LarKC Tutorial at ISWC 2009 - Second Hands-on Scenario

  1. 1. Cyc-Gate workflow Blaz Fortuna, Luka Bradesko Cycorp Europe, Slovenia
  2. 2. Goal <ul><li>Demonstrate reasoning over non-structured input data </li></ul><ul><li>Learn how to correctly annotate a new plug-in </li></ul><ul><li>Learn how to add a new plug-in to the platform </li></ul>
  3. 3. External tools useds <ul><li>GATE </li></ul><ul><ul><li>Information Extraction framework </li></ul></ul><ul><ul><li>Used here for extraction of named entities from articles </li></ul></ul><ul><li>ResearchCyc </li></ul><ul><ul><li>Common-sense knowledge base </li></ul></ul><ul><ul><ul><li>~300,000 concepts, 1.3M assertions </li></ul></ul></ul><ul><ul><li>Reasoning engine </li></ul></ul>
  4. 4. Pipeline diagram Research Cyc GATE Internet Query Identify Transform Select Reason Result
  5. 5. Example
  6. 6. Query PREFIX cyc: <http://www.cycfoundation.org/concepts/> SELECT ?company WHERE { ?company cyc:mentionedInArticle &quot; http://shodan.ijs.si:8080/GateServer/news.txt &quot; . ?company cyc:isa cyc:PubliclyHeldCorporation }
  7. 7. Identify <ul><li>Find links to html documents and retrieve them using ArticleIdentifier plugin. </li></ul><ul><ul><li>Returns a text document: </li></ul></ul>http://shodan.ijs.si:8080/GateServer/news.txt
  8. 8. Transform <ul><li>Use GATE to extract organizations </li></ul><ul><ul><li>Retruns SetOfStatements of style: </li></ul></ul>article-0 urn:hasUrl “http://shodan.ijs.si:8080/GateServer/news.txt &quot; company-0 urn:nameString “Microsoft” company-0 urn:mentionedInArticle article-0 company-1 urn:nameString “Ford” company-1 urn:mentionedInArticle article-0 … Query: … ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news.txt&quot; …
  9. 9. Select <ul><li>Select only the companies with corresponding concept in ResearchCyc KB </li></ul><ul><ul><li>company-0 -> #$MicrosoftInc </li></ul></ul><ul><ul><li>company-1 -> #$FordMotors </li></ul></ul><ul><li>Replace URIs with Cyc concepts </li></ul><ul><ul><li>cyc:mentionedInArticle -> #$mentionedInArticle </li></ul></ul><ul><li>Output: </li></ul>#$MicrosoftInc  #$ mentionedInArticle #$article-0 #$ FordMotors #$ mentionedInArticle #$article-0 …
  10. 10. Reason <ul><li>Reason </li></ul><ul><ul><li>Load the triples with Cyc concept names in ReasearchCyc KB </li></ul></ul><ul><ul><li>Transform SPARQL query to Cyc query </li></ul></ul><ul><ul><li>Execute and retrieve results </li></ul></ul>
  11. 11. Run the workflow on your computer! Main class: eu.larkc.core.Larkc VM arguments: -Xmx512m
  12. 12. Run SPARQL client <ul><li>In windows: </li></ul><ul><ul><li>Double-click SPARQLClient.jar </li></ul></ul><ul><li>In Linux: </li></ul><ul><ul><li>java –jar SPARQLClient.jar </li></ul></ul>
  13. 13. Run example query <ul><li>Execute query in SPARQL Client </li></ul><ul><li>Walk-through the output of the program </li></ul><ul><li>Go through the plug-ins’ .java files </li></ul>
  14. 14. Other interesting queries <ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news.txt&quot; . </li></ul><ul><li>?company cyc:isa cyc:PubliclyHeldCorporation } </li></ul><ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news.txt&quot; . </li></ul><ul><li>?company cyc:isa cyc:SoftwareVendor } </li></ul><ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news2.txt&quot; . </li></ul><ul><li>?company cyc:isa cyc:SoftwareVendor } </li></ul><ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news.txt&quot; . </li></ul><ul><li>?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news2.txt&quot; . </li></ul><ul><li>?company cyc:isa cyc:Business } </li></ul>
