN CNAME puppetmaster
      • You could also change the config to point to a specific system (not recommended)
      • Start the puppetmaster daemon
      • # /etc/init.d/puppetmaster start && tail –f /var/log/messages
      • Ensure the puppetmaster daemon starts on boot
      • # /sbin/chkconfig puppetmaster on 2345
      • Basic puppetmaster installation is complete
    • Configure Puppet on CentOS / RHEL
      • To complete the configuration we must configure the client to run on the puppetmaster
      • Manually start the puppet client once to test
      • # /etc/init.d/puppet once -v
      • This will generate a certificate request to the puppetmaster
      • # puppetca --list (will show the waiting certificate requests)
      • Multiple ways to resolve this
        • Setup puppetmaster to automatically sign all certificates
        • Setup puppetmaster to only sign specific certificates
        • Perform manual certificate signing each time
      • We use option #2
    • Setup Certificate Autosign Option #1
      • To setup automatic certificate signing you must specify so in the /etc/puppet/autosign.conf file
      • An example of autosign.conf file that accepts every new certificate request
      • # cat /etc/puppet/autosign.conf
      • *.sample.domain.com
      • Pro’s – will automatically sign certs, when reinstalling a system the autosign.conf file doesn’t need to be updated
      • Con’s – security risk, not good to automate the certificate signing mechanism
    • Setup Certificate Autosign Option #2
      • To setup restrictive automatic signing we will use the /etc/puppet/autosign.conf file
      • Example autosign.conf file
      • # cat /etc/puppet/autosign.conf
      • server1.sample.domain.com
      • server2.sample.domain.com
      • server3.sample.domain.com
      • Pro’s – adds additional control to certificate signing, provides greater security than option #1, is a good balance of security and automation
      • Con’s – the autosign.conf file must be kept up to date
    • Setup Certificate Autosign Option #3
      • Manual certificate signing doesn’t require the autosign.conf file
      • Once the certificate request has been made you should be able to see a list of the waiting requests on the puppetmaster by using:
      • # puppetca --list
      • server1.sample.domain.com
      • server2.sample.domain.com
      • To sign a specific request run the following:
      • # puppetca --sign server1.sample.domain.com
    • Setup Certificate Autosign Option #3
      • You may verify the signed cert by running:
      • # puppetca --list --all
      • + server1.sample.domain.com
      • The “+” sign denotes a signed certificate
      • Pro’s – most secure way to sign certificates
      • Con’s – can get cumbersome when scaling your puppet installation
    • Configure Puppet on CentOS / RHEL
      • After the certificate is accepted you can retest by starting the puppet client
      • # /etc/init.d/puppet once –v
      • In syslog you will see entries similar to the following:
      • puppetd[18704]: Starting Puppet client version 0.25.4
      • puppetmasterd[18047]: Compiled catalog for server1.sample.domain.com in 0.25 seconds
      • puppetd[18704]: Finished catalog run in 2.96 seconds
      • Puppet client should start and should finish the catalog run without any errors
    • Installation is complete! Basic Puppet installation is complete! (seriously, we aren’t joking)
    • BREAK
    • Managing Your Infrastructure with Puppet
    • NICS Puppet Infrastructure /etc/puppet files/ manifests/ modules/ auth.conf autosign.conf fileserver.conf puppet.conf tagmail.conf byhost/ classes/ nodes.pp site.pp host1 / host2 / host3 / class1.pp class2.pp mod1 / manifests/ files/ templates/ init.pp Files Folders Placeholder Names
    • Sample site.pp
      • There are many ways to configure your Puppet environment
      • Here’s one way to setup your /etc/puppet/manifests/site.pp file:
      • #site.pp
      • import “classes/*.pp” #This will import every .pp #file in the classes directory
      • import nodes #This will import the nodes.pp file that #lives in /etc/puppet/manifests
      • You can also set enterprise wide environment variables here instead of specifically defining them within each node
      • Environment variables can be used in templates
    • Classes vs. Modules
      • Why use the classes directory and the modules directory?
