  • 1. TALLER DE INFORMATICA:“COMPONENTES DE THE MOTHERBOARD”
    PRESENTADO POR:
    DANIELA SANTIBAÑEZ SALAZAR
    GRADO 11-1
    INSTITUCION EDUCATIVA
    NARCISO CABAL SALCEDO
  • 2. INSTALACION DE LOS COMPONENTES
    COMIENZA LA INSTALACION DE LA CPU O RAM
  • 3. RAM 1
  • 4. pestillos RESALTADOS para asegurar RAM
  • 5. RAM 2
  • 6. pestillos RESALTADOS para asegurar RAM
  • 7. CPU
  • 8. ZONA RESALTADA PARA ASEGURAR LA CPU
  • 9. APLICAMOS EL THERMAL COMPOUND
  • 10. ATORNILLAR PARA ADHERIR EL DISIPADOR DE CALOR
  • 11. CONECTAMOS EL DISIPADOR DE CALOR (VENTILADOR)
  • 12. LA MOTHERBOARD CON TODOS SUS COMPONENTES BIEN INSTALADOS
