The welding of aluminium castings  Tony Paterson
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
What is a casting? <ul><li>three dimensional shape formed from the melt (highly complex shapes possible) </li></ul><ul><li...
Why  weld a Casting ? <ul><li>Join a casting to wrought material </li></ul><ul><li>Joining several castings together </li>...
Why  weld a Casting ? <ul><li>Join a casting to wrought material </li></ul><ul><li>Welding compromises the strength of tem...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
Aluminium Casting Designations  Which alloy is which -  Cast Alloy Designations <ul><li>There is no single universally acc...
Aluminium Casting Designations  Cast Alloy Designation (US) <ul><li>US 3 digit number, plus 1 decimal </li></ul><ul><li>  ...
Aluminium Casting Designations  Cast Alloy Designation (US) <ul><li>Example  535.0  is an Al/Mg alloy, with no  modificati...
Aluminium Casting Designations  Cast Alloy Designation (EN) <ul><li>EN 5 digit number  </li></ul><ul><li>  Al+ </li></ul><...
Aluminium Casting Designations  Cast Alloy Designation (EN) <ul><li>Examples:  AC 42100 is an Al/Si/Mg alloy .  AC 45100 i...
Aluminium Casting Designations  Cast Alloy Designation (Chemical) – similar to wrought <ul><li>Chemical designation   (old...
Aluminium Casting Designations  Cast Alloy Designation (BS now superceded) <ul><li>UK discontinued LM series  (unsystemati...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
Which castings are weldable ? <ul><li>Process </li></ul><ul><li>Composition </li></ul>
Which castings are weldable ? Process Alloys Processes Wrought alloys All except > 0,25% copper addition -  (some exceptio...
Weldable Cast Alloys <ul><li>Non heat treatable </li></ul><ul><ul><li>EN 44100 (LM6, AlSi12) </li></ul></ul><ul><ul><li>EN...
Which castings are weldable ? Composition  <ul><li>Based on aluminium silicon </li></ul><ul><li>Main elemental additions o...
Aluminium 660 o C 231 o C- 327 o C  Se, Sn, Bi, Cd, Pb,  97,7 o C Na 44.2 o C P-  650 o C Mg  630 o C Sb  420 o C Zn  1410...
Which castings are weldable ? Composition – cf wrought alloys
Which castings are weldable ? Composition relationship between filler/parent metal and weld cracking –  (Note: long copper...
Which c astings are weldable ? Compostion   NOTE  Log scale!  l n  Cu upper limit % (wrought and cast alloys) (Other alloy...
Silicon <ul><li>Si improves fluidity, feeding and hot tear resistance. </li></ul><ul><li>Si increases hardness, reduces du...
Copper <ul><li>Basis of heat treatable alloys </li></ul><ul><li>Improves strength, hardness, thermal conductivity </li></u...
Iron <ul><li>Normally not added but picked up from furnace  </li></ul><ul><li>Forms many intermetallic phases </li></ul><u...
Magnesium <ul><li>Strengthening in AlSi alloys </li></ul><ul><li>Premium grade alloys have 0,4 - 0,7%Mg </li></ul><ul><li>...
Lead <ul><li>Added up to 0,35%Pb to improves machinability by enhancing intergranular chip breaking  </li></ul><ul><li>Not...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
Designations of comparable casting alloys (unalloyed and aluminium silicon)  CEN Chemical designat-ion  UK BS1450/ AEA  Fr...
Designations of comparable casting alloys (aluminium silicon copper)  CEN Chemical designat-ion  UK BS1450/ AEA  France NF...
Designations of comparable casting alloys (Aluminium copper/aluminium magnesium and piston alloys)  Note: Designations in ...
Alloys selection for weldability/ corrosion resistance <ul><li>Generally corrosion resistance and weldability run in paral...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
Alloys used in RSA <ul><li>EN 44100  (LM6, AlSi12) </li></ul><ul><li>10,5 – 13,5%Si; 0,15%Cu  </li></ul><ul><li>Widely use...
Cast Alloys cont.. <ul><li>EN 46500  (LM24, AlSi9Cu3(Fe)(Zn)) </li></ul><ul><li>8,0 – 11,0%Si; 2,0 – 4,0%Cu; 1,3%Fe; 0,35%...
Cast Alloys cont.. <ul><li>EN 42000  (LM25, AlSi7Mg) </li></ul><ul><li>6,5 – 7,5%Si; 0,2%Cu </li></ul><ul><li>Larger casti...