      • Classes are more global and usually contain many different modules
      • Modules are the smallest unit of measure that Puppet builds from
      • Here are some sample classes that we use:
      • badservices.pp, cluster.pp, disable_accounts.pp, diskcheck.pp, homedirs.pp, hpss.pp, infrastructure.pp, ipmi.pp, packages.pp, python_env.pp, rootmail.pp, security.pp, snmp.pp, subversion.pp, yumconfig.pp, yumreposerver.pp
    • Building Puppet Modules
      • We store all of our modules in /etc/puppet/modules
      • This is referenced in our /etc/puppet/puppet.conf file under the puppetmaster section
      • Here are some of the modules we have created over time:
      • accounts, iptables, named, oncalldb, postfix, rt, syslogng, amie_gold, cron, openssl, postgresql, dhcpd, grid_tools, lustre, moab, networking, otp, psacct, subversion, drupal, nfs, passwd, puppet, sudo, cacti, httpd, mysql, pbstools, splunk, sysctl, console, infiniband, ldap, mailman, nagios, ntp, php, ssh, syslog
      • You don’t have to create all of your modules up front
      • Work on one application (module) at a time until everything is in Puppet
    • Building Puppet Modules
      • This method of storing modules separately in /etc/puppet/modules assists in management
      • We can store module specific files within the module instead of all together
      • If you’re working on a module, you can stay in that module until you are finished and ready to test
      • Inside each module, we have two main directories: manifests and files
      • The file directory houses the module specific files
      • The manifest is where the module’s definition lives (init.pp)
    • Sample module init.pp
      • Below is a simple example of the named (DNS) class:
      • class named {
      • package {
      • bind: ensure => installed;
      • bind-chroot: ensure => installed;
      • }
      • service { "named":
      • enable => true,
      • ensure => running,
      • require => [ Package["bind"], Package["bind-chroot"] ];
      • }
      • file { "/var/named/chroot/etc/rndc.key":
      • path => "/var/named/chroot/etc/rndc.key",
      • source => "puppet:///named/var/named/chroot/etc/rndc.key",
      • require => [ Package["bind"], Package["bind-chroot"] ];
      • }
      • }
    • Module Files
      • What goes in the files directory?
      • These files can be anything from configuration files to custom scripts
      • Gives the system administrator the ability to control any file
      • This doubles as a security measure and as a standardization practice
      • We store our files in the same directory structure as the final configuration
      • The “puppet” user must be able to read the files
      • Simplifies system administration
    • Sample Infrastructure Class
      • Our infrastructure.pp class uses several different modules
      • class infrastructure {
      • include puppet
      • include yumconfig
      • include syslog
      • include security
      • if $ntp_server {
      • include ntp::server
      • } else {
      • include ntp
      • }
      • include ldap
      • include console
      • include badservices
      • }
    • What is a template?
      • Puppet templates are flat files containing Embedded Ruby (ERB) variables
      • An example ssh_config template follows:
      • Protocol <%= ssh_Protocol %>
      • <% if ssh_ListenAddress != &quot;&quot; %>
      • ListenAddress <%= ssh_ListenAddress %>
      • <% end -%>
      • SyslogFacility <%= ssh_SyslogFacility %>
      • RSAAuthentication <%= ssh_RSAAuthentication %>
      • PubkeyAuthentication <%= ssh_PubkeyAuthentication %>
      • UsePAM <%= ssh_UsePAM %>
      • AcceptEnv LANG LC_CTYPE LC_NUMERIC LC_TIME LC_COLLATE LC_MONETARY
      • AcceptEnv LC_PAPER LC_NAME LC_ADDRESS LC_TELEPHONE LC_MEASUREMENT
      • AcceptEnv LC_IDENTIFICATION LC_ALL
      • X11Forwarding <%= ssh_X11Forwarding %>
      • NoneEnabled no
    • ERB variable declaration
      • Ruby ERB variables can be set in different places
      • They can be specified in the class that calls them:
      • class resolv {
      • $searchpath = &quot;testing.com&quot;
      • $nameservers = [&quot;192.168.0.1&quot;, &quot;192.168.0.2&quot;]
      • file { &quot;resolv.conf&quot;:
