MAPC Data Day: OLIVER Aleda Freeman Web Mapping Services Manager Office of Geographic Information (aka MassGIS) January 2012
02/01/12 MassGIS = digital library with > 1,000 datalayers: Landuse   Wind Speed  Aerial    Impervious Photos   Surface
02/01/12 Wind engineer Where to put turbine? Wind speed + Elevation +  Roads +  Zoning +  Open Space + Wetlands   Vernal P...
OLIVER <ul><li>New version Jan. 10, 2012!  </li></ul>02/01/12
OLIVER 02/01/12 GeoServer   OpenLayers GeoExt   Bing    geocoding Google   Yahoo maps   User      Interface    Library (YU...
OLIVER <ul><li>Runs on OpenGeoSpatial Consortium (OGC) standard web mapping services </li></ul><ul><li>provided by GeoServ...
What are web map services? <ul><li>WMS – Web Map Service (GetMap) </li></ul><ul><li>Image of a map returned (PNG, TIFF, et...
What are web map services? <ul><li>For WMS or WFS: </li></ul><ul><li>Request can be URL or XML </li></ul><ul><li>Can filte...
WMS URL Example <ul><li>http://giswebservices.massgis.state.ma.us/geoserver/wms?VERSION=1.1.1&REQUEST=GetMap&SERVICE=WMS&L...
WMS Result 02/01/12
WFS URL Example <ul><li>http://giswebservices.massgis.state.ma.us/geoserver/wfs?request=GetFeature&version=1.0.0&service=W...
WFS Result 02/01/12
OLIVER initial view 02/01/12
OLIVER Basemaps 02/01/12
OLIVER Layer Type Ahead 02/01/12
OLIVER Change Colors 02/01/12
OLIVER Extract by Poly 02/01/12
OLIVER Permalink 02/01/12 http://maps.massgis.state.ma.us/map_ol/oliver.php?lyrs=Massachusetts%20Towns~massgis:GISDATA.TOW...
OLIVER Print/Save 02/01/12
OLIVER Configuration Options 02/01/12 <ul><li>title, datalayer, about text and logos </li></ul><ul><li>default layers, def...
OLIVER“slim” 02/01/12
OLIVER Linked Dropdowns 02/01/12
OLIVER Draw/Edit 02/01/12
OLIVER External WMS 02/01/12
Web Map Services Wiki 02/01/12
THANK YOU. Aleda Freeman [email_address] https://wiki.state.ma.us/confluence/display/massgis   617-626-4530
