Compensation Methods Electronic Engineering © University of Wales Newport 2009 This work is licensed under a  Creative Com...
<ul><li>The following presentation is a part of the level 5 module  -- Electronic Engineering. This resources is a part of...
<ul><li>For our amplifier we are going to apply negative feedback to reduce the gain to 55dB. </li></ul><ul><li>Comment on...
Gain Curve f C1 f C2 Phase Curve -40dB/dec
<ul><li>For our amplifier we are going to apply negative feedback to reduce the gain to 55dB. </li></ul><ul><li>Comment on...
Compensation Methods <ul><li>There are three methods which we will examine. </li></ul><ul><li>Dominant Pole compensation <...
Dominant Pole Compensation <ul><li>In this method the Manufacturer introduces an artificial break frequency (pole) which c...
<ul><li>Try this out on our plot and answer the following questions: </li></ul><ul><li>At what frequency does the dominant...
Gain Curve f C1 f C2 Phase Curve x 9.5dB – 5.1kHz 29.5dB – 510Hz 89.5dB – 0.51Hz 15dB – 2.8kHz 35dB – 280Hz 55dB – 28Hz
<ul><li>Try this out on our plot and answer the following questions: </li></ul><ul><li>At what frequency does the dominant...
Notes <ul><li>This method is stable for all applications. </li></ul><ul><li>The user does not need to carry out the compen...
Frequency Compensation <ul><li>This method is similar to the first in that a dominant pole is introduced. This time its po...
<ul><li>A table supplied by the amplifier manufacturer allows the user to convert the new pole frequency measured from the...
<ul><li>Try this out on our plot and answer the following questions: </li></ul><ul><li>At what frequency does the dominant...
Gain Curve f C1 f C2 Phase Curve x 69.5dB – 3kHz 89.5dB – 300Hz f C1  – 15kHz
<ul><li>Try this out on our plot and answer the following questions: </li></ul><ul><li>At what frequency does the dominant...
Notes <ul><li>The user must compensate each amplifier according to its use. </li></ul><ul><li>The Bandwidth, using this me...
Lead Lag Compensation. <ul><li>Let us examine the problem we have with our amplifier. </li></ul>f C1 f C2 Unstable Origina...
<ul><li>We cannot move the two break frequencies as they are inherent parameters of the amplifier. </li></ul><ul><li>BUT <...
<ul><li>Series combination of R2 and C </li></ul><ul><li>Now we can generate an equation for V OUT  in terms of V IN </li>...
Quantative Analysis At low frequencies  ω  parts << 1 so  the gain = 1 phase will be 0 ° At high frequencies  ω  parts >> ...

Frequency Gain Gain dB Phase 100 0.99764 -0.0205249 -1.99651 200 0.990659 -0.0815145 -3.97231 400 0.964149 -0.3171164 -7.7...
Compensation Methods
<ul><li>Referring to our equation for the network, we will have two break frequencies, one for the top line and one for th...
x x f 1 f 2 -20dB/dec Compensation Methods
Note <ul><li>The phase is not a concern as it returns to a low value by the time the gain curve stops reducing. </li></ul>...
f C1 f C2 Unstable Original Curve gain frequency Desired gain Introduce a lead lag network which starts before f C1  and s...
<ul><li>Try this out on our plot and answer the following questions: </li></ul><ul><li>What component values do we need – ...
<ul><li>Firstly f 2  must equal f C1 </li></ul><ul><li>Secondly what drop in gain is required </li></ul>Compensation Methods
Gain Curve f C1 f C2 Phase Curve Required drop in gain = -10dB
<ul><li>Firstly f 2  must equal f C1 </li></ul><ul><li>Secondly what drop in gain is required </li></ul><ul><li>Finally, w...
Gain Curve f C1 f C2 Phase Curve x x f 1 f 2 Bandwidth f C2
<ul><li>Try this out on our plot and answer the following questions: </li></ul><ul><li>What component values do we need – ...
Notes <ul><li>The user must compensate each amplifier according to its use. </li></ul><ul><li>The Bandwidth, using this me...
Summary <ul><li>No compensation – Unstable </li></ul><ul><li>Dominant Pole Compensation –  B.W. = 28Hz </li></ul><ul><li>F...
This resource was created by the University of Wales Newport and released as an open educational resource through the Open...
