TomTom Dynamic Routing TechnologyHeiko Schilling
Navigate to …                    … how it works       On-board            Off-board: routes.tomtom.com             Identic...
Navigate to …   … how it works
Navigate to …   … how it works
Navigate to …   … how it works
Navigate to …   … how it works
Navigate to …   … how it works
Navigate to …                           … how it works     Did you know that:     -  Up to 15 alternative routes        be...
Standard Speed Input: Flat Speed Profile (Single Value)A8 Zaanstad ➔ AMSConfidential & Internal - TomTom International b.v...
10
IQR Speed Input: Time-Dependent Speed ProfileA8 Zaanstad ➔ AMS, towards townConfidential & Internal - TomTom International...
IQR Speed Input: Time-Dependent Speed ProfileAMS ➔ A8 Zaanstad, outwards townConfidential & Internal - TomTom Internationa...
IQR Speed Input: Step Function of Speed ValuesAMS ➔ A8 Zaanstad, outwards townper profile one look-up table with 7x24x12 v...
Route Planning with Time-Dependent Speeds                                      Destination @ 17:00                   B   A...
Route Planning with Time-Dependent Speeds                                              Destination @ 17:02                ...
Route Planning with Time-Dependent Speeds                                    17:02                                     17:...
Time-expanded Network                                                  Time       Implicitly we are working on a much more...
Continuous Re-calculation                             17:02                               17:07        16:00      continuo...
TomTom’s Challenge: To find the Best Routeamongst all Options for any Traffic SituationEurope Map: 50 million crossings, 1...
On-Board Planning Time (200 km route)          TomTom   10   20   30   40      50      60 sec.          100%             -...
Fast & Exact Routing: On-Board Planning Time (200 km)      TomTom    20% BETTER* routes in Europe    30% BETTER* routes in...
FAST & EXACT Routing – Off-Board Planning Time: 10–35ms  200.000 routes requests categorized according to distance:      •...
FASTFast EXACTRouting Demo           & & Exact Routing Demo                  DEMOStandard Calculation Time: 35 Seconds    ...
FAST & EXACT Routing Demo    Standard                                 FASTCalculation Time:                     Calculatio...
Apollo: Exact Route PlannerLuxembourg 2008.10 map•  Identical        ETT w/o Apollo                 = 86%•  Faster        ...
Sunday Lunch Time: Apollo saved you 12 minutes of 1:26 hrs       A* std route                Apollo route
Thursday afternoon: Apollo saved you 13 minutes of 1:11 hrs       A* std route                 Apollo route
User Benefits ofFAST & EXACT Route Planning
User Benefit: Fast Re-Planning
User Benefit: Dynamic RoutingContinuously Searches for Better Route
User Benefit: Dynamic RoutingContinuously Searches for Better Route
User Benefit: Dynamic RoutingContinuously Searches for Better Route
Best Possible Route at Any Point in TimeBased on Historic Traffic/Speed Profiles                                          ...
User Benefit: Routing Time MachinePreview Best Route in Advance
User Benefit: Routing Time MachinePreview Best Route in Advance
