From Imperial Dam to the Salton Sea:<br />THE STORY OF IMPERIAL VALLEY’S WATER<br />
An Exclusive Presentation by:<br />Chris Austin<br />Maven’s Manor Productions<br />www.MavensManor.com<br />With special ...
A NOTE FROM THE AUTHOR<br />This slideshow follows the path of the water and highlights the infrastructure as it flows fro...
The Imperial Dam straddles the California-Arizona border just north of Yuma, Arizona.  It is the last diversion facility i...
All-American Canal, below Imperial Dam<br />Photo by Chris Austin<br />A cubic-foot per second is about the volume of a ba...
Colorado River above Imperial Dam<br />Photo by Chris Austin<br />The Imperial Dam diverts about 90% of the river’s water ...
Imperial Dam<br />Photo by Chris Austin<br />The amount of water diverted averages  5.5 million acre-feet per year, or rou...
More than half of the water is used to irrigate the nearly half-million acres of productive farmland in California’s  Impe...
Water diverted here also serves 55,000 acres in Arizona’s Yuma Valley and 78,000 acres in California’s Coachella Valley.<b...
Pilot Knob Power Plant on the Yuma Canal <br />(offshoot of the All American Canal).<br />Photo courtesy of the Bureau of ...
Photo courtesy of the Imperial Irrigation District<br />The Imperial Dam was constructed between 1935 and 1938 and was aut...
Photo courtesy of the Imperial Irrigation District<br />Before the project was authorized, the Imperial Valley had been re...
Also authorized by the Boulder Canyon Act was the construction on the All-American Canal, which  began in 1934 with the ca...
Photo courtesy of the Bureau of Reclamation<br />The construction of the 80-mile long unlined canal included digging acros...
As relief for Imperial Valley farmers and citizens suffering from the Great Depression, 250 men and 1,000 head of horses a...
Picture by Bureau of Reclamation, 1939<br />Courtesy of the Library of Congress<br />With the construction of Imperial Dam...
The Colorado River has always carried an enormous load of silt and sediment as it tumbles out of the Rocky Mountains and a...
http://www.flickr.com/photos/willemvanbergen/277907878/<br />At times, this silt and sediment can equal as much as 30% of ...
Photo courtesy of the Imperial Irrigation District<br />The excessive silt loads had long plagued the farmers of the Imper...
Photo courtesy of the Library of Congress<br />http://www.loc.gov/pictures/resource/cph.3a37935/<br />Imperial dam, All-Am...
Even though the construction of  the upstream dams on the Colorado River has reduced the silt load somewhat, periodic dred...
Imperial Irrigation District Headquarters<br />Imperial, California<br />Photo by Chris Austin<br />The Imperial Dam and t...
Imperial Dam Control Room<br />Photo by Chris Austin<br />Engineers in the control room at Imperial Dam control the operat...
Photo by Chris Austin<br />The system can also be controlled and monitored from the Water Control Center at Imperial Irrig...
Imperial Dam is 3475 feet long.  It is a slab-and-buttress (or buttress) dam, a type of dam construction commonly used in ...
A slab-and-buttress dam has a sloping slab facing upstream that is supported by buttresses or walls on the downstream side...
Overflow weir<br />Photo courtesy of the Bureau of Reclamation<br />The purpose of the dam is to raise the level of the ri...
The central overflow weir is a hollow section 1,198 feet long and 31 feet high that contains a gravel ballast for stabilit...
Here is how water is moved around the facility.<br />Gila Gravity Canal<br />Headworks/Intake<br />All-American Canal<br /...
Photo by Chris Austin<br />When the water arrives at the headworks for the All-American Canal, it first goes through the t...
Photo courtesy of the Bureau of Reclamation<br />A trash gantry on a rail system cleans the racks and deposits the trash i...
The water then flows through four gates that are 75 feet long and 22 feet high.<br />Photo courtesy of the Bureau of Recla...
Photo by Chris Austin<br />The gates are cylinder-shaped and designed to be opened as much as 8 feet.  They can be locally...
Photo by Chris Austin<br />Photo by Chris Austin<br />Anode<br />Anodes<br />Anodes are used extensively throughout the fa...
