"Puppet at GitHub / ChatOps" from PuppetConf 2012, by Jesse Newland
...
"Puppet at GitHub / ChatOps" from PuppetConf 2012, by Jesse Newland
Video of "Puppet at GitHub": http://bit.ly/WVS3vQ
Learn more about Puppet: http://bit.ly/QQoAP1
Abstract: Ops at GitHub has a unique challenge - keeping up with the rabid pace of features and products that the GitHub team develops. In this talk, we'll focus on tools and techniques we use to rapidly and confidently ship infrastructure changes/features with Puppet using Puppet-Rspec, CI, Puppet-Lint, branch puppet deploys, and Hubot.
Speaker Bio: Jesse Newland does Ops at GitHub. His favorite hobby is SPOF wack-a-mole, followed closely by guitar and piano. Prior to GitHub, Jesse was the CTO at Rails Machine where he ran a large private cloud and managed several hundred production Ruby on Rails applications using Puppet. To the delight and/or chagrin of the Puppet community, Jesse is to blame for Moonshine, the Ruby DSL for Puppet before Puppet had a Ruby DSL.
Jesse Newland jnewlandhey errbodymy name is jesse newlandI do ops at GitHub
Puppet at GitHubAnd today I’m going to be talking about Puppet at GitHub.Really, I’m telling a story in two parts.
All of the amazing Puppet OSS projects @rodjek has written but doesn’t want to talk aboutFirst... I’ll be talking about all of the amazing Puppet open source projects Tim Sharpe haswritten but doesn’t want to talk aboutand how we use them at GitHub
*And then, I want to introduce you to the star of the GitHub Ops team, Hubot, and tell you alittle bit about something we’ve been calling ChatOps
the SetupBut, before I get into all of that, Im actually going to talk about anupcoming talk, one by a coworker of mine at GitHub. Will Farringtonis going to be speaking tomorrow at 2:45pm about The Setup, ourPuppet-powered GitHubber laptop management solution. Itsamazing. Its one of the coolest uses of Puppet Ive ever seen, andits going to completely change the way you think about yourdevelopment environment.But I’m not going to be talking about any of that today.So, yeah, go to Wills talk tommorrow. You wont be disappointed.
Puppet at GitHubSo I guess you could say that I’m talking about
THE of REST Puppet at GitHubthe rest of puppet at github. For the scope of this talk, I’m going to be talking about thePuppet infrastructure that runs github.com
4 years, >100k LOCWe’ve been managing GitHub’s infrastructure with Puppet for 4 years, since the move toRackspace. There’s a ton of code, and we’re developing at a rapid pace.
SimpleBut we are obsessed with keeping our Puppet deployment simple
Single MasterWe use a single puppetmaster running lots of unicorns. Nothing fancy. It works for now.However, we will need to scale this tier up or out in about 6 months if the trends look right.We’ll probably switch to two load balanced puppetmasters around that time.
cron FTW # cat /etc/cron.d/puppet 13 * * * * root /usr/bin/We don’t run the agent, but rather run puppet on cron every hour in combination with runstriggered via Hubot (more on that later)
No ENCWe don’t use an external node classifier
([a-z0-9-_]+)(d+)([a-z]?).(.*).github.com $ cat manifests/nodes/janky.rscloud.pp node /^jankyd+.rscloud.github.com$/ { github::role::janky { janky: public_address => dns_lookup($fqdn), nginx_hostname => $fqdn, } }Instead, we give nodes DNS names that adhere to a naming convention that maps them to apre-defined role
Where the magic happens$ head modules/github/manifests/role/janky.ppdefine github::role::janky($public_address, $nginx_hostname=, $god=true ) { github::core { janky: } include github::app::janky github::nginx { janky: }}Role definitions are where the magic happens. We try to DRY common functionality into ourcore module and into other simple classes or defines so that role definitions read like a nicesummary of what makes this role different from others
Heavy use of augeas augeas { my.cnf/avoid_cardinality_skew: context => /files/etc/mysql/my.cnf/mysqld/, changes => [ set innodb_stats_auto_update 0, set innodb_stats_on_metadata 0, set innodb_stats_on_metadata 64 ], require => Percona::Server[$::fqdn], }We generally try to avoid templates for configuration files in favor of using aw ge usLets us manage the small pieces of configuration we care about and use the OS defaults forthe things we dont.
BORINGBut I don’t want to just show all of you Puppet code for thirty minutes. Thats boring
What’s interesting about Puppet at GitHub?I’d rather talk about whats interesting about how we use Puppet at GitHub. And what I thinkis the most interesting is that we focus heavily on ensuring the Puppet development workflowis easily accessible to everyone at GitHub.
Making Puppet Less ScaryWe’re doing our best to make puppet less scary for people that aren’t familiar with it, so theycan help the Ops team grow and evolve our infrastructure. We’re doing some things righthere, but there’s still a lot of work to do.
