Irwin Seating Theater Seating Brochure (2009 Edition) Document Transcript

  • 1. Theatre Seating irwin seating company
  • 2. The Irwin Difference People, Products & Services For 100 years, Irwin Seating Company’s sole focus has been on meeting our customers’ needs for public seating solutions. We achieve this through innovative design, by manufacturing the industry’s most durable products, and by providing unmatched ser- vice before, during, and after the installation of a project. Everyone at Irwin Seating Company is focused on quality, continuous improvement and customer satis- faction. This commitment is what the Irwin Difference is all about Kimmel Center, Verizon Hall, - Philadelphia, Pennsylvania and why we are the world’s lead- ing supplier of theatre seating. We recognize the importance of stewardship and understand the delicate balance between aes- thetics, durability and comfort. Our expertise will help to take care of the physical details of the seating so the audience is free to enjoy the performance. We start by asking questions and listening to our customers’ requirements to gain an under- standing of their unique needs. We provide design consultation for seating layout, chair customi- zation and offer sight line studies Carnegie Hall - New York, New York and ADA recommendations to ensure an unencumbered experi- ence by all. We offer luxurious fabrics, fine furniture finishing and an unequalled number of backs, seats and aisle end panels that can be customized to fit the needs of any type of theatre. We coordinate installation with the construction contractor using factory certified installers and offer full chair restoration services to return old, worn chairs to their original beauty. Talk with your Irwin Seating company rep- resentative today and experience the Irwin Difference. Holland Performing Arts Theatre - Omaha, Nebraska 1 Right: International Festival Institute at Round Top - Round Top, Texas
  • 3. Designed Versatility Every facility is unique in design and appearance so we’ve designed our products in a modular fashion to put choice into your hands. We manufacture over 40 different backs, 8 different seats and dozens of aisle end panels and accessories. We’ve included our most popular components here, but others can be found at www.irwinseating.com. No. 6 Century PAC No. 10 Grand Rapids No. 11 Springfield No. 17 Davies No. 27 Allegro No. 29 Rialto No. 52 Marquee No. 52 Marquee • veneer, laminate or upholstered • veneer rear panel with • veneer rear panel with • veneer, laminate or upholstered • veneer rear panel with matching • veneer or laminate rear panel • veneer rear panel • upholstered rear panel rear panel matching face reveal matching face reveal rear panel face reveal • 2” poly foam, 3” available • 2” poly foam with tufted cover • 2” poly foam with tufted cover • 2” poly foam, 3” available • 2” poly foam • 2” poly foam • 2” poly foam, 3” available • 2” poly foam, 3” available • 1-piece cover • concealed fasteners • concealed fasteners • 1-piece cover (2-pc available) • 1-piece cover • 1-piece cover • 1-piece cover (2-pc available) • 1-piece cover • exposed fasteners • ergonomically formed “tall” • ergonomically formed “tall” • concealed fasteners • concealed fasteners • concealed fasteners • concealed fasteners • concealed fasteners back back • high-back available CHAIR BACKS [No. 27] No. 55 Forest No. 58 Winter Garden No. 63 Empire No. 64 Paradise No. 69 Emerson No. 81 Oriental No. 82 Orpheum No. 83 New Amsterdam • veneer, laminate or upholstered • veneer, laminate or upholstered • veneer or laminate rear panel • veneer or laminate rear panel • veneer rear panel with matching • veneer, laminate or upholstered • veneer, laminate or upholstered • veneer rear panel with matching rear panel rear panel • 2” poly foam • 2” poly foam face reveal rear panel rear panel face reveal • 2” poly foam with tufted cover • 2” poly foam with tufted cover • 1-piece cover • 1-piece cover • 2” poly foam • 2” poly foam • 2” poly foam • 2” poly foam • concealed fasteners • concealed fasteners • exposed fasteners • exposed fasteners • 1-piece cover • 1-piece