    Eclipse Modeling & MoDisco - An Introduction to Modeling and (Model Driven) Reverse Engineering Eclipse Modeling & MoDisco - An Introduction to Modeling and (Model Driven) Reverse Engineering Presentation Transcript

    • Eclipse Modeling & MoDisco An Introduction to Modeling and (Model Driven) Reverse Engineering Hugo Brunelière Nantes (France) September 201121/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 1
    • Outline AtlanMod: an expert research team in Modeling Modeling in General… – Base definitions – MDE core techniques Modeling in Eclipse… – Modeling inside/with Eclipse.org – EclipseLabs labeled “Modeling” Modeling in Practice… – MDE implantation in the market – AtlanMod situation in this big picture Model Driven Reverse Engineering (MDRE) & MoDisco – General approach & possible scenarios – Eclipse-MDT MoDisco as a MDRE solution – MoDisco architecture and main components MoDisco in Action… 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 2
    • AtlandMod: an Expert Research Team in MDE/Modeling  A common team between INRIA, Ecole Application Driven Research “Pôles de compétitivité” des Mines de Nantes Virtuous triangle (EMN) & LINA Expertise on Model Labs (scientific experts) Driven Engineering (MDE) Focus on “Modeling OMG Technologies for Eclipse Open source Software Production, Etc. Evolution, and SMEs Big Companies Operation” (technology providers) (end-users)21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 3
    • Modeling in General…21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 4
    • Model Driven Engineering (MDE) / Modeling Modeling: abstracting a (usually simplified) view from a complex reality – Objective: use the appropriate abstraction level! – Simple principle: “Everything is a model” MDSD (software development) MDE (engineering) MDSD MDE 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 5
    • Models & Metamodels A simple example  The city center of Nantes = a system to be modeled  A map is a model of this system  Its legend is a metamodel 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 6
    • Models & Metamodels DefinitionsA model is the result, System Metamodelobtained automatically, S MMsemi-automatically or fullymanually, of the observation representation of conforms toof a system considering a givenmetamodel with specific objectivesor purposes. Model MExamples of metamodels:UML2, Java, SQL, MS Word, etc.Sales, banking or insurance domains, etc. 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 7
    • The 3-level Modeling Stack Metametamodel MOF EBNF M3 (or Ecore)conforms to conforms to conforms to conforms to conforms to conforms to Metamodel Java language UML2 M2 grammar conforms to conforms to conforms to A UML A Java Model M1 class diagram program 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 8
    • MDE vs. MDA MDE – Model Driven Engineering – Generic term for everything that is “Modeling” – Principles, techniques, tooling and applications MDA – Model Driven Architecture – An Object Management Group (OMG) trademark – An interpretation of MDE  Overall architecture and underlying standards  No implementations of the specifications! 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 9
    • MDE Core Technique/Operation: Model Transformation Models are designed/built/generated to be – Observed – Transformed A simple “MDE Equation” – Models + Transformations = Software http://modeling-languages.com/models-transformations-software/ Transform models into: – Other models – Source code – Structured/unstructured data – Etc. 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 10
    • MDE Core Technique/Operation: Model Transformation Model-to-Model Transformation (M2M) – Semantic or syntactic mappings at model level Java ATL UML2 Metamodel Metamodel Metamodel Conforms to Conforms to Conforms to Transformation Java-to-UML2 Model a Model b 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 11
    • Other MDE Core Techniques/Operations… Model-to-Text Transformation (M2T) – Code generation, data generation Model decoration – Annotation of existing models Model weaving – Linking, merging, composition, etc Model extension – Dynamically (at runtime) or statically Global model management – Model metadata handling 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 12
    • Domain Specific Languages (1) DSLs vs GPLs? – GPL = General Purpose Language  Cover a wide variety of application domains – E.g., several well-know GPLs for programming  C/C++, Java, C#, etc. General Purpose Modeling Languages (GPMLs) – A simple principle: a single language for modeling everything – Most famous GPML is UML 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 13
