@HatemMahmoud ExpressionLab.com April 21, 2011
Agenda <ul><li>Introduction
History
Features
Conclusion
References </li></ul>
Introduction
HTML <ul><li>HTML * is the core technology of the World Wide Web
With HTML, authors describe the structure of Web pages using markup  <tags> </li></ul>*HyperText Markup Language
HTML5 <ul><li>The  new standard  for HTML, XHTML, and HTML DOM
Improves  interoperability
Introduces markup and APIs for  Web applications </li></ul>
History
1989 <ul><li>Tim Berners-Lee  proposed an Internet-based hypertext system for CERN* researchers to use and share documents...
1990 <ul><li>Tim published the first HTML specifications in a document called  HTML Tags
Tim wrote the  first Web browser
Tim wrote the  first Web server </li></ul>
1991 <ul><li>HTML   1.0  published by  IETF * </li></ul>*Internet Engineering Task Force
1994 <ul><li>Tim  founded  W3C * as the standards organization for the World Wide Web </li></ul>*World Wide Web Consortium
1995 <ul><li>HTML   2.0  published by  IETF </li></ul>
1997 <ul><li>HTML   3.2  was the first version developed by W3C and published as a Recommendation
HTML   4.0  was published as a W3C Recommendation </li></ul>
1999 <ul><li>HTML 4.1  was published as a W3C Recommendation </li></ul>
2000 <ul><li>XHTML 1.0  was published as a W3C Recommendation
Because XHTML is an  XML  application, other XML tools can be used (for example, XSLT for transforming XML content) </li><...
2001 <ul><li>XHTML 1.1  was published as a W3C Recommendation </li></ul>
2004 <ul><li>XHTML 2.0  drafts
Most major browser vendors were unwilling to implement the new features </li></ul>
2004 <ul><li>WHATWG * was formed by individuals from  Mozilla ,  Opera  and  Apple  to work on advancing HTML in response ...
2007 <ul><li>W3C formed  HTML Working Group  to work with  WHATWG
Since then, both groups have been working together on the development of the  HTML5  specification </li></ul>
2009 “ While we recognize the value of the XHTML 2 Working Group’s contributions over the years, after discussion with the...
2011
2011 <ul><li>W3C announced  2014  as the target for Recommendation </li></ul>
Features
Syntax <ul><li>No longer  based on  SGML *
Backward compatible  with common parsing of older versions of HTML </li></ul>*Standard Generalized Markup Language
DOCTYPE <ul><li>DOCTYPE is  not a tag , it is an instruction to the browser about the markup language
SGML-based DOCTYPE required a reference to a DTD* </li></ul>*Document Type Definition
HTML 4.01 Strict <ul><li>DTD does  not  include presentational or deprecated elements
Framesets are  not  allowed </li></ul><!DOCTYPE HTML PUBLIC &quot;-//W3C//DTD HTML 4.01//EN&quot; &quot;http://www.w3.org/...
HTML 4.01 Transitional <ul><li>DTD includes presentational and deprecated elements
Framesets are  not  allowed </li></ul><!DOCTYPE HTML PUBLIC &quot;-//W3C//DTD HTML 4.01 Transitional//EN&quot; &quot;http:...
HTML 4.01 Frameset <ul><li>DTD includes presentational and deprecated elements
Framesets are allowed </li></ul><!DOCTYPE HTML PUBLIC &quot;-//W3C//DTD HTML 4.01 Frameset//EN&quot; &quot;http://www.w3.o...
Browser Mode <ul><li>Standards Mode DOCTYPE exists and valid
Quirks Mode DOCTYPE doesn't exists or invalid </li></ul>
HTML5 DOCTYPE <ul><li>HTML5 requires a DOCTYPE only to enable Standards Mode </li></ul><!DOCTYPE html>
Example <!doctype html> <html> <head>   <meta charset=&quot;UTF-8&quot;>   <title> Example document </title>   </head>   <...

Semantics <ul><li>Elements, attributes, and attribute values are defined to have certain  meanings
Authors  must not  use elements, attributes, or attribute values for purposes other than their intended semantic purpose <...




Input Types
Input Types
Validation
Absent Elements basefont big center font strike tt u  frame frameset noframes acronym applet isindex

Audio <audio id=&quot;audio&quot; src=&quot;sound.mp3&quot; controls> </audio> <script> document.getElementById(&quot;audi...
Video <video id=&quot;video&quot; src=&quot;movie.webm&quot; autoplay controls> </video> <script> document.getElementById(...

2D Canvas <canvas id=&quot;canvas&quot; width=&quot;838&quot; height=&quot;220&quot;></canvas> <script>  var canvasContext...
2D Canvas
3D Canvas (Web GL) <canvas id=&quot;canvas&quot; width=&quot;838&quot; height=&quot;220&quot;></canvas> <script> var gl = ...
3D Canvas (Web GL)
SVG <svg> <circle id=&quot;myCircle&quot;    cx=&quot;50%&quot;    cy=&quot;50%&quot;    r=&quot;100&quot;    fill=&quot;u...
SVG

Web Storage <ul><li>key/value pairs </li><ul><li>Key: string
Value: any JavaScript type  </li></ul></ul>
Web Storage <script>  storagesaveButton.addEventListener('click',  function (){ window. localStorage.setItem ('value',  ar...
Web Storage <script> sessionStorage .firstname=&quot;Hatem&quot;; document.write( sessionStorage .firstname); </script>
Web SQL Database var db = window. openDatabase (&quot;DBName&quot;, &quot;1.0&quot;, &quot;description&quot;, 5*1024*1024)...
Indexed Database API <ul><li>Each  database  contains object stores
Each  object store  has a list of records
Each  record  consists of a  key  and a  value
Indexes  allows looking up records in an object store using properties of the values
Cursors  used to iterate on records of an index or object store </li></ul>
Indexed Database API var idbRequest = window. indexedDB . open ('Database Name'); idbRequest.onsuccess = function(event) {...
Offline Web applications <ul><li>Offline browsing
Cached resources load faster
Only download resources that have changed </li></ul>
Offline Web applications <html  manifest=&quot;cache.appcache&quot; > window. applicationCache .addEventListener ('updater...