cover • 1-piece cover • 1-piece cover • ergonomically formed “tall” back • ergonomically formed “tall” back • exposed fasteners • concealed fasteners • concealed fasteners • “tall” back with concealed fasteners SEATS [No. 17] No. 6 Seat No. 7 Loge Seat No. 12 Seat No. 12U Fully Upholstered Seat No. 14 Crusader Seat No. 14U Upholstered Crusader Seat No. 17 Allegro Wood Bottom Seat • steel seat pan • steel seat pan • plastic seat foundation • plastic seat foundation • self-rising, 7-ply hardwood plywood seat • self-rising, 7-ply hardwood plywood seat • gravity-lift, 8-ply hardwood plywood seat • serpentine spring support • serpentine spring support • 3” poly foam (4” available) • 3” poly foam • surfaced with wood veneer • upholstered over 3” poly foam with deco- • upholstered over 3” poly foam • 3” poly foam • 4” poly foam • available with serpentine spring or • serpentine spring support • available with upholstered pad rative welt • available with decorative solid hardwood • available with acoustical perfora- • available with acoustical perfora- ergonomic substrate construction • zipper enclosure • available with 11-ply hardwood veneer • available with upholstered bottom cover cap to conceal plies tions and sound absorption pad tions and sound absorption pad • available with 11-ply hardwood veneer AISLE STANDARDS [No. 17] No. 14 Aisle End No. 46 Aisle End No. 56 Aisle End No. 66 Aisle End No. 86 Aisle End No. 73 Aisle End No. 98 Aisle End No. 12 Aisle End Model: N o 27.17.17 Allegro No. 17 Aisle End • steel column • steel column • steel column • steel column • steel column • steel column • steel column • steel column • cast iron column with cast iron panel • veneer surfaced panel • veneer surfaced panel • solid wood panel • veneer surfaced panel • veneer surfaced aisle panel • veneer surfaced aisle panel • veneer surfaced aisle panel • contemporary, • available for riser mounting with block front with block front with block front with block front • available with riser and canti- • available with riser and canti- • available with laminate “open” aisle standard • available with Nos. 56, 66 and 86 aisle • available with riser and • available with riser and • available with riser and • available with riser and cantilevered levered mounts levered mounts surfaced or upholstered aisle panels surfaced with laminate, veneer cantilevered mounts cantilevered mounts cantilevered mounts mounts • available with laminate • available with laminate panels or fabric • available with upholstered • available with upholstered • available with upholstered • available with laminate surfaced or surfaced or upholstered aisle surfaced or upholstered aisle aisle panel aisle panel aisle panel upholstered aisle panels panels panels 3 4 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times. 5
  • 4. Accessories & Options Details are what distinguish one project from another so we offer a wide array of accessories designed specifically to help add those final touches of function, comfort and beauty. Scrolled Wood Armrest Curved Wood Armrest Rounded Wood Armrest Standard Armrest Blow-Mold Plastic Armrest Plastic Cupholder Armrest (stained or surfaced with (black only) plastic laminate Row Letter Plate No. 92 ADA Aisle Standard Upholstered Seat Insert Cantilever Steel Standards No. 119 No. 137 No. 139 No. 140 No. 141 No. 142 Deco Singer Sunburst Fireside Zeigfield Fulton No. 166 Skyline Aisle End Row Letter Plate No. 12 ADA Aisle Standard Veneer Seat Insert Riser Mount Steel Standards No. 143 No. 145 No. 146 No. 151 No. 153 No. 154 Winter Garden Herald Rialto Roundabout Pantages Sunset 120v Rectangular Aisle Light 120v Round Aisle Light Seat Number Plate Movable Base Acoustical Perforations Riser Mount Cast Iron Standards No. 155 No. 158 No. 160 No. 162 No. 163 No. 164 Low Voltage L.E.D. Aisle Light Low Voltage Concealed Donor Plate Swing-Away Aisle End Tru-Fold Tablet Arm E-Link System Baroque New Amsterdam Warner Mystic Commonwealth Trinity L.E.D. Aisle Light 6 7 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times. 8