I’ve been thinking about this a lot recently as we’ve just had two large infrastructure projectsshipped by people that were completely or relatively new to puppet. First, Derek Greentreeshipped a Cassandra cluster,,,
And Adam Roben shipped puppet manifests for our windows build and CI servers.
this is goodThis is an awesome trend, and I want it to continue. So I thought I’d talk a bit today aboutwhat we’re doing to try to enable even more of this.
Flow just like a (GitHub)Ruby projectFor us, an important part of making Puppet development accessible for other developers atGitHub is making the development flow on our puppet codebase as similar as possible to thatof any other GitHub Ruby project. That means sticking with some common conventions
Setup $ ./script/bootstrapLike making it as easy to setup as any other project at GitHub
$ cat Puppetfileforge "http://forge.puppetlabs.com"mod puppetlabs/apt...And puppet deps are managed by librarian-puppet, a bundler-like library that manages thepuppet modules your infrastructure depends on and install them directly from GitHubrepositories.I’m of the opinion that the unit of open source currency is no longer a tarball downloadedfrom a something named *forge. It’s a GitHub repo. All of the developers at GitHub feel thesame way, so Tim wrote librarian puppet
rodjek / librarian-puppetFor those of you keeping score at home, that’s the first of Tim Sharpe’s open source projectsthat I’ve mentioned. Hi Tim!
Making puppet flow like other projects at GitHub means ensuring we have good editorsupport for the language
rodjek / vim-puppetvim-puppet, that’s two.
Tests $ ./script/cibuildIt means running tests is a simple one-step process
TESTS!Tests are super important. A solid and easy to use test harness helps build developerconfidence in a new language.
Safety netAnd tests are crucial safety net for helping people cut their teeth on Puppet if they haven’tever touched it before.
rspec-puppet should contain_github__firewall_rule(internal_network) should contain_ssmtp__relay_to(smtp).with_relay_host(smtp) should contain_file(/etc/logstash/logstash.conf) should include_class(github::ksplice) should contain_networking__bond(bond0).with( :gateway => 172.22.0.2, :arp_ip_target => 172.22.0.2, :up_commands => nil )We use rspec-puppet heavily. If you haven’t used rspec-puppet yet, go check it out rightnow.It’s amazing.There are no less than three talks about it at Puppetconf, so I’m not going to talk about HOWto use it today, just touch a little bit on how WE use it.
rodjek / rspec-puppetrspec-puppet, that’s three
role describe github::role::fe do let(:title) { fe } let(:node) { fe1.rs.github.com } let(:params) { { specs :public_address => 207.97.227.242/27, :private_address => 172.22.1.59/22, :git_weight => 16 } } let(:facts) { are { :ipaddress => 172.22.1.59, :operatingsystem => Debian, :datacenter => rackspace-iad2, } king } it do should contain_github__core(fe) ... end endWe try our best to adequately test our individual puppet modules, but our central and mostfrequently touched specs exercise our role system. There’s one spec for each role whichdescribes its intended functionality.These specs focus on critical functionality of each role, and help a great deal to buildconfidence that we’re not introducing regressions when adding or refactoring functionality orworking in other roles.
.git/hooks/pre-commit $ git commit -am "lolbadchange" modules/github/manifests/role/fe.pp:err: Could not parse for environment production: Syntax error at allow_outbound_syslog; expected } at /Users/jnewland/github/puppet/modules/github/ manifests/role/fe.pp:31 modules/github/manifests/role/fe.pp - WARNING: => is not properly aligned on line 626For an even faster feedback loop than running specs, all Puppet dev environmentsautomatically get setup with a pre-commit hook that checks for syntax errors and ensuresyour changes confirm to the Puppet Style guide.This has proved amazingly useful for Puppet novices and experts alike, novices finding ithelps them understand language conventions quickly and guides them towards solutions,and experts using it to catch typos and help them not look like novices.
specs run on each push auto deploy on CI passrspec-puppet and puppet-lint are automatically run by CI on every commit on every branchpushed to our Puppet repo.Once master passes CI, puppet is automatically deployed
As you can see, Hubot automates a lot of the process of rolling out PuppetThat example covered pushing changes to master, but what about a Pull-Request basedworkflow?
Say we have a pull request for a branch we want to merge, and that we’ve reviewed the codeand it all looks good.
branches == environmentsOn each deploy, we turn all git branches into puppet environments.
This combined with heaven, our capistrano-powered deployment API we interact with viaHubot, enables us to experiment with unmerged Puppet branches in a powerful way
So, to safely merge this pull request...
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubYou might ask Hubot to confirm its build status
Build #108816 (5fe75932f26ea62cb5fc5e3d0cb302cc2461d11e) of puppet/git-gh13 was successful(421s) github/ puppet@567ea48...5fe7593Yup, looks good.