    • Domain Specific Languages (2) DSL: a language dedicated to a given domain or a specific range of problems – “formally” introduced quite recently – Already used since a long time ago in practice Some well-known DSL examples – Unix Shell scripts, a DSL for data organization – HTML, a DSL for defining structured Web pages – CSS, a DSL for the layout of these Web pages – SQL, a DSL for database querying – And many others… 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 14
    • Domain Specific Languages (3) What a DSL actually is? – An abstract syntax defining the handled concepts  A metamodel or domain model – One or several concrete syntaxes  Textual and/or graphical – A related manipulation tooling  For the DSL and underlying models Eclipse “Modeling” provides support for this… 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 15
    • Modeling in Eclipse…21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 16
    • What is Eclipse? (1) A not-for-profit corporation – The Eclipse Foundation – Funded in January 2004  From 2001 to 2003, only a consortium – Borland, IBM, Rational, RedHat, etc. – Headquarters in Ottawa, Canada Development platform, runtimes and application frameworks – Building, deploying and managing Software – Much more than only a Java IDE!!! 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 17
    • What is Eclipse? (2) An open source community & ecosystem – Based on meritocracy, transparent processes & public communications – But supported by the main actors in IT  IBM, Oracle, SAP, Google, Nokia, etc. A different business model – Core software components given to the community – Proprietary software can freely rely on them – Dedicated support & service are sold around them – Benefits made on the domain/technical expertise 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 18
    • Eclipse Structure The Foundation staff (13 persons) – Direction – Marketing – Ecosystem management – Legal affairs – Webmasters Eclipse committers in the various projects (situation in September 2011) – More than 570 regularly active committers (and more than 1400 in total) – More than 60 different organizations/companies 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 19
    • Eclipse Top-level Projects (1) Eclipse Project (i.e., the Eclipse Platform itself) – Support for all the other projects Data Tools Platform – Data centric technologies (extensible frameworks and exemplary tools, e.g., for SQL) Business Intelligence and Reporting Tools (BIRT) – Reporting system for Web applications Eclipse Modeling Project – Plenty of cool “modeling” stuffs… (detailed right after!) Eclipse Technology Project – Technology explorations or incubators (various domains) Mylyn – Task-Focused Interface for Eclipse 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 20
    • Eclipse Top-level Projects (2) RT – Intermediate services for complex environments – Based on Equinox framework and OSGI SOA Tools Platform Project – Frameworks and exemplary extensible tools dedicated to SOA Tools Project – Support for different technologies (C/C++, PHP, etc) Test and Performance Tools Platform Project – Frameworks and services for testing and evaluation Eclipse Web Tools Platform Project – Tools for developing Web and Java EE applications 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 21
    • The Eclipse Modeling Project (1) EMP (http://www.eclipse.org/modeling/) – Evolution and promotion of model-based development technologies – A unified set of modeling frameworks, tooling, and implementations of standards – Included technologies based on the Eclipse Modeling Framework (EMF) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 22
    • The Eclipse Modeling Project (2) Abstract Syntax Development (modeling core infrastructure) – Eclipse Modeling Framework (EMF) Concrete Syntax Development – Graphical Modeling Project (GMP) – Textual Modeling Framework (TMF) Model Development Tools (MDT) – Tooling for “Modeling” standards 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 23
    • The Eclipse Modeling Project (3) Model Transformation – Model-to-Model Transformation (M2M) – Model-to-Text Transformation (M2T) Amalgam – Packaging, integration and usability of Modeling Projects components Technology and Innovation – Eclipse Modeling Framework Technology (EMFT), incubator for EMF-related tools 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 24
    • Eclipse Modeling Framework (EMF) Ecore The EMF core metametamodel Definition of metamodels (or domain models) A de-facto standard for modeling… 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 25