  • 5. Custom Chair Design Do the math on our component based system, and you will find over 15,000 possible chair combinations; and that doesn’t include accessories! But we know even with that kind of selection to choose from there are times when a custom solution is needed; whether it’s a period-style end or a custom shaped back the Irwin Difference will ensure the seating meets all your expectations. Custom Allegro shown with: • custom back with CNC cut holes in the top reveal for exact duplication (recommend No. 8 Natural finish only with this option) • custom aisle end standard with curved, solid wood arm- Custom Century PAC rests and concealed, low voltage LED lighting shown with: • fully upholstered back with 3” foam and a two-piece cover • fully upholstered gravity lift seat • upholstered armrests and modified aisle end panel • decorative applique for aisle and center standards Custom Chair shown with: • custom veneer surfaced back • No. 17 wood bottom seat • custom aisle end panel designed to match the back curvature Custom Meteor shown with: • custom reveal on the back face for Custom Allegro custom chair number tag placement shown with: • No. 17 wood bottom seat • custom high back Allegro • custom aisle end panel designed to match the back angle • custom aisle end on rocker platform • custom aisle and center armrests • custom cupholder arms with laser cut, stainless steel inserts 9 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times. 10
  • 6. Allegro 27HB.17.17 Allegro High Back 27.XX.XX Allegro shown with: shown with: • 35” high back with veneer surfaced rear • 31” high back with veneer surfaced rear panel attached with concealed fasteners and panel attached with concealed fasteners and wood reveal on the face wood reveal on the face • no. 17 wood bottom seat • modified no. 17 wood bottom seat • aisle end panel surfaced with wood veneer • custom aisle end panel surfaced with wood and solid wood armrests veneer and custom solid wood armrests 27HB.17.14PED Allegro High Back 37.12.14 Allegro shown with: shown with: • 35” high back with veneer surfaced rear panel attached with concealed fasteners and • 31” high back with veneer surfaced rear panel attached wood reveal on the face with concealed fasteners • no. 17 wood bottom seat • upholstered, self-rising seat with decorative fabric insert and seat number plates • pedestal base with no. 14 aisle end panel surfaced with wood veneer and solid wood • no. 14 aisle end panel surfaced with wood veneer, 2” armrests round row letter plate and solid wood armrests Allegheny College, Vukovich Center Kimmel Center, Perelman Theater Bass Performance Hall Kansas City Music Hall Georgia Southern University Schermerhorn Symphony Center Meadville, Pennsylvania Philadelphia, Pennsylvania Fort Worth, Texas Municipal Auditorium Statesboro, Georgia Nashville, Tennessee 11 Kansas City, Missouri 12 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times.
  • 7. Century PAC Davies 6.XX.56 Century PAC 17.12U.46 Davies shown with: shown with: • 32” high back surfaced with a fully upholstered rear • 31” high back surfaced with a wood veneer panel attached with concealed fasteners rear panel attached with concealed fasteners • custom self-rising seat with decorative wood bottom • fully upholstered self-rising seat • steel standards with veneer surfaced aisle panels • steel standards with solid maple aisle panels which feature a block front and solid maple armrests which feature a block front and solid maple • low voltage LED aisle light armrests • number & letter plates 17.17.46 Davies shown with: • 31” high back surfaced with a wood veneer rear panel attached with concealed fasteners • gravity-lift wood bottom seat • steel standards with solid maple aisle panels which fea- ture a block front and solid maple armrests • number & letter plates Herberger Theater Eastern Illinois University Christel DeHaan Fine Arts Center The Classic Center Clay Center Theatre Works Phoenix, Arizona Doudna Fine Arts Center University of Indianapolis Athens, Georgia Charleston, West Virginia Hartford, Connecticut 13 Charleston, Illinois Indianapolis, Indiana 14 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times.
