    Engineered Systems: Oracle's Vision for the Future Engineered Systems: Oracle's Vision for the Future Presentation Transcript

    • Engineered Systems: Oracles Vision for the Future Ralf Dossmann Engineered Systems Lead, Public Sector Technology1 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • The following is intended to outline our general product direction. It is intended for information purposes only, and may not be incorporated into any contract. It is not a commitment to deliver any material, code, or functionality, and should not be relied upon in making purchasing decisions. The development, release, and timing of any features or functionality described for Oracle’s products remain at the sole discretion of Oracle.2 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Engineered Systems: End of an EraCopyright © 2011 Oracle Corporation 3
    • Current Standard High Touch, High Cost, Low Return • In-house platforms: – Design, Develop – Test, Document – Procure, Deploy – Operate, Maintain • Inhibits growth • Misdirects innovation • Wastes time and resources4 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Oracle Engineered Systems Hardware and Software Engineered to Work Together“We will accelerate the Engineered Systems trend…new engineered systems will optimally combine Oracle software, Oracle silicon and Oracle hardware to deliver extreme performance, fault-tolerant reliability and improved ease of use.” - Larry Ellison, Q1 FY12 Earnings Call, September 20, 2011 Oracle Engineered Systems Value Proposition • Engineered • Fastest time to market • Tested • Certified • Highest performance • Deployed Together • Easiest to manage • Upgraded • Lowest TCO • Managed • Supported • Maximum innovation: Focus of Oracle R&D © 2011 Oracle Corporation 5
    • Oracle Engineered Systems Meet the Family…Exadata Exalogic Oracle Exalytics Big Data SPARCDatabase Elastic Cloud Database In-Memory Appliance SuperClusterMachine Appliance Machine T4-4 Oracle Engineered Systems share the following characteristics: • Expedited time to value • Reduced change management risk • Easier to manage and upgrade • One-stop support • Lower cost of ownership • Extreme performance © 2011 Oracle Corporation 6
    • How Customers Leverage Oracle Engineered Systems“PHH Corporation lays a foundation for sharedservices with Oracle Exalogic Elastic Cloud andOracle Exadata Database Machine.” “Sogeti USA LLC Improves Performance and Productivity of Critical Business Systems”“TIMWE Ensures Competitive Edge withReal-Time Analysis of Marketing Campaigns” “Merck achieves fivefold performance for Critical Product Research Platform”“SquareTwo Financial expects to reduceoperating costs by 60% and bring newproducts to market more quickly.”” © 2011 Oracle Corporation 7
    • Exadata Database MachineA complete system for the database and storage tier Database Grid Intel-based database servers Oracle Linux or Solaris 11 Oracle Database 11g 10 Gig Ethernet (to data center) Storage Grid Intel-based storage servers Up to 336 terabytes raw disk 5.3 terabytes Flash storage Exadata Storage Server Software InfiniBand Network Internal connectivity ( 40 Gb/sec ) 8
    • Superior Product Capabilities: Exadata Hardware + Software Optimized to Work Together9 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Oracle Exalogic X2-2 A complete system for the application tier Compute Nodes (Servers) • Up to: 30 x86 compute nodes X2-2 Full Rack • Up to: 360 Xeon cores (2.93 GHz) Configuration • Up to: 2.8 TB DRAM, 960 GB SSD InfiniBand I/O Fabric and 10GbE • 40 Gb/sec links • 10 Gigabit Ethernet connectivity to datacenter Integrated Storage • Shared storage for applications • Clustered for HA • 40 TB SAS disk • 4 TB read cache,72 GB write cache EL X2-210 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Exalogic vs. Alternatives Building a system that can compare with Exalogic is hard Applications and MiddlewareIntegrated OS Layer OS, Kernel, Patch Level? Different Tuned Compute and CPU, RAM, Flash, Blade, Rack? Virtualization Layer EveryOptimized I/O Layer Ethernet, InfiniBand, FC? Time Identical Storage NAS, SAN, SSD, HDD? Layer 1 Engineered System 160+ separate parts Unpack to production in hours Months from start to production 11 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Exalogic - Scale on Demand Start small and grow• Designed for zero- downtime upgrades 8 Compute 16 Compute 30 Compute Nodes Nodes Nodes12 