Photo by Chris Austin<br />Photo by Chris Austin<br />The gates empty into four channels with vertical concrete walls betw...
Photo by Chris Austin<br />The water drops down 2 feet as it moves away from the dam toward the desilting basins.  The vel...
Water enters the basin through a long tapered channel in the center  that is designed to evenly distribute the water.<br /...
Photo by Chris Austin<br />While in the basin, the water slows down, allowing the silt and sediment to sink to the bottom....
Photo by Chris Austin<br />The clear water near the surface flows over weirs into channels leading toward the All-American...
Photo courtesy of the Bureau of Reclamation<br />… while large, slowly rotating scrapers on the bottom of each basin colle...
Photo by Chris Austin<br />The accumulated sediments are then discharged to the California Sluiceway, which is what is lef...
Photo by Chris Austin<br />Some water is released into the sluiceway to move the flows along.  <br />
In order to keep a disproportionate amount of sediment from entering the Mexican irrigation system, a channel with a large...
Laguna Dam<br />Photo by Chris Austin<br />Further downstream from Imperial Dam along the river  is Laguna Dam.  Completed...
Laguna Reservoir, above Laguna Dam<br />Photo by Chris Austin<br />Now, Laguna Dam is used for regulation of  the sluicing...
Photo courtesy of the Bureau of Reclamation<br />Before the All-American canal crosses the California-Arizona border, it f...
The All-American Canal flows 82 miles from Imperial Dam to Imperial Valley entirely by  gravity, crossing the Algodones Du...
Photo by Chris Austin<br />The portions of the unlined canal  that traverse the Algodones dunes were highly porous and see...
As part of the Quantification Settlement Agreement (QSA), a provision was included to line a 23-mile section of the All-Am...
Because the Imperial Valley is entirely dependent upon the All-American Canal for water, it was imperative that the canal ...
Photo courtesy of GOMACO Corporation, Ida Grove, IA <br />Over 30 million tons of material were excavated to create the pa...
Photo courtesy of GOMACO Corporation, Ida Grove, IA <br />The paving train was designed to pave the canal in two passes an...
Diagram courtesy of GOMACO Corporation, <br />Ida Grove, IA <br />The paving train consisted of three machines: - a paver,...
The first machine in the chain was the paving machine.  Concrete was dumped into a distribution system utilizing a paddle ...
Seepage from the unlined canal still in operation was a problem.  Wells were placed every 100 feet along the route to keep...
Photo courtesy of GOMACO Corporation, Ida Grove, IA <br />Construction required interfacing the new canal with the existin...
At these transitions, the canal was split longitudinally in half, and while half the canal prism was being paved, a sheet ...
Photo by Chris Austin<br />The canal lining project was completed in 2010.<br />The All-American Canal lining project was ...
The All-American Canal drops 175 feet as it flows to the Imperial Valley, and hydropower plants have been extensively deve...
Pilot Knob Powerplant<br />Photo by Chris Austin<br />Hydropower generation accounts for 17.75% of the electrical power so...
After crossing the dunes, the All-American Canal arrives in the Imperial Valley.  At a point called Drop 1, the Coachella ...
Every Wednesday, IID’s watermaster submits a water order to the Bureau of Reclamation based on historical and current wate...
Photo courtesy of the Bureau of Reclamation<br />Drop 2 Reservoir<br />However, during the time the water is in transit, c...
Photo courtesy of the Bureau of Reclamation<br />The new reservoir will conserve an estimated 70,000 acre-feet per year, m...
Diagram  courtesy of the Bureau of Reclamation<br />This diagram shows how water is moved in and out of the reservoir.<br ...
East Highline Canal<br />Central Main Canal<br />Westside Main Canal<br />Water is distributed to the Imperial Valley thro...
Photo by Chris Austin<br />From these main canals, 167 smaller lateral canals transport the water another 1438 miles …<br />
Photo by Chris Austin<br /> … to approximately 5,600 delivery gates that serve the half-million acres of farmland within I...
While a remote system controls the main canals, most lateral headings are controlled by zanjeros, who are responsible for ...
Photo by Chris Austin<br />The Imperial Valley’s favorable climate, fertile soils, and ample water rights make it one of t...