  15. 15. Other interesting queries <ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news2.txt&quot; . </li></ul><ul><li>?company cyc:makesProductType cyc:CellularTelephone } </li></ul><ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news2.txt&quot; . </li></ul><ul><li>?company cyc:makesProductType cyc:CellularTelephone . </li></ul><ul><li>?company cyc:stockTickerSymbol ?ticker } </li></ul><ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news2.txt&quot; . </li></ul><ul><li>?program cyc:programAuthor ?company } </li></ul><ul><li>PREFIX cyc: <http://www.cycfoundation.org/concepts/> </li></ul><ul><li>SELECT ?company WHERE </li></ul><ul><li>{ ?company cyc:mentionedInArticle &quot;http://shodan.ijs.si:8080/GateServer/news2.txt&quot; . </li></ul><ul><li>?competitor cyc:competitors ?company . </li></ul><ul><li>?competitor cyc:makesProductType cyc:CellularTelephone } </li></ul>
  16. 16. Plug-in SAWSDL description <ul><li><wsdl:description> </li></ul><ul><li><!-- COMMON TO ALL SELECTERS --> </li></ul><ul><li><wsdl:interface name=&quot;identifier&quot; </li></ul><ul><li>sawsdl:modelReference=&quot;http://larkc.eu/plugin#Identifier&quot;> </li></ul><ul><li></wsdl:interface> </li></ul><ul><li><wsdl:binding name=&quot;larkcbinding&quot; type=&quot;http://larkc.eu/wsdl-binding&quot; /> </li></ul><ul><li><!-- SPECIFIC TO THIS IDENTIFIER --> </li></ul><ul><li><wsdl:service </li></ul><ul><li>name=&quot;urn:eu.larkc.plugin.identify.article.ArticleIdentifier&quot; </li></ul><ul><li>interface=&quot;identifier” </li></ul><ul><li>sawsdl:modelReference=&quot;http://larkc.eu/plugin#ArticleIdentifier&quot; > </li></ul><ul><li><wsdl:endpoint </li></ul><ul><li>location=&quot;java:eu.larkc.plugin.identify.article.ArticleIdentifier&quot; /> </li></ul><ul><li></wsdl:service> </li></ul><ul><li></wsdl:description> </li></ul>
  17. 17. Plug-in ontology <ul><li>@prefix larkc: <http://larkc.eu/plugin#> . </li></ul><ul><li>@prefix rdfs: <http://www.w3.org/2000/01/rdf-schema#> . </li></ul><ul><li>@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> . </li></ul><ul><li>larkc:ArticleIdentifier </li></ul><ul><ul><li>rdf:type rdfs:Class ; </li></ul></ul><ul><ul><li>rdfs:subClassOf larkc:Identifier ; </li></ul></ul><ul><ul><li>larkc:hasInputType larkc:SPARQLQuery ; </li></ul></ul><ul><ul><li>larkc:hasOutputType larkc:NaturalLanguageDocument . </li></ul></ul>
  18. 18. Scripted decider <ul><li>Pipeline pipeline = new Pipeline(); </li></ul><ul><li>pipeline.addPlugIn( new URIImpl( &quot;urn:eu.larkc.plugin.identify.article.ArticleIdentifier&quot; )); </li></ul><ul><li>pipeline.addPlugIn( new URIImpl( &quot;urn:eu.larkc.plugin.transform.gate.GateTransformer&quot; )); </li></ul><ul><li>pipeline.addPlugIn( new URIImpl( &quot;urn:eu.larkc.plugin.select.cycselecter.CycSelecter&quot; )); </li></ul><ul><li>pipeline.addPlugIn( new URIImpl( &quot;urn:eu.larkc.plugin.reason.cycreasoner.CycReasoner&quot; )); </li></ul><ul><li>try { </li></ul><ul><li>pipeline.start(theQuery); </li></ul><ul><li>} catch (Exception e) { </li></ul><ul><li>// error </li></ul><ul><li>} </li></ul><ul><li>return (VariableBinding)pipeline.take(); </li></ul>
  19. 19. Write a new plug-in <ul><li>Create new project </li></ul><ul><ul><li>New Folder </li></ul></ul><ul><ul><li>Link bin directory </li></ul></ul><ul><ul><li>Make source directory </li></ul></ul><ul><ul><li>Add libraries </li></ul></ul><ul><li>Prepare code: </li></ul><ul><ul><li>Copy-paste GateTransformer.Java </li></ul></ul><ul><ul><li>Rename it to SimpleNamedEntitiyExtractor </li></ul></ul><ul><ul><li>Insert code available in SimpleNamedEntitiyExtractor.txt </li></ul></ul><ul><li>Prepare/update meta-data files </li></ul><ul><ul><li>SimpleNamedEntitiyExtractor.wsdl </li></ul></ul><ul><ul><li>SimpleNamedEntitiyExtractor.rdf </li></ul></ul><ul><li>Update CycGateDecider </li></ul><ul><li>Clean, Build and Run! </li></ul>

×