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubThen roll the branch out to a staging box to make everything applies cleanly there.
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubThen, if you wanted an extra layer of confidence, you could noop the branch against aproduction node
** [out :: REDACTED ] Bootstrapping... ** [out :: REDACTED ] Gem environment up-to-date. ** [out :: REDACTED ] Running librarian-puppet... ** [out :: REDACTED ] Generating puppet environments... ** [out :: REDACTED ] Cleaning up deleted branches... ** [out :: REDACTED ] Done! ** [out :: REDACTED ] Sending restart command ** [out :: REDACTED ] The following watches were affected: ** [out :: REDACTED ] puppetmaster_unicorn ** [out :: fs1a.rs.github.com] info: Applying configuration version 8fb1a2716d5f950b836e511471a2bdac3ed27090 ** [out :: fs1a.rs.github.com] notice: /Stage[main]/ Github::Common_packages/Package[git]/ensure: would have changed from 1:1.7.10-1+github12 to 1:1.7.10-1+github13 ...Yup, looks good
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubNext, you’d merge the pull request. If you stopped here, the code would gradually roll out toall affected nodes over the next hour.
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubIf you wanted the rollout to happen faster than that, you could force a puppet run on theaffected class of nodes
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubThen you’d probably want to check out load to make sure nothing went crazy
Yup, looks good
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/github...and maybe check some logs or other related metrics to confirm your change didn’t breaksomething
Yup, looks good
ChatOpsHow we interact with Puppet via Hubot is a great example of a core principal of how we doops at GitHub. We’ve been calling it ChatOps recently.
Essentially, ChatOps is the result of Hubot becoming sentient, and decreeing, among otherthings, that we now address him as “Supreme Leader” and communicate with ourinfrastructure though his secure channels alone.We occasionally observe him speaking in tongues that sound eerily like YouTube comments.
HubotActually, that’s not it at all. Hubot is the star of our Ops team.
heaven shell Hubot janky graphmeWe use hubot day in day out to interact with other simple tools we’ve written over JSON apis.
ALL OF hubotshell heaven jankyTHE APIS graphmeHubot interacts nicely with tons of external APIs too. If you have a JSON API, making yourservice work with Hubot is a piece of cake.
Why is this stupid chat bot so important to Ops?But why do we obsess about Hubot so much? It’s just a chat bot, right?There are some distinct upsides to this approach we’ve notices as our use of Hubot in Opshas grown
hubot ci status puppet/git-gh13 deploy:apply puppet/git-gh13 staging/fs1 deploy:noop puppet/git-gh13 prod/fs1 # merge pull request hubot deploy:apply puppet to prod/fs graph me -1h @collectd.load(fs*) log me hooks github/githubRemember the flow I just showed you for rolling out puppet changes to our infrastructure?
Everyone sees all of that happen on their first dayEveryone sees all of this happen from the minute they join GitHub. It’s right there, in the Opsroom, right in the middle of the conversation in campfire.
You don’t just see how to roll out puppet, you see how to...
hubot ci status github/smoke-perfcheck the status of branch’s last build
hubot deploy github/smoke-perf to prod/fe1deploy a any branch of any github app to any server
hubot graph me -10min @app-perfget graphs of the app’s recent performance
hubot procs unicorncheck the status of unicorns across all frontends
hubot resque criticalcheck the status of the resque critical queue
hubot graph me -10min @collectd.load(fe*)check load on the frontends
hubot conns fe1check current connections to a frontend that you suspect has a problem
hubot log me smoke fe1grab smoke logs for that frontend and realize that you did, in fact, break it
hubot lbctl disable fe1take it out of the load balancer
hubot status yellow Bad deploy. Reverting now.update the status blog
hubot who’s on calldetermine who is currently on call so you can apologize to them
hubot pingdom checkscheck pingdom to make sure you haven’t broken everything
hubot upset mechill yourself out really quick
hubot deploy github to prod/fe1revert back to master on the busted frontend
hubot log me smoke fe1verify things have returned to normal
hubot air drum meget pumped up because you fixed it
hubot lbctl enable fe1bring the fixed frontend back into the rotation
hubot status green All systems go.clear alerts on the status page
hubot whois 4.9.23.22Once the outage has been resolved, you might see how to grab whois information for an IPthat exhibited suspicious activity in the logs you saw
hubot khanify spammersand how to hit meme generator to make a joke when you realize that IP is a spammer
hubot play in the air tonightthen someone would queue up the song that popped into their head when they thoughtabout drums and gorillas at the same time
hubot tweet@github PuppetConf Drinkup Friday night at 8:30 at Zeke’s (3rd & Brannan)and then finish it all off with a tweet about the Drinkup we’re throwing friday night
ChatOpsChatOps means building tools that make it easier to operate your infrastructure via Hubotthan via Terminal or Chrome
By placing tools directly in the middle of the conversationBecause...