      • name => &quot;/etc/resolv.conf&quot;,
      • content => template(&quot;resolv-template.erb&quot;)
      • }
      • }
    • ERB variable declaration
      • Or you can set them for each node in /etc/puppet/manifests/nodes.pp
      • node server1 {
      • $searchpath = &quot;testing.com&quot;
      • $nameservers = [&quot;192.168.0.1&quot;, &quot;192.168.0.2&quot;]
      • include resolv
      • }
      • node server2 {
      • $searchpath = &quot;testing.com&quot;
      • $nameservers = [&quot;192.168.0.1&quot;, &quot;192.168.0.2&quot;]
      • include resolv
      • }
    • Hands on Exercises
      • Install and configure Puppet client/server
      • Create a basic MySQL client module
      • Create a basic MySQL server module
    • Install and Configure Puppet client / server
      • Using the handouts install and configure the Puppetmaster and Puppet client
      • These systems are CentOS 5.5 virtual machines
      • Login and pw will be given
    • Create a module
      • Now that we have Puppet up and running, create a MySQL client module using the handout
      • Once you have created the MySQL client module, we would then like to work through creating a MySQL server module
    • Advanced Puppet Topics
    • Module Dependency
      • Module dependencies can serialize module installation
      • Handy when an application needs to have certain files in place before installing the rest
      • Puppet runs in a “shotgun” manner
      • Different pieces of each class are installed a completely different times
      • This is where module dependency comes in
      • Example: YUM repositories and application specific installs
    • Intra-module dependencies
      • Most of the time dependencies are in the context of the same module
      • The application must be installed before it is configured
      • class rt {
      • package {&quot;rt3&quot;:
      • ensure => installed,
      • }
      • file {
      • &quot;/etc/rt3/RT_SiteConfig.pm&quot;:
      • source => &quot;puppet:///rt/etc/rt3/RT_SiteConfig.pm&quot;,
      • ensure => present,
      • owner => apache, group => apache, mode => 640,
      • require => Package[rt3];
      • }
      • }
    • Inter-module dependencies
      • The more complex your Puppet environment becomes the greater the need for inter-module dependencies are.
      • This is where a specific resource defined in module “A” is dependent on a resource in module “B”
      • class rt {
      • package {
      • &quot;rt3&quot;:
      • ensure => installed,
      • require => Yumrepo[epel];
      • &quot;mod_fcgid&quot;:
      • ensure => installed;
      • &quot;perl-Authen-PAM&quot;:
      • ensure => installed;
      • }
      • }
    • Module Inheritance
      • Inherit statements do exactly what they sound like they do
      • Come in handy when you only need to change something specific for a node or two
      • class ntp::verne inherits ntp {
      • file { &quot;/etc/sysconfig/ntpd&quot;:
      • ensure => file,
      • source => &quot;puppet:///verne/etc/sysconfig/ntpd&quot;,
      • owner => root,
      • group => root,
      • mode => 0644,
      • notify => [ Service[ntpd], ],
      • }
      • }
    • Optimize your MySQL modules for use with dependencies
      • HINT - The MySQL server module should have an inheritance from the MySQL client module
    • Proper Cluster Management
      • Clusters should be managed with “classes” not “modules”
      • Here’s an example of our /etc/puppet/manifests/cluster.pp
      • class cluster {
      • include puppet
      • include yumconfig
      • include syslog
      • include sysctl
      • include ntp
      • include homedirs
      • include ldap
      • include console
      • include psacct
      • include security
      • }
    • Proper Cluster Management
      • More recent version of Puppet support ruby regex
      • Here’s an example of how to efficiently manage a cluster of 10
      • node /^clusternode[0-9]+/ {
      • $disable_ipv6 = False
      • include cluster
      • include kernel-utils
      • boot_kernel { &quot;2.6.18-164.15.1.el5&quot;: }
      • }
      • To test out your ruby regex use:
      • http://rubular.com/
    • Questions?? Nick Jones [email_address] Stephen McNally [email_address]
