Deliverance
                  Deliverance
Plone theming without the learning curve


      Plone Symposium East 2009
     ...
Who am I?

• Using Plone since 2002
• Founder/President of Jazkarta since 2004
• Not a designer but work with many designe...
Put this nav and content...
Put this nav and content...
Put this nav and content...
...into this website design.
...into this website design.
...into this website design.
Voila!
Voila!
Voila!
How long did this take?
2 minutes
How many lines of code?
2 rules
And I didn't touch
  www.psu.edu
       (honest)
Agenda
• What is the problem with Plone theming?
• What is Deliverance?
• Who is it for?
• When might you consider using D...
Theming in Plone
       an exercise in patience
• Install dependencies (Python, XCode, GCC)
• Create a theme egg using pas...
Knowledge needed
• Buildout
• Paster
• Zope page templates (ZPT)
• Python
• ZCML
• resource registry (for CSS and JS)
• /s...
Designers are not coders
      quot;It is a significant disadvantage if
      the designers and HTML/CSS
      coders are n...
Who is it for?

• Designers
• Integrators
• Customers
• First-timers
When you might consider
  using Deliverance?

 • Consulting projects
 • Heterogenous environment
 • Designers are not fami...
Why use it?

• Designers don't want to learn unusual stuff
• Sometimes the design already exists
• Reduce size of stuff-un...
Why not?

• Plone 2.5/3.0 is easy enough to theme
• Might be hard, but worth it
• I'm both the developer and UI person
• I...
Who is using it?

• The Open Planning Project
• repoze.org
• plone.tv
• plone.org
TOPP

• Many different
  systems
• All being themed
  using Deliverance
• topp.openplans.org
TOPP

One Deliverance
theme for:
• Plone site
• Wordpress site
• Task tracker
repoze.org

nginx   Deliverance
proxy      proxy
Home page
Blog
Issue tracker
Mailing lists
plone.tv uses Deliverance
plone.org uses Deliverance
How does it work?
move elements from your content


into placeholders in your theme


... without touching the theme or co...
Black magic?
         (well, not really)

• uses a rule file to govern the merging
• rules are verbs of common actions
• us...
What are the verbs?

• drop
• append
• prepend
• replace

                     Rules documentation:
     http://deliveranc...
Let's look at an example
How do I make this...
...look like this?




http://www.oswd.org/design/preview/id/3293
With Deliverance!


      Deliverance
Replace the logo

• Replace the logo in the theme with the
  logo in the Plone site.
• Use Firebug to identify the CSS sel...
#portal-logo img
#logo h1
Rule to replace logo


<replace content=quot;____________quot; theme=quot;_______quot; />
Rule to replace logo


<replace content=quot;#portal-logo imgquot; theme=quot;________quot; />
Rule to replace logo


<replace content=quot;#portal-logo imgquot; theme=quot;#logo h1quot; />
Logo placeholder is
replaced with real logo
Slightly more complex
        example
• Replace horizontal navigation tabs with
  Plone's portal_tabs
• Uses children: to ...
children:#portal-globalnav
children:#links ul
Rule to replace navigation


<replace content=quot;__________________quot; theme=quot;____________quot; />
Rule to replace navigation


<replace content=quot;children:#portal-globalnavquot; theme=quot;____________quot; />
Rule to replace navigation


<replace content=quot;children:#portal-globalnavquot; theme=quot;children:#links ulquot; />
Dummy text for top
navigation is replaced
Introducing XPath

• Replace page title and description and body
  text
• Theme doesn't have explicit identifiers for
  the...
children:#parent-fieldname-title
children:div#leftbar h2
Rule to replace heading


<replace content=quot;children:#parent-fieldname-titlequot;
theme=quot;children:div#leftbar h2quo...
p.documentDescription
No class or id for this
Use XPath to get the
 element identifier
XPath

• The XPath expression that Firebug gives us:
 • /html/body/div/div/div[3]/div[2]/p
• since the <div> above the <p>...
Replace the first
       paragraph with the
      document description
<replace content=quot;p.documentDescriptionquot; the...
children:#parent-fieldname-text
What is the XPath for
 the 2nd paragraph?
What is the XPath for
 the 2nd paragraph?


• children://*[@id=quot;leftbarquot;]/p[2]
Map body text to 2nd
         paragraph

<replace content=quot;children:#parent-fieldname-textquot;
theme=quot;children://*...
Logo, nav, heading,
description, body text
Logo, nav, heading,
description, body text
XPath of more link
Remove the more link
     with drop


<drop theme='/html/body/div/div/div[3]/div/a' />
Other cool features of
   Deliverance 0.3
• modify attributes
• drop a particular CSS file
• conditionals (when logged in, ...
Modify attributes
 Replace tags
Debugging console
Edit rules TTW
Ways to run
          deliverance

• proxy
• WSGI middleware using repoze
• xdv (using Martin's collective.xdv)
Proxy


• Deliverance runs on port 5000 and
  forwards requests on to port 8080
• Two separate Python processes
WSGI Middleware

• Deliverances runs as WSGI middleware
• Only one Python process
• Example showing Zope and Zine running ...
Make your blog look
like your Plone site
Zine - python blogging tool
paste.ini
[pipeline:zope]                          [filter:deliverance]
pipeline = egg:Paste#cgitb               use = egg...
rules.xml
<ruleset>

  <theme href=quot;/zope/Plone/main_templatequot; />

  <rule>

    <prepend theme=quot;//headquot; c...
Zine themed as Plone
collective.xdv
• tightly integration solution with Plone
• applies a transformation to Plone's HTML
  output, using the XD...
collective.xdv
xdv vs. Deliverance 0.3
        Pros and Cons
Pros for xdv


• Deployment is simpler, as pure XSLT
• No runtime overhead of another long-
  running Python process
Cons for xdv
• Somewhat less natural selectors/rules (i.e.
  you can't use CSS selectors, at least not
  directly)
• Less ...
Pros for Deliverance 0.3

• Has a dedicated maintainer
• More powerful - can combine multiple
  themes without requiring A...
Cons for Deliverance 0.3

• More power means people will start doing crazy
  things
• Makes most sense (for Plone) in a WS...
Thanks to...


Paul Everitt
Thanks to...


Paul Everitt
Thanks to...


Paul Everitt     Ian Bicking
Thanks to...


Paul Everitt     Ian Bicking
Thanks to...


Paul Everitt     Ian Bicking   Aaron VanDerlip
Your chance to
      contribute and learn!
            Deliverance documentation sprint

• produce the Definitive
  Deliver...
Your chance to
      contribute and learn!
            Deliverance documentation sprint

• produce the Definitive       • l...
More info
•   http://svn.plone.org/svn/collective/deliverancedemo/

•   http://www.openplans.org/projects/deliverance/
   ...
Photo credits


• http://www.flickr.com/photos/sir_mervs/
  2697096089/
