SLIDE SHOW 1 of 3:
Pictorial chronology documenting the permeable paver parking lot at Odell Brewing Company. Part 1 of 3 covers site prep., geotextile fabric, sub-base, base course, and bedding.

Published in Design
  • Full Name Full Name Comment goes here.
    Are you sure you want to
    Your message goes here
    Be the first to comment
    Be the first to like this
No Downloads

Views

Total Views
681
On SlideShare
0
From Embeds
0
Number of Embeds
1

Actions

Shares
Downloads
0
Comments
0
Likes
0

Embeds 0

No embeds

Report content

Flagged as inappropriate Flag as inappropriate
Flag as inappropriate

Select your reason for flagging this presentation as inappropriate.

Cancel
    No notes for slide

Transcript

  • 1.
  • 2. BIO-AQUIFER STORM SYSTEM (BASS ™) WITH AQUA-BRIC ® PERMEABLE PAVERS ODELL BREWING COMPANY Fort Collins, Colorado
  • 3. SITE PREPARATION perimeter edge restraints (concrete curbs and grade beams)
  • 4. SITE PREPARATION interior parking islands with dry wells
  • 5. SITE PREPARATION pumping subgrade, therefore…
  • 6. SITE PREPARATION … subgrade stabilization required
  • 7. SITE PREPARATION 6-inch minus pit run material worked into subgrade
  • 8. GEOTEXTILE FABRIC geotextile is adhered to sides of perimeter edge restraints
  • 9. GEOTEXTILE FABRIC option to line bottom in fabric as well
  • 10. GEOTEXTILE FABRIC both exterior and interior edge restraints are wrapped
  • 11. GEOTEXTILE FABRIC begin spreading sub-base material on fabric
  • 12. SUB-BASE COURSE AASHTO No. 2 material, VTC, or approved equal
  • 13. SUB-BASE COURSE 1 ½” – 3” cleaned, fractured, open-graded stone
  • 14. taking delivery of a truckload of sub-base material SUB-BASE COURSE
  • 15. 12” minimum depth of sub-base course SUB-BASE COURSE
  • 16. no other construction vehicles allowed on sub-base during installation SUB-BASE COURSE
  • 17. sub-base material delivered until design depth achieved SUB-BASE COURSE
  • 18. standard skid-steer loader used to move and place material SUB-BASE COURSE
  • 19. important to keep geotextile secure during placement SUB-BASE COURSE
  • 20. open-graded aggregates are critical to the BASS ™ success SUB-BASE COURSE
  • 21. sub-base course is compacted with vibratory drum roller SUB-BASE COURSE
  • 22. panoramic view of permeable sub-base course SUB-BASE COURSE
  • 23. BASE COURSE 4” depth of AASHTO No. 57 material, or approved equal
  • 24. BASE COURSE continue to use vibratory drum roller
  • 25. notice ¾” base course against larger sub-base course BASE COURSE
  • 26. BEDDING COURSE base course Compare the size of the bedding material bedding course paver joint
  • 27. 2” depth of ¼” - ⅜” w ashed, fractured, open-graded stone BEDDING COURSE
  • 28. BEDDING COURSE pavers rest directly on setting bed (AASHTO No. 8, or approved equal)