More than 100 different crops are grown here.<br />View Imperial County Agricultural Reports here:<br />http://www.co.impe...
Imperial County Fair exhibit, 1942<br />Photo courtesy of the Library of Congress<br />The Imperial Valley has long been k...
Photo by Chris Austin<br />The Imperial Valley’s top agricultural commodity is cattle; it is ranked third among California...
Photo by Chris Austin<br />Alfalfa is the number one agronomic crop with over 112,912 acres in production in 2009.  The la...
The Imperial Valley produces 1.6 million tons of hay and other forage crops annually, and is a vital producer for the dome...
Photo by Chris Austin<br />As part of its system, the Imperial Irrigation District maintains an extensive gravity flow dra...
Surface runoff, or tailwater, refers to the water running off of the lower end of the field as part of normal surface irri...
To improve water efficiency on gravity-irrigated fields, the fields are often leveled precisely using a laser-leveling sys...
While tailwater can be reused, subsurface drainage water cannot.  Subsurface drainage systems (sometimes called “tile drai...
The irrigation water from the Colorado River is salty, and when the water is used by the plant through transpiration or th...
http://ceimperial.ucdavis.edu/Custom_Program275/Salton_Sea_and_Salinity/</li></li></ul><li>As part of its efforts to conse...
Photo courtesy of the Bureau of Reclamation<br />About 1/3rd of the water delivered to the Imperial Valley will ultimately...
As an agricultural drainage reservoir, the Salton Sea serves an important purpose for the productive agricultural valleys ...
Photo courtesy of the Bureau of Reclamation<br />With all the demands on the Colorado River, it no longer reaches the Sea ...
As one of the few remaining wetlands left, many birds have come to rely on the Salton Sea.  It has become an important win...
Bird populations on any given day number at least in the low hundreds of thousands, but can number in the low millions dur...
Photo by Chris Austin<br />Dubbed by some scientists as "California's crown jewel of avian biodiversity", more than 380 sp...
Photo by Chris Austin<br />The Salton Sea is a terminal lake, meaning it has no outlets.  The water that sustains the sea ...
Photo by Chris Austin<br />Currently, the amount of water flowing into the Sea and the rate of evaporation are roughly equ...
Photo by Chris Austin<br />As the inflows to the Sea decrease, the Sea will shrink, become saltier, and expose tens of tho...
During the QSA negotiations, the state agreed to assume most of the financial responsibilities for mitigating negative env...
One agency working towards restoration and revitalization of the Sea is the Salton Sea Authority, a Joint Powers Authority...
Photo courtesy of the Salton Sea Authority<br />While many projects are currently underway, much more needs to be done.<br...
The Imperial Dam and the All-American Canal system delivers one-fifth of the flow of the Colorado River to the Imperial Va...
Photo by Chris Austin<br />Imperial Valley farmers use that water to produce food and fiber for the nation and for the wor...
Water conservation measures enacted within the Imperial Valley as part of the QSA Agreement will reduce inflows into the S...
Photo by Chris Austin<br />This presentation is just the beginning, the first of a three-part presentation that will take ...
From this …<br />… to this …<br />… the next installment will cover the story of the Imperial Valley, from the pioneer day...
Photo by Chris Austin<br />  … including the valley’s incredible renewable energy potential.  <br />
Photo by Chris Austin<br />An integral part of the system, the Salton Sea has it’s own story to tell, one of boom, bust, a...
TECHNICAL/OPERATIONAL RESOURCES<br />From the Bureau of Reclamation:<br />   Imperial Diversion Dam: http://www.usbr.gov/p...
HISTORICAL RESOURCES<br />LIFE Magazine, October 31, 1938: Pictorial essay on the construction of the desilting works of t...
IMPERIAL COUNTY RESOURCES<br />Imperial County Farm Bureau: http://www.icfb.net/<br />Imperial County Agriculture Overview...
SALTON SEA RESOURCES<br />Reports:<br />Restoring the Salton Sea, a Legislative Analyst Office report: http://www.lao.ca.g...
This exclusive presentation by:<br />Chris Austin<br />Maven’s Manor Productions<br />See more of my presentations online ...
Also available online<br />Follow the path California’s first water project, learn a bit of it’s history and find out how ...
