Design Patterns
  illustrated




        Herman Peeren          May 31st 2010
              (DP-illustrations: Nelleke Ve...
Design Patterns
●●   recipes against common (OO-) programming problems
●●   code reuse: no need to reinvent the wheel
●●  ...
The one constant in software development:
The one constant in software development:



CHANGE!
The one constant in software development:



CHANGE!

                     I knew it ...
Ideal: code as modular black boxes
Wish list and OOP-principles
●●   loose coupling: 1 change = ceteris paribus

●●   code reuse (is not the same as copy/pas...
Avoid: tight coupling!
It might get you into trouble...
Beware of:



Code
smells!
some code smells:
1.●   duplicate code: DRY
2.●   long method, huge class: SRP
3.●   combinatorial explosion (similar clas...
some code smells:
1.●   duplicate code: DRY
2.●   long method, huge class: SRP
3.●   combinatorial explosion (similar clas...
Classic pattern categories
creational, structural and behavioral patterns:

●●   creational: object instantiation
●●   str...
Creational design patterns
●● Factory Method: Allow subclasses to “decide”
   which class to instantiate.
●● Abstract Fact...
Factory Method
    Provide an interface for the creation of objects.
    Allow subclasses to “decide” which class to insta...
Abstract Factory
    Povide an interface for creating families of related
    or dependent objects. A factory for factorie...
Builder
    Seperate the construction process (how) of a complex object
    from the concrete representations (what).
c
Singleton
    Ensure a class only has one instance, and provide a global
    point of access to it.




                  ...
Joomla!
●●   JFactory: a class with static methods to instantiate objects
     like JDatabase, JUser, JDocument, JTemplate...
“Every
      advantage
        has its
   disadvantages”
(free to Johan Cruyff,
Dutch Football Pattern Designer
and Ajax-f...
Prototype
    Make variations on copies of a basic-object.




                              COPY-SERVICE
c
Structural design patterns
●● Adapter: Adapt an interface to an expected
   interface.
●● Bridge: Decouple an interface fr...
Adapter (= Wrapper)
c   Adapt an interface to an expected interface.
Joomla!
●●   new in 1.6: JAdapter and JAdapterInstance

●●   JUpdateAdapter extends JAdapterInstance

     JUpdaterExtensi...
Bridge
    Decouple an abstraction from its implementation.




                                                          ...
Composite
    Create a tree structure for part-whole hierarchies. A node is also a
    (part of a) tree. Recursive:
c
Decorator
    Add extra functionallity (at runtime),
    while keeping the interface the same.
    Matroushka’s...
c
Decorator




Nooku
●●   KPatternDecorator: a general decorator
●●   e.g. extended by KDecoratorJoomlaApplication
Facade
    Provide a general (simpler) interface for a set of interfaces.




              looks
             simple
c
Flyweight
    Use one instance of a class to provide many
    “virtual” instances.
c
Proxy
    Provide a surrogate or placeholder for another object
    to control access to it.
c
Behavioral design patterns
●● Chain of Responsibility: Define a method of passing a
request among a chain of objects.
●● C...
Command
    Encapsulate a command request in an object.




                      YOU,DO YOUR
                         TAS...
Chain of Responsibility
c
    Define a method of passing a request among a chain of objects.
Nooku
●●   KCommandChain
     + KCommandContext, KCommandEvent, KCommandHandler and
     KCommandInterface

●●    N.B.: ex...
Interpreter
    Domain -> (little) language -> grammar -> objects
    (DSL)



              HÉ!         he means:
       ...
Iterator
    Enable sequential access to collection elements, without showing
    the underlying data-structures (array, l...
Mediator
c   Layer in between: communication via one object.
Memento
    Save and restore the internal state of an object.




                                          ME
c
Observer
    Notify “subscribers” of changes.



                                            ME

                         ...
Joomla!
●●   JObserver and JObservable
●●   JObserver extended by JEvent and that by JPlugin




Nooku
●●   KPatternObserv...
State
Let an object show other methods after a change of internal
state (as if it changes it’s class).



      in a.....h...
Strategy
    When something can be done in several ways, make those
    ways interchangeable.




                       P...
Template Method
    The skeleton of an algorithm is fixed, but parts can be filled in
    differently.
c
Visitor
    Make a kind of plugin-possibility for methods: in that way me-
    thods can be added in runtime.




        ...
extra: Mixin
●●   Used in Nooku (and a.o. in Ruby and Python)
●●   a kind of abstract class that is mixed into another obj...
Golden OO-principles

 ●●   encapsulate what varies, OCP

 ●●   1class, 1 responsibility, SRP

 ●●   program against an in...
Some books
GOF: 23 “classical” patterns:




                               very nice!


                    classic,
    ...
good start




       Fowler:
       extended
       e.g. with
       patterns
       for web



Fowler: also
known from
r...
Resign Patterns:
Ailments of Unsuitable Project-Disoriented Software
Joomla!
Could be improved by studying design patterns and applying
them.

                                           Loose...
Questions?



Contact info:
Herman Peeren
herman@yepr.nl
© Yepr