  • 8. Marquee 52.12.46 Marquee 53.12.46 Marquee shown with: shown with: • 36” high back with maple veneer surfaced rear panel • 36” high back with fully upholstered rear panel • upholstered self-rising seat with plastic seat foundation • upholstered self-rising seat with plastic seat foundation and decorative veneer seat bottom insert and decorative upholstered seat bottom insert • solid maple aisle panel and armrests with 2” round row • upholstered aisle panel with padded and upholstered letter plate armrests Alys Robinson Stephens Center Richardson Performance Hall Summerlin Performing Arts Center Wynn Las Vegas, Grail Theatre SUNY Fine Arts Center National Theatre University of Alabama Del Mar College Summerlin, Nevada Las Vegas, Nevada Buffalo, New York Washington, D.C. Birmingham, Alabama Corpus Christi, Texas 15 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times. 16
  • 9. Grand Rapids Springfield 10.6.56 Grand Rapids 11.12.142 Springfield shown with: shown with: • 33” high back with veneer surfaced rear • 33” high back with veneer surfaced rear panel and match- panel and matching wood reveal on the face ing wood reveal on the face • upholstered self-rising seat with acoustical • upholstered self-rising seat with plastic seat foundation perforated steel foundation and number • period style aisle standard with scrolled, solid oak armrests plates • steel standards with solid wood aisle panel and armrests with a rectangular aisle light 10.17.56AV Grand Rapids shown with: • 33” high back with veneer surfaced rear panel and matching wood 11.6.155 Springfield reveal on the face shown with: • upholstered, wood bottom gravity- • 33” high back with veneer surfaced rear panel and lift seat wood reveal on the face • solid wood aisle panel and armrests • upholstered self-rising seat with acoustical perforated on air vent pedestal standard steel foundation and number plates • period style aisle standard with scrolled, solid maple armrests and row letter plates DeVos Performance Hall The Bushnell, Belding Theatre Warner Theatre The Grand Opera House Columbia Theatre Fulton Opera House Grand Rapids, Michigan Hartford, Connecticut Erie, Pennsylvania Wilmington, Delaware Southeast Louisiana University Lancaster, Pennsylvania 17 Hammond, Louisiana 18 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times.
  • 10. Rialto Winter Garden 29.6.166 Rialto shown with: • 32” high back surfaced with maple veneer and attached with exposed fasteners • upholstered self-rising seat with steel foun- dation and number plates • period-style cast aisle standard and scrolled maple armrests 58.12.141 Winter Garden shown with: • 34” high back features a tufted cover and rear panel surfaced with maple veneer attached with concealed fasteners • upholstered self-rising seat with plastic seat foundation and decorative upholstered seat bottom insert • period-style cast aisle standard and scrolled maple armrests Pantages Theatre Boston Opera House Warner Theatre Shubert Theatre Music Box Theatre Winter Garden Theatre Los Angeles, California Boston, Massachusetts Torrington, Connecticut New York, New York New York, New York New York, New York 19 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times. 20
  • 11. Orpheum & New Amsterdam Emerson 82.6.153 Orpheum shown with: • 33” high back surfaced with a wood veneer rear panel attached with concealed fasteners • upholstered self-rising seat with steel foun- dation and number plates • period-style cast aisle standard and scrolled maple armrests 69.14U.137 Emerson shown with: • 34” high back surfaced with a wood veneer rear panel attached with exposed fasteners and matching wood reveal on the face • self rising wood bottom seat • period style cast aisle end standards and scrolled maple armrests 83.6.158 New Amsterdam shown with: • 36” high back surfaced with a wood veneer rear panel attached with concealed fasteners and matching wood reveal on the face • upholstered self-rising seat with steel foundation and number plates • period-style cast aisle standard and scrolled maple armrests New Amsterdam Theatre Cutler Majestic Theatre The Venetian Resort, Hotel & Casino New York, New York at Emerson College Las Vegas, Nevada 21 Boston, Massachusetts 22 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times.
