John Adams Puppet Camp 2010

Puppet at High Scale John Adams, Twitter

First, the bad news! (*) (*) We’re on 0.25.4. Things may be different now.

Problems Sort of idempotent Ruby file transfer is inefficient Minimize use of recursion (home dirs, etc.) Single run is non-deterministic Order matters if order is specified Not specifying dependency order creates out of order delivery

Working Together Puppet is great with a small team Management is hard with a large number of admins Unforeseen interactions between changes No simple means of review

Security Anyone who can check into the tree can kill production with simple mistakes SVN access is effectively root equivalent Divergence from desired conﬁguration through use of chattr +i puppetmanagedfile You can’t chattr +i with broken ﬁngers.

Puppet DSL Puppet DSL not Ruby enough Stated as a plus, but really a minus when most engineers expect Ruby Incomplete conditionals in the DSL

Cron Removing conﬁguration for a cron job leaves the cronjob behind Need to specify ensure => absent If you forget the command with absent, duplicate cronjob entries can occur The vestigal tail of these “ensure absent” lines end up living in the conﬁg long after they are needed

Cron + NTP NTP synchronizes the system time Cron granularity is one second Performance regression if you make puppet install many jobs across different modules, on the same zero second Introduce random delays before jobs sleep $(($RANDOM % 60)); do_something...

Test and “Canary” No facility in puppet for testing Monolithic design Controlled Deploys are preferable to “full change” Use representative machines ﬁrst Push to cluster when everything works.

Machine Database Node membership to classes, and the nodes themselves in a puppet conﬁguration are not well exposed. Once entered, parsing is the only option to retrieve the machine list and associated “roles” from the SVN tree. ldapnodes is a possible solution here.

Node Class Changes Still an unsolved problem Removing class deﬁnition from a node leaves all of the conﬁguration from the class behind Have to re-kickstart the host to get to a base state

Why Puppet?(*) (*) the good news!

Conﬁguration Management Our world is changing. The end of the “Systems Administrator” The beginning of “DevOps”

Conﬁguration Management Consistent edits Trackable Changes Consistent ability to Rebuild Find Variance

DevOps Stop Wasting Time Start Delivering Great Ops Software Stop administering individual machines.

DevOps Puppet deﬁnitions are code Incorporate Cross-functional skills. Build a bridge between your developers and the ops team.

Let’s ﬁx This.

Change Process initial Generate Review. HEAD commit Ad-hoc tests.

Change Process HEAD test integrate ~10% of hosts Watch for failures! TEST Test Integration

Change Process HEAD TEST production integrate 100% Production Final Review

Change Process HEAD cherry pick TEST (bypass) Production No Review.

Testing / Staging A test infrastructure is needed to ensure that updates don’t kill production People make mistakes Treat the puppet conﬁg as if it were code

Security Restrict access to SVN tree itself (through ACLs) Create a concept of an OWNER for each module and manifest subdir; restrict access. Enforce ownership during SVN checkin Enforce a proper review process

SVN can be smarter Post-Commit checks BIND (Verify zones, DNS, SOA++) A mistake here is a full site outage Verify puppet conﬁg Create Reviewboard Entries

puppet-util A script on each box to select the current branch Set the branch (by modifying facter fact + conﬁg) Show current branch Enable or Disable puppetd in emergencies or ad-hoc testing

Reviewboard www.reviewboard.org Visualize and centralize change Keep teams informed Prevent Unknown Interactions

User Security Distrust puppet for creating user accounts Build them from an LDAP infrastructure Base package connects to LDAP and creates users based on group and machine role You still have to deal with RPMs creating system users

Machine Database No machine database in puppet We used Django, MySQL, but you could use LDAP Role membership imported to DB by parsing existing puppet deﬁnitions and special variables in the node stanza

Ad hoc scripting No facility in puppet for immediate execution of command on many hosts SSH in a loop is not a solution at scale Threaded SSH system through our own tool Uses Paraminko open source (Python) see also: func

Multiple Instances Three complete puppetmasterd instances on each puppet master machine, on different ports, pointed to different SVN branches HEAD TEST PRODUCTION

Handling many clients Distribute: the SVN tree (eliminate the SPOF) Use more puppet servers Rsync manifests, then run puppet Selectively update hosts (func)

Puppet Web Server Don’t run WEBRick (script/server) - too slow Unicorn (best choice) Passenger (mod_rails) mongrel?

Distributed Puppet SVN PM PM PM host host host host host host host host host host host host host host host

Distributed Puppet Too many clients eventually overwhelm the Master You must deploy more hosts Distribute cron jobs Randomize start times Distribute the master itself

Questions?