Cast Alloys cont.. <ul><li>EN 46100  (LM2, ADC12, AlSi11Cu2(Fe)) </li></ul><ul><li>10,0 – 12,0%Si; 1,5 – 2,5%Cu </li></ul>...
Cast Alloys cont.. <ul><li>EN 44000  (ALSi11) </li></ul><ul><li>Very fluid permanent mould alloy </li></ul><ul><li>Traditi...
Cast Alloys cont.. <ul><li>EN 42100  (AlSi7Mg0.3) </li></ul><ul><li>Used for alloy rims, premium aerospace castings, nucle...
Cast Alloys cont.. <ul><li>EN 43100  (LM9, AlSi10Mg) </li></ul><ul><li>10,0 – 11,8%Si; 0,25 – 0,45%Mg </li></ul><ul><li>Mo...
Cast Alloys – filler alloy choice Selection of filler rods and wires for MIG and TIG welding   Parent metal combination LM...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
Repair Welding <ul><li>Casting is heat treatable and has been hardened </li></ul><ul><li>Welding will over age HAZ </li></...
Non Heat Treatable Castin g <ul><li>Preheat 100  C up to 8 mm thick </li></ul><ul><ul><li>340 - 400  C for heavy or intr...
Heat Treatable Alloy cont.. <ul><li>Preheat 100 - 400°C (short period to avoid anneal) </li></ul><ul><li>Use 4043 filler m...
Cosmetic Repair <ul><li>Non heat treatable </li></ul><ul><li>Preheat as appropriate </li></ul><ul><li>Clean thoroughly </l...
Cosmetic Repair <ul><li>Heat treatable alloy </li></ul><ul><li>Casting is in ‘as cast’ F temper </li></ul><ul><li>Preheat ...
Welding Multiple Castings <ul><li>Preferably F or T2 condition </li></ul><ul><ul><li>Lowest strength in base metal </li></...
Welding Cast to Wrought <ul><li>Same principles as casting to casting </li></ul><ul><li>Wrought material will lose strengt...
Build-up of Castings <ul><li>Very similar to cosmetic repair procedure </li></ul><ul><li>Depends on alloy and temper </li>...
Aluminium to Steel <ul><li>Very difficult ~ intermetallic compounds, melting temperatures, expansion </li></ul><ul><li>Can...
Aluminium to Copper <ul><li>Used for electrical terminations </li></ul><ul><li>Can coat copper with silver or silver alloy...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Objectives: </li></ul><ul><li>What is a casting  </li></ul><ul><l...
General Considerations <ul><li>Avoid unnecessary stresses </li></ul><ul><ul><li>No sudden thickness changes ~ use tapers <...
General Considerations <ul><li>Clean the joint properly </li></ul><ul><ul><li>Aluminium very susceptible to contamination ...
General Considerations <ul><li>Create the right conditions for welding - physical </li></ul><ul><ul><li>Dry (RH<65%), warm...
General Considerations <ul><li>Ensure consumables are suitable </li></ul><ul><ul><li>Gas must be 99,995% pure minimum - no...
Cutting and Preparing Al <ul><li>Cannot use oxy fuel </li></ul><ul><li>Aluminium is not fit up tolerant – cannot fill sign...
Cutting and Preparing Al cont.. <ul><li>Planers, routers and edge mills for edge preparation </li></ul><ul><li>Tungsten ca...
Welding problems Gas porosity in aluminium welds – always caused by hydrogen <ul><li>Low solubility in solid and high solu...
Welding problems Gas porosity in aluminium welds – always caused by hydrogen (Low solubility in solid and high solubility ...
Welding problems - Gas Porosity in welds
Welding problems Cracking in aluminium is always hot cracking <ul><li>Strength of solidifying metal is too low to resist s...
Hot Cracking cont.. <ul><li>Weld bead chemistry - Select suitable filler metal </li></ul><ul><li>Higher alloy content allo...
Welding problems Composition relationship between filler/parent metal and weld cracking –  (Note: long copper sensitivity ...
Good Fair Poor Filler Alloy 5356 Parent Alloy 6061 Filler Alloy 4043  a b d c 1 2 3 4 5 6 Silicon in the Weld Bead (%) 0 1...
<ul><li>Welding of aluminium castings  </li></ul><ul><li>Topics covered: </li></ul><ul><li>What is a casting  </li></ul><u...
The welding of aluminium castings  Tony Paterson (082 602 4517) Questions??