  • 12. Forest Empire, Paradise & Oriental 55.6.142 Forest shown with: • 34” high back features a tufted cover and rear panel surfaced with maple veneer attached with concealed fasteners • upholstered self-rising seat with steel foun- dation and number plates • period-style cast aisle standard and scrolled maple armrests 63.12U.156 Empire shown with: • 33” high back surfaced with maple veneer and attached with exposed fasteners • fully upholstered self-rising seat • period-style cast aisle standard and scrolled maple armrests 64.7.151 Paradise shown with: • 33” high back surfaced with maple veneer and attached with exposed fasteners • upholstered self-rising seat with steel foundation and number plates • period-style cast aisle standard and scrolled maple armrests 81.6.164 Oriental shown with: • 33” high back surfaced with maple veneer and attached with concealed fasteners • upholstered self-rising seat with steel foundation and number plates • period-style cast aisle standard and scrolled Hippodrome Theatre Forest Theatre Brooks Atkinson Theatre maple armrests Baltimore, Maryland Philadelphia, Pennsylvania New York, New York 23 Note: Many of the chairs featured in this brochure feature custom, non-standard products that require extended lead times. 24
  • 13. Marquee Citation & Millennium 51.12.66 Marquee 47.12.66 Millennium shown with: shown with: • 36” high back with an injection molded plastic rear • 32” high back with an injection molded back panel panel and structurally formed lumbar support • upholstered self-rising seat with plastic seat foundation • upholstered self-rising seat with plastic seat foundation • laminate surfaced aisle panels and armrests and decorative veneer seat bottom insert • solid maple aisle panel and armrests (below), laminate surfaced aisle panel, armrests and tablet arm (right) 4.12.56 (left) 4.12.86 (above) Citation shown with: • 32” high back with an injection molded back panel • upholstered self-rising seat with plastic seat foundation • laminate surfaced aisle panels with cupholder armrests (left), veneer surfaced aisle panel and solid wood armrest (above) William D. Purser Center Indigo Music Club Nokia Live Planet Hollywood Resort & Casino Juanita K. Hammons Performance Hall Trinity Academy Logan College of Chiropractic London, England Los Angeles, California Las Vegas, Nevada SW Missouri State University Wichita, Kansas Chesterfield, Missouri Springfield, Missouri 25 26
  • 14. Chair Restoration Restoration is an excellent way to maintain the original design of an auditorium or theatre and is often the best solution when compliance with modern building codes is a concern. Chair restoration is also an out- standing way to practice environmental stewardship. Often, the best solution is a mix of new and original components and with 100 years of experience the Irwin Difference can help to bridge the gap between new and old. Before Before Period Chair AMSECO 16M Restoration Details: Restoration Details: • all components not suitable for restoration were replaced from stock • all components not suitable for restoration were replaced from stock • all steel / cast iron components were stripped, pre-finished and powder coated • all steel / cast iron components were stripped, pre-finished • standards were modified to accept new self rising seats and powder coated After • upholstered pads were added to the backs After • seat-lift springs & bushings were replaced with new parts • wood armrests were stripped, sanded and stained • fabric covers and foam were replaced to meet current safety codes • aisle light assemblies were replaced • wood armrests were stripped, sanded and stained • custom number and letter plates were produced • number and letter tags were replaced Candor High School (before) Candor High School (after) Lincoln Theatre Bailey Hall (before) Bailey Hall (after) Warner Theatre Candor, New York Candor, New York Yountville, California Cornell University Cornell University San Pedro, California 27 Ithica, New York Ithica, New York 28
  • 15. Dedicating ourselves to customer satisfaction, employee well-being, and profitable growth. Irwin Seating Company Irwin Telescopic Seating Company 3251 Fruit Ridge Ave. NW P.O. Box 320 Grand Rapids, MI 49544 Altamont, IL 62411 Sales Office: 616-574-7400 Phone: 618-483-6157 Fax: 616-574-7411 Fax: 618-483-5539 E-mail: sales@irwinseating.com E-mail: sales@irwintelescopicseating.com www.irwinseating.com www.irwintelescopicseating.com Printed in USA © 2009 Irwin Seating Company, Grand Rapids, Michigan