Everyone is pairing all of the timeThis is the core concept behind ChatOps.
Teaching by doingTeaching by doing is awesome
This was always my mainmotivation with hubot - teaching by doing by making things visible. Its an extremely powerful teaching technique - @rtomaykoRyan Tomayko had this in mind from the very first commits to hubot, which just presented asimple wrapper around a repository of shell scripts we use for management and monitoringour infrastructure.
This is how I respond to “how to I do X” questions in Campfire now.If there’s not yet Hubot functionality to do a thing, we try to write it.
Communicate by doingPlacing tools in the middle of the conversation also means you get communication of yourwork for free.If you’re doing something in a shell or on a website, you have to do it, then tell people aboutit. If you do it with hubot, that comes free.
THINGS IHAVEN’T ASKED RECENTLYFor example, here are a few things I haven’t asked recently because Hubot has told me theanswer
THINGS IHAVEN’T ASKED how’s that deploy going? RECENTLY
THINGS I are you deploying that or should i?HAVEN’T ASKED how’s that deploy going? RECENTLY
THINGS I are you deploying that or should i?HAVEN’T ASKED how’s that deploy going?is anyone responding to that nagios alert? RECENTLY
THINGS I is that branch green? are you deploying that or should i?HAVEN’T ASKED how’s that deploy going?is anyone responding to that nagios alert? RECENTLY
THINGS I is that branch green? are you deploying that or should i?HAVEN’T ASKED how’s that deploy going?is anyone responding to that nagios alert? RECENTLY how does load look?
did anyone update the status page? THINGS I is that branch green? are you deploying that or should i?HAVEN’T ASKED how’s that deploy going?is anyone responding to that nagios alert? RECENTLY how does load look?
did anyone update the status page? THINGS I is that branch green? are you deploying that or should i?HAVEN’T ASKED how’s that deploy going?is anyone responding to that nagios alert? RECENTLY how does load look? did that deploy finish?
Free communication is especially crucial in a distributed environment.
Our Ops team is entirely remote, so Campfire is our default means of communication.
http://www.flickr.com/photos/7997249@N06/6061305639/This is extremely helpful during outages or other situations that require tactical response.You don’t have to SAY that you’re spraying water on the fire, people SEE you doing it.
Hide the uglyAnother awesome benefit of ChatOps-ing all of the things is that you can hide ugly interfacesand design exactly the interaction you want with some simple porcelain commands
My favorite example of this is ugliest of the ugly, Nagios.
hubot nagios ack fs3b/syslog # fix stuff nagios check fs3b/syslog nagios status fs3b/syslog hubot nagios downtime fs3b/syslog 90 nagios mute fs3b/syslog nagios unmute fs3b/syslogWhich we can interact with without any unnecessary eye bleeding. Making this easy meansdevelopers and other ops engineers actually mute or schedule downtime when they’re testingthings.
Mobile FTWYet another awesome benefit of ChatOps is that you get mobile support for free
Well, that is, if you have a team of awesome iOS developers that have built an actuallyfunctioning Campfire client for the iPhoneThis lets you do anything hubot can do from your phone.Which means from your couch. Or your bed. Or a beach in Hawaii.Which means you can fix a lot of things without pulling your laptop out of your bag.
ChatOpsThat’s ChatOps at its finest.
And now for something completely differentWhile I’m showing off mobile stuff, I thought I’d slip in a demo of something else we’ve doneto make Ops more mobile friendly.
We’ve hacked together support for PagerDuty alerts via Apple Push Notifications. When youswipe on the alert, you go directly to the PagerDuty mobile UI for an incident
Which lets you ack an alert
while you’re still in bed
or on the couch.
BoomI can’t even begin to tell you how happy this makes me, and how less shitty it makes beingon-call
So, who better to summarize all of this than Hubot himself. I asked him what he thoughtabout ChatOps. Here’s what he said:
ChatOps all the things.Listen to what Hubot said. You’ll love it. Your ops team will love it.And you’ll help other developers learn how to interact with ops tools without any additionalwork.That’s awesome.
Work at GitHub jesse@github.comIf you can’t ChatOps all the things at your gig now, you could always just come work with meat GitHub.Shoot me an email if you’re interested.
Thanks!That’s all I have. Thanks for listening! any questions?
Tomorrow @ 8:30 PM Zeke’s 3rd & BrannanWhile I still have everyone’s attention, I wanted to mention the GitHub Drinkup we’rethrowing for Puppetconf again. It’s tomorrow night at 8:30pm at Zeke’s, which is on thecorner of 3rd and Brannan, everyone’s invited. I’ll see you there.Thanks again!