    • Eclipse Modeling Framework (EMF) Project Core modeling framework – Complete model handling API (Java) – Generative approach  Java code generation from metamodel definition – Reflexive approach  Dynamic handling of models via the generic API Related support – Scalability (CDO) – Comparison (EMF Compare) – Querying (Model Query) – Transactions (Model Transaction) – Validation (Validation Framework) – And a few others 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 26
    • Eclipse Modeling Framework Technologies (EMFT) Project Incubator for technologies extending/complementing EMF – New tools may be integrated in EMF later… Some of the included (sub)projects – EMF Facet  Dynamic extension of models – EEF (Extended Editing Framework)  Generation of forms for editing models – Ecore Tools  Graphical Ecore model editor – MWE (Modeling Workflow Engine)  Orchestration of model processing workflows – EMF Index  Indexing of big models… 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 27
    • Model Development Tools (MDT) Project Industry standard modeling (big “M”) – EMF-based implementation of standards, related tooling Some of the included (sub)projects – MoDisco  Model Driven Reverse Engineering framework – UML2 (Unified Modeling Language) – BPMN2 (Business Process Model and Notation) – OCL (Object Constraint Language), – SBVR (Semantics of Business Vocabulary and Business Rules) – Papyrus  Model edition environment for UML, SysML, MARTE… – XSD (XML Schema Definition)  Manipulation API for XML schemas and documents 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 28
    • Model To Model (M2M) & Model To Text (M2T) Projects M2M: declarative languages and technologies for model-to-model transformation – ATL (AtlanMod Transformation Language)  Full implementation – Operational QVT  Partial implementation – Declarative QVT  No implementation M2T: template languages and technologies for generation of textual artifacts from models – Acceleo  OMG MTL standard implementation and tooling – Xpand  Statically-typed template environment – Jet  Older code generation facilities 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 29
    • Concrete Syntax Development Projects GMP (Graphical Modeling Project): development of graphical DSLs and related editors – GMF Runtime  Common application framework – GMF Tooling vs. Graphiti  Two solutions relying on GMF Runtime TMF (Textual Modeling Framework): development of textual DSLs and related editors – Xtext  Grammar-to-metamodel generative approach – TCS (Textual Concrete Syntaxes)  Metamodel-to-grammar generative approach 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 30
    • “Modeling” Eclipse Labs Eclipse Labs vs. Eclipse Projects – Hosted on code.google.com, not on Eclipse Foundation servers – Less constraints: experimentations, innovative prototypes Some interesting EMF-related tools available as Eclipse Labs – Virtual EMF  Transparent composition, weaving and linking of models – EMF Profile  Profile support for EMF-based models – EMFtoCSP  Formal verification of models using constraint programming – Bundle Configuration for Build  Automated initialization of build configurations from OSGI bundles – EMFPath  Google Guava extension and utilities for EMF (navigation) – yakindu  Model-driven development toolkit for embedded systems 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 31
    • Modeling in Practice…21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 32
    • MDE Implantation in the Market (1) Some companies working actively on MDE – Worldwide – From France Some big companies using MDE 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 33
    • MDE Implantation in the Market (2) Common uses of MDE in companies – (Business) Process Modeling (e.g., BPMN) – Forward Engineering  Software design and specification  Software development process automation (notably code generation) – Reverse Engineering (from legacy systems)  Software design/specification recovery  Software migration – Quality assurance (of Software and related data)  Checking, verification, validation – Interoperability (between tools, data, ISs)  Make the present/future work with the past (legacy) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 34
    • MDE Implantation in the Market (3) So finally, do we put “Modeling” inside companies? (YES, but…) – Right amount of modeling (positive pains/gains ratio) – Potential initial decrease of productivity (mid/long-term investment) – Social and organizational aspects (adoption guidelines) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 35
    • AtlandMod Involvement in “Modeling” Model Transformation – M2M ATL (collaboration with Obeo) Model Dynamic Extension – EMFT EMF Facet (collaboration with Mia- Software) Model Driven Reverse Engineering – MDT MoDisco (collaboration with Mia-Software) Model Weaving – GMT AMW (prototype) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 36