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Superior Product Capabilities: Exalogic Example: Exabus Standard Hardware I/O Exabus Application Application Application Application Application Buffer Application Buffer Copy TCP IP Transport Kernel 20% Buffer Copies Zero Buffer Copy 40% Transport Processing Direct Memory Access 40 % Kernel Context Switches Kernel Bypass 4X Throughput, 6X Lower Latency13 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Active GridLink for Oracle RAC 960 Gigabits/second (Maximum: 24x InfiniBand QDR)Exalogic Exadata • Exclusive: direct InfiniBand integration! • Extreme performance, reliability, security • Simple to deploy and manage Up to 3X OLTP Performance Active GridLink for RAC • Resource-aware load balancing • Instantaneous connection failover • Transaction affinity to RAC nodes • SQLnet optimized for InfiniBand SDP14 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Benefit #1: Simplification, Fast Time-To-Market Exalogic Setup in Ten Hours15 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Benefit #2: Better Performance (Fusion Middleware) Unmatched Throughput, Responsiveness and Efficiency 520ms 240,000 1.1ms 7X 9X 10X 17,340 tps 3X 5,640 tps 0.16ms 58ms 24,000Copyright © 2011 Oracle Corporation 16
    • Benefit #2: Better Performance (Oracle Applications) on Exadata and ExalogicE-Business Suite E-Business Suite PeopleSoft Siebel UCM Self Service and HR Order to Cash Self Service HRMS, FIN Customer Hub and Procurement3x better Response Time 3x better Response Time 8x better Response Time 8x better Response Time2x better Scalability 5x better Scalability 4x better Scalability 2x better Scalability 200 ms 11.94 s 2.23 s 8X 1.18 s 8X 3X 0.74 s 0.39 s 1.42 s 25 ms Standard hardware Exalogic and Exadata 17
    • Benefit #2: Better Performance (Oracle Applications) on Exadata and Exalogic JD Edwards Utilities Communications ATG Web Commerce Order Management Meter Data Management Billing Revenue Management Commerce Reference Store3x better Response Time 2x better Response Time 2x better Response Time 3x better Response Time2x better Scalability 7x better Scalability 2x better Scalability 3x better Scalability 10 4000 20 million 0.51 s 3X 2027 3.1 0.17 s 2.75 million Standard hardware Exalogic and Exadata 18
    • Case Study: E-Business Suite on Exalogic / ExadataImpressive Performance 19
    • Case Study: E-Business Suite on Exalogic / ExadataImpressive Business Results 20
    • Benefit #3: Reduced TCO Exalogic and ExadataMaintain DeployRemote Management Enterprise Provisioning of Firmware, Manager - Telemetry OS, Middleware,Phone Home Grid Database and Control - Proactive Support ApplicationsMy Oracle Support Integration Clone and Scale-out OpsCenterFor FMW and DatabasesManage TestEnd-to-End Diagnostics Functional Testing - Service Levels Monitor Load Testing - Root Cause Application-to-Disk Test ManagementConfiguration Mgmt Exalogic and Exadata Monitoring Integration - Change Tracking - System, Middleware, Database, Applications, Database DiagnosticsPatch Automation Compute Nodes, Switch, Storage Database Back-up and Recovery - Firmware, OS Energy Utilization and Impact 21 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Patches Example Exalogic: Single File Patches • Single file download containing all Exalogic patches – Entire platform from firmware to OS across entire system – Middleware and application stack patches validated for Exalogic • All patches (PSU, one-offs) validated against entire system and certified by Oracle to work end-to-end – Apply and go22 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Typical Platform TCO Breakdown Standardization and Consolidation • Server, storage, network, application administration • Facilities management • 3rd party consulting and services • In-house R&D • Test/QA23 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Summary: Engineered System Benefits • Faster Time-To-Market, Lower Risk – Set up in days, not months • Unmatched Performance – At least 2x improvement in response times – At least 2x increase in throughput • Reduced TCO – At least 50% lower TCO • Superior Product Capabilities (“Special Sauce”) – Exabus, database-aware storage, columnar compression24 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • Q&A25 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • 26 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
    • 27 Copyright © 2011, Oracle and/or its affiliates. All rights reserved.