    • AtlandMod Involvement in “Modeling” Model Virtual Linking/Composition – Virtual EMF (prototype on Eclipse Labs) Model Verification – EMFToCSP (prototype on Eclipse Labs) Model Annotation/Decoration – EMF Profile (prototype on Eclipse Labs) Global Model Management – AM3 (part of MoDisco, prototype) DSL Textual Concrete Syntaxes – TMF TCS (prototype) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 37
    • Now Let’s Focus on MDRE and MoDisco…21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 38
    • Different Possible Reverse Engineering Scenarios Legacy Technologies Outputs Scenarios Source code Metrics • Quality Analysis Databases Models • Understanding • Code Refactoring Configuration • Technical Migration files New system • EtcOther sources Documentation 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 39
    • Model Driven Reverse Engineering (MDRE) Approach Use models to represent and manipulate artifacts from existing systems Existing Discover Understand Transform Legacy System Software artifacts : New - source code Models Viewpoints - configuration files Software Artifacts - tests - database -… 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 40
    • Model Driven Reverse Engineering (MDRE) Approach Discover Java metamodel MoDisco Java conforms to Discoverer Java source code Java model JUnit3 code JUnit3  Navigate MoDisco Model Browser 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 41
    • Model Driven Reverse Engineering (MDRE) Approach Understand Java model JUnit3 Java JUnit3 Customization Facets MoDisco Models uses ModelBrowser JUnit3  Extract Queries 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 42
    • Model Driven Reverse Engineering (MDRE) Approach Transform JUnit3 to JUnit4 M2M Transformation Java model Java model JUnit3 JUnit4 JUnit3 Facets  Regenerate Java source code JUnit4 code 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 43
    • Eclipse-MDT MoDisco An Eclipse framework to support the elaboration of Model Driven Reverse Engineering solutions  Official Eclipse Modeling project (in MDT)  Open-source (EPL)  Based on other Eclipse Modeling projects  Released with Helios & Indigo  Supported by the OMG  Reference implementations for ADM (Architecture  Driven Modernization) standards:  KDM (Knowledge Discovery Metamodel)  SMM (Structured Metrics Metamodel)  ASTM (Abstract Syntax Tree Metamodel)21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 44
    • MoDisco: Global Architecture Supported Technologies Java ... JSP XML Metamodel Metamodel Metamodel Discoverer Discoverer Discoverer Generator Generator Generator Transfo. to KDM/UML Discovery Model Customization OMG/ADM Manager Browser & Extensibility Standards Plug and orchestrate Navigation through Definition of Pivot metamodels transformations complex models specific viewpoints (KDM, ASTM, SMM) Infrastructure Eclipse Modeling projects21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 45
    • MoDisco Model Browser A feature-rich Ecore model browser Generic (metamodel- independent) Customizable (display, fonts, colors, icons, etc.) Advanced navigation & search capabilities 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 46
    • MoDisco Discoverer Manager Define and register model discoverers – Support for different legacy technologies 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 47
    • MoDisco Workflow Specify reverse engineering processes – Chain discoverers, transformations & generations 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 48
    • MoDisco Support for Java Technology-specific components for Java Complete metamodel Corresponding discoverer & generator Transformation to KDM Advanced composite discoverer (Java + KDM) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 49
    • MoDisco Support for JEE Technology-specific components for JEE Complete JSP metamodel & corresponding discoverer Discoverers for web.xml & ejb- jar.xml files (based on XML) + generic framework JEE queries & facets (based on Java) 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 50
    • MoDisco Support for XML Technology-specific components for XML Generic support (XSD- or DTD- independent) Complete metamodel (based W3C specification) Corresponding discoverer 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 51
    • MoDisco in Action…21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 52
    • Thanks for your attention! Useful links – Eclipse Modeling Project  http://eclipse.org/modeling/ – Eclipse Labs “Modeling”  http://code.google.com/a/eclipselabs.org/hosting/search?q=label%3a Modeling – Eclipse-MDT MoDisco project  http://www.eclipse.org/MoDisco AtlanMod Contact – Hugo Bruneliere  R&D engineer & MoDisco project co-leader  hugo.bruneliere@inria.fr 21/09/2011 © AtlanMod - atlanmod-contact@mines-nantes.fr 53
